EtherWAN EW75000 Series Installation And Setup Manual

Hardened wireless lan access point
Hide thumbs Also See for EW75000 Series:
Table of Contents

Advertisement

Quick Links

EW75000 Hardened Wireless LAN Access Point
FastFind Links
Introduction
Installation and Setup Guide
Installation
Configuration

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EW75000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for EtherWAN EW75000 Series

Summary of Contents for EtherWAN EW75000 Series

  • Page 1 EW75000 Hardened Wireless LAN Access Point FastFind Links Introduction Installation and Setup Guide Installation Configuration...
  • Page 2 Disclaimer of Liability The information contained in this document is subject to change without notice. EtherWAN is not liable for any errors or omissions contained herein or for resulting damage in connection with the information provided in this manual.

  • Page 3: Preface

    Preface Audience This guide is designed for the person who installs, configures, deploys, and maintains the Ethernet network. This document assumes the reader has moderate hardware, computer, and Internet skills. Document Revision Level This section provides a history of the revision changes to this document. Revision Document Version Date...

  • Page 4: Safety And Warnings

    Safety and Warnings This guide uses the following symbols to draw your attention to certain information. Symbol Meaning Description Note Notes emphasize or supplement important points of the main text. Tips provide helpful information, guidelines, or suggestions for performing tasks more effectively.

  • Page 5: Table Of Contents

    Document Conventions ..................... iii Safety and Warnings ....................iv Abbreviations ......................iv Contents ........................v 1 Introduction ......................7 EW75000 Series Model Reference................8 2 Installation ......................9 Unpacking the Hardware ................... 9 Supplying Power ....................... 9 Digital Configuration ....................10 Connect Antennas ....................
  • Page 6 Specifications ......................50 Technology ......................50 Antenna ......................50 A.3 Power ......................50 Wireless ......................51 A.5 Physical ....................... 52 Regulatory Approvals ..................52 Interference Statement ..................53 EW75000 Hardened Wireless LAN Access Point...

  • Page 7: Introduction

    1 Introduction The eWAV EW75000 series is a family of hardened outdoor wireless access points (WAP) and client bridges providing high speed wireless connectivity for harsh and demanding environments. Comprised of high-power, long-range single and dual-band IEEE 802.11ac MIMO wireless radios with gigabit IEEE802.3at PoE connectivity, the series is hardened against extreme temperatures and water ingress.

  • Page 8: Ew75000 Series Model Reference

    EW75000 Series Model Reference Model Image Mode Wireless Modules EW75200-0804 Access Point 2.4G, 5G (AP) EW75200-1304 Access Point 2.4G, 5G (AP) EW75200-2104 Access Point 2.4G, 5G (AP) EW75000-08 Access Point 5G (AP) EW75000-13 Subscriber unit 5G (Subscriber) EW75000-21 Subscriber unit...

  • Page 9: Installation

    Supplying Power All EW75000 series models are PoE Powered Devices, and have no AC or DC power socket. Power is supplied through an Ethernet cable plugged into the RJ45 port. The cable must be connected to a switch that supports PoE, or an inline power injector.

  • Page 10: Digital Configuration

    EW75000. Use a web browser to navigate to the default IP address, and log in. Note: The PC being used to configure the EW75000 Series must be on the same subnet as the EW75000. It may be necessary to change the PC’s IP address temporarily.

  • Page 11: Physical Installation

    Physical Installation NOTE: It is recommended to test all wireless devices before final installation. This includes bench testing, and signal testing of the AP and subscriber unit in the positions where they will be mounted. Loosely mount AP and subscriber units in the intended installation spots, and ensure that the transmission signal is strong enough for the intended application.

  • Page 12: Grounding

    In areas with high incidence of lightning, it is suggested to install surge protection devices on the Ethernet cable, such as the PD1041 hardened surge protection device available from EtherWAN. This will protect the indoor network from damage caused by electrical surges through the data cable. Check your local electrical codes, and contact your EtherWAN representative to find out more.

  • Page 13: Reset Button

    Reset Button There is a reset button located at the bottom of the housing. To access the button, remove the protective cap as shown in the figure on the right. Power down the device by removing the Ethernet cable. Plug the cable back in while pressing and holding the reset button for eight seconds to reset the device operating system to its default state.

