OWNER'S AND ASSEMBLY MANUAL
FOR USE WITH BUTANE OR PROPANE GAS
CATEGORY I 3+(28-30/37) , CATEGORY I 3B/P(30)
CATEGORY I 3B/P(37) , CATEGORY I 3P(50)
FOR USE WITH NATURAL GAS
CATEGORY I 2E(20) , CATEGORY I 2H(20)
CONTENTS
SAFETY ............................................................. 2
LEAK TESTING ................................................ 3
LIGHTING .......................................................... 4
OPERATION ..................................................... 5
COOKING TECHNIQUES ................................. 5
MAINTENANCE ................................................ 6
TROUBLE SHOOTING ..................................... 7
ASSEMBLY ....................................................... 8
PARTS LISTING ............................................. 19
WARRANTY .................................................... 20
FITS:
Broil King® Imperial™ XLS, Imperial™ XL, Imperial™ 590, Imperial™ 490
Broil King® Regal™ XL, Regal™ S 590 Pro, Regal™ 590, Regal™ S 490 Pro, Regal™ 490, Regal™ S 440 Pro, Regal™ 440
Broil King® Baron™590, Baron™ 490, Baron™ 440, Baron™340
READ ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING.
INFRARED SIDE BURNER
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
20094-IREU REV A
01/19
