GSM/SMS/GPRS/3G/4G
Remote Relay Switch
SEMENOVIP.RU
Remote Switch ON/OFF
Device with SMS!
2/4/8 Channel Relay Outputs
Schedule Switch ON/OFF
Device
Auto Report Status by SMS!
RTU5020/RTU5021/
RTU5022
User Manual
Ver 1.3
Date Issued: 2018-01-24
King Pigeon Hi-Tech. Co., Ltd.
www.GPRS-M2M.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for King Pigeon RTU5020
Summary of Contents for King Pigeon RTU5020
- Page 1 Remote Switch ON/OFF приобрести устройство: Device with SMS! 2/4/8 Channel Relay Outputs Schedule Switch ON/OFF Device Auto Report Status by SMS! GSM/SMS/GPRS/3G/4G Remote Relay Switch RTU5020/RTU5021/ RTU5022 User Manual Ver 1.3 Date Issued: 2018-01-24 King Pigeon Hi-Tech. Co., Ltd. www.GPRS-M2M.com SEMENOVIP.RU...
- Page 2 We recommend that the advice of a registered electrician be sought before any Installation work commences. King Pigeon Hi-Tech.Co., Ltd, its employees and distributors, accept no liability for any loss or damage including consequential damage due to reliance on any material contained in this handbook.
-
Page 3: Table Of Contents
3. Standard Packing List Remote Relay Switch X 1; Antenna X 1; AC/DC adaptor (12V1.5A) X1; User Manual (CD) X 1. Note: The package does not include any SIM card. SEMENOVIP.RU Page 3 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3... -
Page 4: Mainly Features
-40~+60 °C Humidity range Relative humidity 0~90% (condensation free) Backup Battery 900mAH, last 8hours Exterior dimension L105mm*W88mm*H30mm Installation 35mm standard DIN rail(Optional) Wall mount (Default) Net Weight 500 g SEMENOVIP.RU Page 4 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3... -
Page 5: Physical Layout And Installation Diagram
Relay 1 positive input. DO2~8 Relay 2~8 positive input. The unit provides 2/4/8 relay outputs; it can be used for control different device according to requirements. The connection diagram is below: SEMENOVIP.RU Page 5 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3... -
Page 6: Initialize/Reset The Unit
3) Switch the Power Switch to ON side to powered on the Unit, holding 5seconds, then loose the RESET Button. 4) Restart the unit then recovery to factory default settings, and will enter to work mode. SEMENOVIP.RU Page 6 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3... -
Page 7: Settings&Operation
Command Return SMS Example [new password],This is the New Password, 1234P4321 stands for change ＋ ＋ n ew password please remember it carefully. password from 1234 to 4321 SEMENOVIP.RU Page 7 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3... - Page 8 DOx:xxxx Delete DO Name PWD +DO+ channel number<nn> +DEL DOx: Switch ON(Close) PWD +DOC+ channel number<nn> DOx: ON DOy:ON Switch OFF(Open) PWD +DOO+ channel number<nn> DOx: OFF DOy:OFF SEMENOVIP.RU Page 8 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3...
- Page 9 User Name: apn=access point name) Password: Inquiry PWD+AP Delete PWD+APDEL 12) Setup the Server Parameter SMS Command Return SMS Content Set Server IP PWD+IP+ IP address+*+Server port Server: Port: SEMENOVIP.RU Page 9 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3...
- Page 10 18) Setup the Heartbeat Interval (used for Modbus RTU protocol) SMS Command Return SMS Content PWD+HT+xxx Heart Pack Period:xxx second xxx=0~9999, stands for second,=0 stands for not upload, default is 60 seconds. Inquiry PWD+HTE SEMENOVIP.RU Page 10 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3...
-
Page 11: Data Communication Protocol
Operating Instructions. In no event shall the manufacturer be liable for any alarm system altered by purchasers. Any questions please help to contact us feel free. Http://www.GPRS-M2M.com The End! SEMENOVIP.RU Page 11 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3...