  • Page 14: Configuration

    3 Configuration Quick Set Once you have logged in, you will see the Quick Set page. This page provides several presets that allow for fast configuration of the device. Selecting an operation mode from the drop-down menu in the upper right corner causes the relevant fields for that setup to be displayed.

  • Page 15: Description Of Quick Set Modes

    Description of Quick Set Modes The Quick Set mode to be selected will depend on the intended application of the EW75000. Each mode is roughly described in the table below. MODE DESCRIPTION Controlled Access Point, an AP that will be managed by a CAPsMAN server.

  • Page 16: Advanced Mode

    Advanced Mode In Advanced Mode, menu items are arranged on the left side of the page. Items with a small black arrow can be expanded to view its sub-menu. When a menu item is selected, the corresponding layout showing relevant fields and tabs will display in the main working area in the center of the page.

  • Page 17: Description Of Menu Items

    Description of Menu Items Wireless The wireless page allows for the easy management of wireless connections. Functions are organized by tab layers across the top. Interfaces – Add, delete and manage wireless interfaces, and analyze interfaces with various tools. Clicking on an item in the table opens the detail page for that wireless interface.
  • Page 18 Interface – Shows current interfaces. Clicking on an item in the table opens the detail page for that interface. Interface List – Allows for the defining of interface sets for easier interface management in firewalls. Ethernet – Click an Ethernet connection shown in the table to view or modify its parameters.
  • Page 19 Point-to-Point Protocol (PPP) is a Layer 2 communications protocol used to establish a direct connection between two nodes. It provides Authentication via the Password Authentication Protocol (PAP), the Challenge-Handshake Authentication Protocol (CHAP), and Microsoft’s version (MS-CHAP v1/v2). Interface – All PPP client and server configurations are added and managed on this page. Click the Add New button and select the desired client or server setup from the drop-down list.
  • Page 20 Mesh The EW75000 series uses HWMP+ for wireless mesh networks. It is based on Hybrid Wireless Mesh Protocol (HWMP) from the IEEE 802.11 draft standard. It can be used instead of (Rapid) Spanning Tree protocols in mesh setups to ensure loop-free optimal routing.
  • Page 21 Accounting Authentication, Authorization and Accounting feature provides a possibility of local and/or remote (on RADIUS server) Point-to-Point and Hotspot user management and traffic accounting (for all IP traffic passing through the device; local traffic accounting is also an option). For local traffic accounting, the packet source and destination addresses are matched against an IP pair list in the accounting table and the traffic for that pair is increased.
  • Page 22 The eWAV DHCP client may be enabled on any Ethernet-like interface at a time. The client will accept an address, netmask, default gateway, and two DNS server addresses. The received IP address will be added to the interface with the respective netmask. The default gateway will be added to the routing table as a dynamic entry.
  • Page 23 and is compliant with RFC 2131. The eWAV DHCP server supports the basic functions of giving each requesting client an IP address/netmask lease, default gateway, domain name, DNS-server(s) and WINS-server(s) (for Windows clients) information (set up in the DHCP networks submenu). In order for the DHCP server to work, IP pools must also be configured (do not include the DHCP server's own IP address into the pool range) and the DHCP networks.
  • Page 24 Mangle – Mangle is a kind of 'marker' that marks packets for future processing with special marks. Many other facilities in the EW75000 series make use of these marks, e.g. queue trees, NAT, routing. They identify a packet based on its mark and process it accordingly.
  • Page 25 memory is freed and the protocol is considered as unknown. Take into account that a lot of connections will significantly increase memory and CPU usage. To avoid this, add regular firewall matchers to reduce amount of data passed to layer-7 filters repeatedly. An additional requirement is that the Layer7 matcher must see both directions of traffic (incoming and outgoing).
  • Page 26 Neighbors Neighbors – This read-only page lists all discovered neighbors in the Layer-2 broadcast domain. It shows to which interface neighbor is connected, shows its IP/MAC addresses, and several related parameters. Discovery Interfaces – Turn discovery protocol on or off for a specific interface or interfaces on this page.
  • Page 27 Routes Routes – Add new and view existing IP routes on this page. Nexthops – Nexthop lookup is a part of the route selection process. This read-only page lists all nexthops that have been established. Rules – Use this page to set routing rule parameters and actions (drop, lookup, lookup only in table, unreachable).
  • Page 28 Services This page shows the protocols and ports used by various services. Individual services can be selectively enabled or disabled. Settings The IP Settings page allows for the configuration of several IP related kernel parameters. EW75000 Hardened Wireless LAN Access Point...
  • Page 29 Socks SOCKS is a proxy server that allows TCP based application data to relay across the firewall, even if the firewall would block the packets. The SOCKS protocol is independent from application protocols, so it can be used for many services, e.g., WWW, FTP, TELNET, and others.
