Rodstation

Rodstation HD

Rodstation

Thank you for purchasing the Rodstation High Definition Camera Kit. This handbook will help you

to operate the DVR and 15 Metre Wired Camera.

Our company is only responsible for maintaining and repairing the problems arising from correct

use of the product. We are not responsible for any personal data deleted and lost caused by wrong

operation, product repair or other case. We are also not responsible for any other indirect loss caused

by incorrect use, damage or failure to follow instructions.

Any modify of software, hardware, introduction of this product will not be notified separately.

HD Camera

Camera Kit Kit Kit Kit

Camera

Table of Contents

Need help?

Do you have a question about the HD Camera Kit and is the answer not in the manual?

Questions and answers

Summary of Contents for Rodstation HD Camera Kit

Page 1 Camera Camera Kit Kit Kit Kit Thank you for purchasing the Rodstation High Definition Camera Kit. This handbook will help you to operate the DVR and 15 Metre Wired Camera. Our company is only responsible for maintaining and repairing the problems arising from correct use of the product.
Page 2: Table Of Contents
Contents Notes…….………………………………………………………………………………1 Basic Information………………………………………………………………………..2 Buttons & Interface……………………………………………………….……………..3 Installation of the Camera…………………………………………………………..…...4 Attaching & Removing the Sunshield Cover………………………………..……….. 5 Charging the DVR… …………………………………………………………………………………..Basic Operation .……………………………………………………………………….. .7 Recording & Photo…………………………………………………………………..…8,9 Play Video & Pictures..…………………………………………………………..…10,11 System Settings 13,19 ……………………………………………………………………………………..Trouble Shooting…………………………………………………….……………….….20 Specifications………………………………………………………….………….….21,22 Package Content…………………………………………………………………...….…23...
Page 3: Notes
Notes Dear customer, thank you for choosing our products. Please read the following instructions carefully before using: Must not be used in high temperature or a high humidity environment, ℃ 0~40 is the best working temperature for the DVR. Avoid putting the DVR in direct sunlight. Please insert or take out the SD card only after the DVR power is turned off.
Page 4: Basic Information
Basic Information Basic Information: Camera: 2 sets full HD 1080P cameras Night vision: 6 pcs Led Camera resolution: 5.0 MP 3200*1800 pixel Metal monitor bracket: adjustable Monitor: 7-inch HD screen with sun visor HD Video Output Interference ： F PD-Link Ⅲ...
Page 5: Buttons & Interface
Buttons & Interface Tips for symbols - 3 -...
Page 6: Installation Of The Camera
Installation of Camera Connect the five core aviation plug of camera to the DVR unit ensuring the red dot on the plug is pointing towards the back of the DVR. Press “ ” to turn on LED light, Press “ ”...
Page 7: Attaching & Removing The Sunshield Cover
Attaching & removing the Sunshade Cover The bottom of sunshade cover has 4 buckle pins. Please aim them at the button holes on monitor and push gently to load the cover into position. If you require removing the cover just gently push it to the opposite direction. To open the sunshade cover push up the button in the middle of the front cover.
Page 8: Charging The Dvr
Charging the DVR 1. Notice the battery capacity symbols before charging: Tips: The possible reason for being unable to power on monitor is battery running out. Please operate it after charging by the AC adapter or PC. 2. How to charge Charge 4~6 hours for fully charged.
Page 9: Basic Operation
Basic Operation 1. Power On/Off: Press “ ” to power on, check the moniter is operating and the Rodsation® Logo will apear on the monitor; to power off press “ ” again for a longer period. 2. LED light turn on mode selection: Turn on the monitor, LED is off.
