nuskin Pharmanex S3 User Manual

Biophotonic scanner
Hide thumbs Also See for Pharmanex S3:
Table of Contents

Advertisement

Quick Links

USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pharmanex S3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for nuskin Pharmanex S3

Summary of Contents for nuskin Pharmanex S3

  • Page 1 USER MANUAL...

  • Page 2: Table Of Contents

    CONTENTS AT A GLANCE SET UP YOUR S3 SUPPORT SAFETY INFORMATION SCAN WITH YOUR S3 TIPS AND TRICKS IMPORTANT TO KNOW SYNC YOUR S3 TECHNICAL SPECS OPERATOR TAB TURN OFF YOUR S3...

  • Page 3: At A Glance

    AT A GLANCE BLUETOOTH DARK CAP POWER BUTTON POWERJACK DARK CAP SERIAL # HOLDER S3 NOSE LED LIGHT > CONTINUE...

  • Page 4: Safety Information

    SAFETY INFORMATION HANDLING WARNING: Failure to follow these safety instructions could result in fire, electric ELECTRICAL WARNINGS shock, or other injuries, or cause damage to the S3 or iPad mini. Before using the S3, read the entire manual and all safety instructions GENERAL WARNINGS to ensure safe and proper use.
  • Page 5 SAFETY INFORMATION ELECTRICAL WARNINGS HANDLING A. WATER AND MOISTURE ELECTRICAL WARNINGS To reduce the risk of electric shock, do not expose the S3 to rain or moisture. GENERAL WARNINGS Do not use the S3 near water sources such as bathtubs, wash bowls, sinks, laundry machines, wet basements, swimming pools, or other receptacles SERVICING containing liquid.
  • Page 6 SAFETY INFORMATION ELECTRICAL WARNINGS HANDLING C. POWER CORDS AND POWER SUPPLIES ELECTRICAL WARNINGS Do not plug any other power cord or power supply into the S3 except GENERAL WARNINGS those provided with this unit. Do not overload wall outlets or extension cords.
  • Page 7 SAFETY INFORMATION GENERAL WARNINGS HANDLING A. EYE SAFETY ELECTRICAL WARNINGS The scanner uses LEDs (Light Emitting Diodes) as a source of light. LEDs GENERAL WARNINGS are found in household lighting, electronics, and common flashlights. While they are not generally thought of as harmful to the eye, you should SERVICING avoid staring directly into this, or any bright source, at close range or for prolonged periods of time.
  • Page 8 SAFETY INFORMATION GENERAL WARNINGS HANDLING C. USAGE LIMITATIONS ELECTRICAL WARNINGS This unit must not be used or operated in any manner other than that GENERAL WARNINGS specified by Nu Skin®. Failure to operate the unit under these conditions may impair the device’s safety features. SERVICING D.
  • Page 9 SAFETY INFORMATION SERVICING HANDLING Scanner operators and unapproved third parties should never service the ELECTRICAL WARNINGS S3. The S3 should never be opened or disassembled. If the S3 enclosure ever cracks or breaks, do not attempt to access the internal components GENERAL WARNINGS or electric circuitry.
  • Page 10 The S3 exhibits a distinct change in performance, such as the inability to perform basic functions. • The scanner shows a red X on its display even after rebooting several times. • The S3 Scanner app instructs you to call Technical Support. TECHNICAL SUPPORT techsupport@nuskin.com 1-800-487-1000 > CONTINUE...

  • Page 11: Important To Know

    IMPORTANT TO KNOW PURPOSE PURPOSE The Pharmanex® BioPhotonic Scanner S3 is an instrument that measures CALIBRATION carotenoid levels in the skin. It is not intended to be used for medical purposes. It is not a medical device or a medical diagnostic tool of any kind and is not OPERATING TEMPERATURE intended to diagnose, treat, mitigate, cure, or prevent any disease or condition, TRAVELING WITH THE S3...
  • Page 12 IMPORTANT TO KNOW CALIBRATION PURPOSE All precision scientific instruments require calibration. Most are calibrated CALIBRATION daily and some are calibrated before each measurement. The first time you use it, the S3 requires a Dark Scan and an Operator Scan. After this first OPERATING TEMPERATURE calibration is done, you will need to do a Dark Scan once every 24 hours, and an Operator Scan once every 14 days.
  • Page 13 IMPORTANT TO KNOW OPERATING TEMPERATURE PURPOSE The environmental conditions in which you store and operate the scanner CALIBRATION can affect the device. The scanner is designed to work in ambient ). The optimal temperatures between 50° and 95 °  (10° and 35 °  OPERATING TEMPERATURE scanning temperature is 68°...
  • Page 14 IMPORTANT TO KNOW TRAVELING WITH THE S3 PURPOSE When traveling with the scanner, make sure to store it in the carrying case CALIBRATION that came with it. If transporting it by air, bring it along as carry-on luggage. This minimizes the potential for added shock, jarring, and exposure to OPERATING TEMPERATURE extreme temperatures associated with checked baggage.

