Get'r Done Series Owner's Guide
Model
Bubba and Cletus
Bubba
Cletus
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
!
Obey all safety messages that follow this symbol to avoid possible injury or death.
Mask, Lens Care, Lens Replacement and Headgear Assembly Instructions
© December 2017
Get'r Done Series-M0_122017
Advertisement
Table of Contents
Summary of Contents for Save Phace Get'r Done Series
- Page 1 Get'r Done Series Owner's Guide Model Bubba and Cletus Bubba Cletus This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
-
Page 2: Safety And General Information
NOTICE: For your SAFETY - PLEASE read and follow all of these instructions exactly. If you have problems understanding these instructions or have questions, please call 1-866-783-3223. Caution! Read and follow these instructions EXACTLY for care and cleaning of the lenses. Summary The automatic welding mask is a new generation product for labor protection. -
Page 3: Main Specifications
Characteristics The Get’r Done Series automatic welding helmet is equipped with a filter set that can become dark. The filter is transparent before welding so that the operator may observe the work surface clearly. The filter immediately darkens automatically when striking arc. When arc goes out, the filter will become transparent again. The switching time from light to dark is about 0.0001 second. The switching time from dark to light may be set up within 0.1 – 0.9 second. The mask is equipped with continuous darkness-adjusting unit, so the operator may select an arbitrary dark shade number ranging from #9 to #13. The Get’r Done Series automatic welding mask gives the operator permanent complete protection against UV/IR: even in transparent conditions. - Page 4 5. Sensitivity selection By moving the SENSITIVITY selector knob (#6 on the rear of the cartridge), the sensitivity to ambient light changes can be altered. Turn to LO: The photosensitivity decreases. Suitable for high amperage welding and welding in bright light conditions (lamp light or sunlight).
-
Page 5: Replacement Parts
ASSEMBLY PARTS FOR GET'R DONE SERIES AUTOMATIC WELDING MASKS 1. Lens frame 2. Outer protection lens 3. Automatic filter 4. Inner protection lens 5. Shade knob 6. Sensitivity knob 7. Delay knob 8. Headband adjusting button 9. Segmental positioning plate 10. Headband tightness adjusting knob 11. -
Page 7: One-Year Limited Warranty
Created, Engineered, Designed & Shipped in USA Made in China and Taiwan This product meets CSA 290.3-7 Standards. ONE YEAR LIMITED WARRANTY SavePhace products undergo a strict quality control inspection for workmanship, function, and safety before leaving the factory. From the date of purchase, SavePhace will warranty or repair it's products for: one (1) year on its helmet and two (2) years on its the ADF against defects in parts and workmanship. - Page 8 NOTES:...