Page 10: Recording & Photo
Record & Photo Power monitor on, and select working mode to “ ”, it is in recording/photo mode. 1. Record: Under “ ” mode, press “ ”, monitor starts to record, and screen shows red “ ”. Press “ ”again to pause and store, press “ ”...
Page 11 Record & Photo While “Overwrite” is turned on, do not press “ ” to end recording, system will automatically save the video in segments. And when the card is full, it will overwrite the earliest recording and save the latest one, keep cycle recording. Under “...
Page 12: Play Video & Pictures
Play Video/Photo When working mode selected to “ ”, it will play video & photo. Press to select “Photo” “ ” / “ ” or “Video”. Press “ ” to exit and back to main menu. 1.Play Video: When you select “Video”, press “ ”...
Page 13 Play Video/Photo 2.Play Photos ： S elect “ P hoto ” , and press “ ” to enter into photo files. Press to select “ ” / “ ” pictures, then press “ ” to view. Press “ ” to view previous photo; press “ ”...
Page 14: System Settings
System Settings Press to enter system. “ “ “ “ ” ” ” ” Language: Press t o select “Language”, and press “ ” to enter. Press “ ” / “ ” “ ” / “ ” choose your language. And press “ ”...
Page 15: System Settings
System Settings Date Time: Press to select “Date Time”, and press “ ” to enter. Press “ “ ” again “ ” / “ ” to move the cursor, and press to adjust date & time. Press “ ” to exit. “...
Page 16 System Settings Photo Size: Press to select “Photo Size” and press “ ” to enter. Press “ ” / “ ” “ ” / “ ” select “2M”/“3M”/“5M”Press “ ” to confirm & exit. Video Segment Sizes: Press to select “Video Segment Sizes” and press “ ”...
Page 17 System Settings 6. Overwrite: Press to select “ Overwrite”, and press “ ” to enter. Press “ ” / “ ” “ ” / / “ ” select “Off”/ “On”, and press “ ” to confirm & exit. If “Overwrite” is on, monitor will ill cycle record, and save the latest video.
Page 18 System Settings Time Stamp: Press to select “Time Stamp”, and press “ ” to enter. Press “ ” / “ ” “ ” / t o select “Off”/ “On”, and press “ ” to confirm & exit. If it’s on, video will be saved “...
Page 19 System Settings 10. Power Save: Press to select “ Power Save ” ， a nd press “ ” to enter. “ ” / “ ” Press t o select “ Auto LCD Off” / “Auto Power Off” and press “ ”...
Page 20 System Settings 12. Firmware Update ： P ress to select “Firmware Update”, and press “ ” to enter. “ ” / “ ” Press to select “Yes” ， a nd press “ ” to start update. Please remember to save “...
Page 21 System Settings 14. Version: Press t o select “Version” ， a nd press “ ” to view version information. “ ” / “ ” Press to exit. ， “ 15. Default Setup: Press to select “Default Setup” and press ” to enter. Press “...
Page 22: Trouble Shooting
Trouble Shooting Trouble Shooting: The unit won't power on: Maybe no power in the unit, try recharging; System halted: Press the RESET key on the bottom right corner, turn on the unit again; It cannot play M aybe the format of video file is not supported by this monitor, please ：...
Page 23: Specifications
Specifications Camera Optical Total Pixels 5.0Mega ： 3 200 （） × 1800 （） CMOS Sensor Size 5.07mm （） × 3.38mm （） HD 1080P LED lamps 6 pcs LED lamps light 15 Metre Sensitivity 0.2Lux/F1.2 Cable Lens & View angle 0.5mm F1.2 120 °...
Page 24: Specifications
Specifications Monitor Video Compression Format H.264 Video Storage HD Digital Video Input Interface FPD-Link Ⅲ Photo Format JPG 5.0 MP ： 3 200 （） × 1800 （） Storage External SD card SD card 1GB-64GB （ O ptional ） Language Multiple 7"...
Page 25: Package Content
Package Contents The following items are supplied in a Rodstation Case. HD DVR Main Body User Manual HDMI Cable USB Cable Quick Start Guide Mini SD Card DVR Charger Rodstation Carry Case When purchased as a camera kit the below is included...
