SP604 Series
Lift color LCD display board
Operation Instruction
S h a n g h a i S u m p o E l e c t r i c C o . , L t d .
Te c h n i c i a n s i n E l e v a t o r d e s i g n , i n s t a l l a t i o n , c o m m i s s i o n i n g , m a i n t e n a n c e
a n d t e c h n i c a l s u p p o r t r e l a t e d w i t h t h e p r o d u c t s h o u l d c a r e f u l l y s t u d y
t h i s i n s t r u c t i o n , a n d p l e a s e a p p r o p r i a t e l y r e t a i n i t f o r f u t u r e r e f e r e n c e .
Advertisement
Table of Contents
Summary of Contents for Sumpo Electric Co., Ltd. SP604 Series
-
Page 1: Operation Instruction
SP604 Series Lift color LCD display board Operation Instruction S h a n g h a i S u m p o E l e c t r i c C o . , L t d . Te c h n i c i a n s i n E l e v a t o r d e s i g n , i n s t a l l a t i o n , c o m m i s s i o n i n g , m a i n t e n a n c e a n d t e c h n i c a l s u p p o r t r e l a t e d w i t h t h e p r o d u c t s h o u l d c a r e f u l l y s t u d y t h i s i n s t r u c t i o n , a n d p l e a s e a p p r o p r i a t e l y r e t a i n i t f o r f u t u r e r e f e r e n c e . -
Page 2: Table Of Contents
Charter 1 Product Information ....................1 Product Introduction ....................1 1.2 Electric Specification ......................2 1.3 Installation Dimension ...................... 3 1.4 Product Character ......................4 Charter 2 wiring ......................... 5 Wiring Diagram ......................5 Charter 3 Set..........................6 3.1 Connector set ........................6 3.2 Sewing Jump Set ....................... -
Page 3: Charter 1 Product Information
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board Charter 1 Product Information Product Introduction Lift LCD display module receive CANBUS command to display floor number, car running state, special state such as full load, over load, maintain etc, and current time. Picture of real products is as following: 4.3 inch... -
Page 4: Electric Specification
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board Default UI is as following: 1.2 Electric Specification Input voltage 12~40V Power Operating -20~70℃ temperature ±4KV... -
Page 5: Installation Dimension
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board 1.3 Installation Dimension 1.3.1 4.3 inch LCD display Installation dimension of 4.3 inch LCD display:... -
Page 6: Product Character
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board 1.3.2 7 inch LCD display Dimension figure of 7 inch LCD display: 1.4 Product Character 1. User can design the interface picture 2. Interface picture can be changed by U disk 3. -
Page 7: Charter 2 Wiring
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board Charter 2 wiring Wiring Diagram... -
Page 8: Set
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board Charter 3 3.1 Connector set Name Explanation CON301 power input, CAN signal CON601 down call button CON602 up call button CON604 lock lift signal input CON605 fire signal input... -
Page 9: Charter 4 Using Method
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board Charter 4 Using Method 4.1 Floor Set Press Key 301, power on, enter into set menu, as following: ******************************************* * User Set Floor number Time&Date Lcd backlight Save&Exit No save&Exit... -
Page 10: Charter 5 Update Method Of Landing Call Lcd Content
Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board Charter 5 Update Method of Landing Call LCD Content 5.1 Making Method of Background Picture Form of background picture is 24 bit bmp. If picture is not this form, can be transferred by photoshop or other drawing software. - Page 11 Shanghai Sumpo Electric Co.,Ltd. SP604 Series Lift color LCD display board …… …… date character 9 d9.bmp date character - d10.bmp time character 0 t0.bmp time character 1 t1.bmp …… …… time character 9 t9.bmp time character: t10.bmp 5.3.2 File Saving Position Save tft4.3 or tft7.0 in U disk root di-rectory.
- Page 12 SP604 Series Lift color LCD display board Using Instruction Te c h n i c i a n s i n e l e v a t o r d e s i g n , i n s t a l l a t i o n , c o m m i s s i o n i n g , m a i n t e n a n c e a n d t e c h n i c a l s u p p o r t r e l a t e d w i t h t h e p r o d u c t s h o u l d c a r e f u l l y s t u d y t h i s i n s t r u c t i o n , a n d p l e a s e a p p r o p r i a t e l y r e t a i n i t f o r f u t u r e r e f e r e n c e .