  • Page 30 Traffic-Flow is a system that provides statistic information about packets which pass through the device. Besides network monitoring and accounting, system administrators can identify various problems that may occur in the network. With help of Traffic-Flow, it is possible to analyze and optimize the overall network performance. As Traffic-Flow is compatible with Cisco NetFlow, it can be used with various utilities which are designed for Cisco's NetFlow.
  • Page 31 Routing Bidirectional Forwarding Detection (BFD) is a low-overhead and short-duration protocol intended to detect faults in the bidirectional path between two forwarding engines, including physical interfaces, sub-interfaces, data link(s), and to the extent possible the forwarding engines themselves, with potentially very low latency. It operates independently of media, data protocols and routing protocols.
  • Page 32 makes the protocol more scalable if multiple areas are used; routing table calculation takes less CPU resources and routing traffic is reduced. However, multi-area setups create additional complexity. It is not recommended separate areas with fewer than 50 routers. The maximum number of routers in one area is mostly dependent on CPU power you have for routing table calculation.
  • Page 33 This device supports implements RIP Version 1 (RFC 1058) and Version 2 (RFC 2453). RIP enables routers in an autonomous system to exchange routing information. It always uses the best path (the path with the fewest number of hops (i.e. routers)) available. Interfaces –...
  • Page 34 Health Read-only page that shows history of system actions. History Read-only page that shows history of system actions. Identity Setting the System's Identity (max. length of 64 characters) provides a unique identifying name for when the system identifies itself to other routers in the network and when accessing services such as DHCP, Neighbor Discovery and default wireless SSID.
  • Page 35 mme, ospf, pim, pptp, raw, route, sertcp, snmp, state, telephony, upnp, warning, wireless, backup, calc, critical, dhcp, e-mail, firewall, igmp-proxy, ipsec, kvm, lte, mpls, ovpn, ppp, radius, read, rsvp, simulator, ssh, store, tftp, ups, watchdog, write) and the corresponding Action. Actions –...
  • Page 36 Resources View resource usage for PCI, CPU, and IRQ. Routerboard This page provides basic information about the device. The Upgrade button will upgrade the device firmware. EW75000 Hardened Wireless LAN Access Point...
  • Page 37 SNTP Client This device implements the SNTP protocol as defined in RFC4330. Manycast mode is not supported. Users Users – Each user is assigned to a user Group, which defines the rights of the user. In case the user authentication is to be performed using RADIUS, click the AAA button for the configuration page.
  • Page 38 Watchdog This menu allows for the setting of a system reboot on kernel panic, when an IP address does not respond, or in case the system has locked up. Software watchdog timer is used to provide the last option, so in very rare cases (caused by hardware malfunction) it can lock up by itself.
  • Page 39 Queue Tree – Queue tree creates only one directional queue in one of the HTBs (Hierarchical Token Bucket). It is also the only way to add a queue on a separate interface. This eases mangle configuration - you don't need separate marks for download and upload - only upload will get to Public interface and only download will get to Private interface.
  • Page 40 the respective default profile. The RADIUS server database is consulted only if no matching user access record is found in router's local database. Traffic is accounted locally with Traffic Flow and Cisco IP pairs and a snapshot image can be gathered using Syslog utilities. If RADIUS accounting is enabled, accounting information is also sent to the RADIUS server default for that service.
  • Page 41 Tools The eWAV web management GUI has a wide range of built-in tools for testing, debugging, and troubleshooting. In addition to classic utilities such as ping, Telnet, and traceroute, the tools menu offers several powerful diagnostic tools with which you may be unfamiliar. It is recommended that you familiarize yourself with these tools when you are working for the first time with an eWAV device.
  • Page 42 Email This utility allows for the sending of emails from the router. This tool can be used to send regular configuration backups and exports to network administrator. Only plain authentication and TLS encryption is used. Other methods are not supported. Flood Ping Ping flood sends ICMP (Internet Control Message Protocol) echo requests to a remote host in the same manner as ping, but it sends the next request as soon as it receives a...
  • Page 43 Ping Speed The ICMP Bandwidth Tester (Ping Speed) can be used to approximately evaluate the throughput to any remote computer and thereby help to discover network 'bottlenecks'. Profile Profiler tool shows CPU usage for each process running in the eWAV device. It helps to identify which process is using most of the CPU resources.
  • Page 44 Traffic Monitor The traffic monitor tool is used to execute console scripts when interface traffic crosses a given threshold. Each item in traffic monitor list consists of its name (which is useful if you want to disable or change properties of this item from another script), some parameters, specifying traffic condition, and the pointer to a script or scheduled event to execute when this condition is met.

