Summary of Contents for Silex technology ClickShow R101
- Page 1 User Guide Silex ClickShow R101...
-
Page 2: Table Of Contents
User Guide - Silex ClickShow R101 Table of Contents 1. Introduction ................3 2. -
Page 3: Introduction
User Guide - Silex ClickShow R101 1. Introduction Thank you for choosing the Silex ClickShow R101 wireless presentation system. This system is designed with the complex nature of today’s business in mind, allowing for a flexibility that matches the product to the customer’s needs, not the other way around. -
Page 4: Sharing From Windows Laptops Using The Soft Button Desktop App
User Guide - Silex ClickShow R101 4. Sharing from Windows laptops using the soft Button Desktop App Windows users can install the ClickShow Soft Button Desktop App and share their content from their laptop without using a physical button. The laptop and the... -
Page 5: Sharing From An Ios Device Using Airplay
User Guide - Silex ClickShow R101 5. Sharing from an iOS device using AirPlay This option works for all iOS devices that support AirPlay. To share from iOS tablets, smartphones and Mac PCs, the device should first be connected to the ClickShow base... -
Page 6: Connecting To The Base Unit
User Guide - Silex ClickShow R101 Note: If Pin Code security is enabled on the Base unit, you will have to enter a Pin code before you can share using the Android soft Button app. The Pin code can be found on the ClickShow Wallpaper on the main display. -
Page 7: Switching Between Users
User Guide - Silex ClickShow R101 • Wirelessly via the network access point (Windows and MAC laptops, Android devices, iOS devices) If the ClickShow Base unit is connected to the LAN wirelessly, then the iOS device can be connecter wirelessly to the same network. -
Page 8: How To Access The Configurator
User Guide - Silex ClickShow R101 To pair a Button, insert the USB cable of the Button in the USB port on the Base unit. The light indicator on the Button will remain static blue during the pairing process. When the Button pairing is done, the light indicator on the Button turns static red. At this point, you can unplug the Button from the Base unit. -
Page 9: Wifi Configuration
User Guide - Silex ClickShow R101 The ClickShow Base unit will automatically restart, and a random PIN Code will be displayed in the top left corner of the Wallpaper on the meeting room main display. To disable PIN Code: Connect to the Configurator (see Section 11), then go to Settings –... -
Page 10: Wireless Bridging Configuration
User Guide - Silex ClickShow R101 13.2- Wireless bridging configuration The ClickShow can connect to an access point on the Local Area Network (LAN), creating a wireless bridge between the ClickShow and the LAN. This allows the users who are connected to the ClickShow Base unit, to access the LAN (Network peripherals, internet…) and the users on the LAN, to connect to the ClickShow device... -
Page 11: Multicasting
User Guide - Silex ClickShow R101 15. Multicasting If you have multiple ClickShow devices in your enterprise, it is possible to use them for multicasting by setting one of them as a sender and the others as receivers. 1. Requirements: •... -
Page 12: Changing The Administrator Password
User Guide - Silex ClickShow R101 • Sharpness: Used to set the sharpness of the output image. • Volume: To set the audio output volume 17. Changing the administrator password To Change the default administrator password for the Configurator access, login to... -
Page 13: Update The Images Using A Usb Flash Drive
User Guide - Silex ClickShow R101 Select the image to upload for each of the ‘logo picture’ and/or ‘home picture’, then click on ‘update’. The wallpaper update will take effect immediately. The start-up screen update will take effect after an automatic reboot of the ClickShow base unit. -
Page 14: Update The System Via The Configurator
User Guide - Silex ClickShow R101 20.2- Update the system via the Configurator To update the ClickShow device, the Kernel upgrade should be processed separately first. Only when the Kernel upgrade is completed, can the OS upgrade take place. Login to the Configurator as described in Section 11 and go to Maintain –...