  • Page 45: Example: Set Up A Point To Point Link Using Quickset

    Example: Set Up a Point to Point Link Using QuickSet This section will provide a quick overview on setting up a Point to Point link using the Quick Set screen on the access point and the subscriber unit. Configure the Access Point Log into the access point.

  • Page 46: Configure The Subscriber Unit

    Configure the Subscriber Unit Log into the subscriber unit. On the Quick Set screen, use the drop-down menu in the upper right to set the device mode to PTP Bridge CPE. Then click Apply Configuration. In the lower left of this screen, there is a visual display of wireless networks detected by the EW75000.

  • Page 47: Example: Set Up A Point To Point Link Using Advanced Mode

    Example: Set Up a Point to Point Link Using Advanced Mode This section will provide a quick overview on setting up a Point to Point link using the web interface. Configure the Access Point Click on the Wireless tab in the menu on the left. All available WLANs will display. To configure an interface, double-click on the desired WLAN (in this example, wlan1), and the config screen will appear.
  • Page 48 Add ether1 & the wlan used to the bridge port by clicking the Ports tab at the top, and then using the Add New button to add the interfaces to the bridge. Click OK when finished. EW75000 Hardened Wireless LAN Access Point...

  • Page 49: Configure The Subscriber Unit

    To configure WPA2 security, navigate to the Security Profiles tab of the Wireless page. Make a new profile with the Add button and set the desired WPA2 settings. You can choose this new security profile back in the Interface configuration. Make sure to configure both ends of the link with the same security.

  • Page 50: Specifications

    Specifications Technology Specification Description IEEE 802.11 IEEE 802.11a IEEE 802.11b Standards IEEE 802.11g IEEE 802.11n IEEE 802.11ac Wireless 5G:11a :108Mbps 11n:300Mbps 11ac: 866Mbps transmission 2.4G 11b 22Mbps 11g:108Mbps 11n: 300Mbps rate Ethernet data Up to 540Mbps (LAN to wireless 11ac) rate Antenna Specification...

  • Page 51: Wireless

    Wireless Specification Description Dual band EW75200-0804, EW75200-1304 and EW75200-2104 Single band EW75000-08, EW75000-13 and EW75000-21 Frequency range 5GHz: 5150-5250 MHz and 5725 – 5850 MHz 2.4GHz: 2412- 2462 MHz Channel width 5GHz: 10MHz, 20MHz, 40MHz, 80MHz 2.4GHz: 5MHz, 10MHz, 20MHz, 40MHz Modulation 5G: OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM) 2.4G, 5G: OFDM (BPSK, QPSK,16-QAM, 64-QAM)

  • Page 52: Physical

    A.5 Physical Specification Description Operating -40 to 75°C (-40 to 167°F) temperature Designed for outdoor installation and operation Environment IP65 Protection rating 260 x 230 x 93.47mm (W x H x D) Housing 10.2 x 9 x 3.7” dimensions Large panel: 3.5kg (7.7lbs) Total device Small panel 2.5kg (5.5lbs) weight...

  • Page 53: Interference Statement

    Interference Statement Federal Communications Commission Interference Statement FCC, Class A This product has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 54 Email: support@etherwan.com EtherWAN has made a good faith effort to ensure the accuracy of the information in this document and disclaims the implied warranties of merchantability and fitness for a particular purpose, and makes no express warranties, except as may be stated in its written agreement with and for its customers.