  • Page 15: Set Up Your S3

    SET UP YOUR S3 CHECK YOUR EQUIPMENT CHECK YOUR EQUIPMENT Please review the following equipment list to ensure CHARGE YOUR DEVICES all components are included. ACTIVATE YOUR IPAD MINI HOW TO SETUP THE S3 VIDEO SERIES - CHAPTER 1 UNBOXING AND SETUP CONNECT YOUR IPAD INSTALL THE S3 APP S3 Scanner...
  • Page 16 SET UP YOUR S3 CHARGE YOUR DEVICES CHECK YOUR EQUIPMENT The scanner and the iPad mini should be plugged into a grounded electrical CHARGE YOUR DEVICES outlet and charged using the power supplies included for at least eight hours before you attempt to operate the devices. ACTIVATE YOUR IPAD MINI HOW TO SETUP THE S3 VIDEO SERIES - CHAPTER 2 CONNECT YOUR IPAD...
  • Page 17 SET UP YOUR S3 ACTIVATE YOUR IPAD MINI CHECK YOUR EQUIPMENT Press the Power button on the top right bezel of the unit. Slide the unlock CHARGE YOUR DEVICES bar on the screen to the right to access the Home Screen. ACTIVATE YOUR IPAD MINI CONNECT YOUR IPAD POWER BUTTON...
  • Page 18 SET UP YOUR S3 CONNECT YOUR IPAD MINI TO CHECK YOUR EQUIPMENT A WI-FI NETWORK CHARGE YOUR DEVICES Wi-Fi is needed to: ACTIVATE YOUR IPAD MINI • Access the Internet. CONNECT YOUR IPAD • Install the S3 Scanner app. The S3 Scanner app must be installed INSTALL THE S3 APP on your iPad mini in order to use the scanner with your iPad.
  • Page 19 SET UP YOUR S3 CONNECT YOUR IPAD MINI TO CHECK YOUR EQUIPMENT A WI-FI NETWORK CHARGE YOUR DEVICES Activating the iPad mini will automatically display what is called the ACTIVATE YOUR IPAD MINI Home Screen. You can always return to the Home Screen by pushing the Home button at the bottom center of the device.
  • Page 20 SET UP YOUR S3 CONNECT YOUR IPAD MINI TO CHECK YOUR EQUIPMENT A WI-FI NETWORK CHARGE YOUR DEVICES • A list of available Wi-Fi networks will appear on your iPad. Tap on the ACTIVATE YOUR IPAD MINI network you want to join and enter any required security credentials. CONNECT YOUR IPAD Example: INSTALL THE S3 APP...
  • Page 21 SET UP YOUR S3 CONNECT YOUR IPAD MINI TO CHECK YOUR EQUIPMENT A WI-FI NETWORK CHARGE YOUR DEVICES • Once you have selected a Wi-Fi network, the iPad mini will ACTIVATE YOUR IPAD MINI automatically access the Internet through that signal. A Wi-Fi icon will be displayed in the upper left corner of the iPad.
  • Page 22 SET UP YOUR S3 INSTALL THE S3 SCANNER APP ON CHECK YOUR EQUIPMENT THE IPAD MINI CHARGE YOUR DEVICES ACTIVATE YOUR IPAD MINI REMINDER: For iOS9 and above, you will need to validate the app in the iPad Settings. For a complete list of instructions, please go to CONNECT YOUR IPAD www.s3scannerapp.com INSTALL THE S3 APP...
  • Page 23 SET UP YOUR S3 TURN ON YOUR SCANNER AND CHECK YOUR EQUIPMENT CONNECT IT TO YOUR IPAD MINI CHARGE YOUR DEVICES VIA BLUETOOTH ACTIVATE YOUR IPAD MINI CONNECT YOUR IPAD REMINDER: The S3 operates using a rechargeable battery. Once the battery is INSTALL THE S3 APP charged, it can be unplugged from the power supply and used as a stand-alone device for a maximum of six hours of constant use.
  • Page 24 SET UP YOUR S3 TURN ON YOUR SCANNER AND CHECK YOUR EQUIPMENT CONNECT IT TO YOUR IPAD MINI CHARGE YOUR DEVICES VIA BLUETOOTH ACTIVATE YOUR IPAD MINI Press the Home button of your iPad mini to return CONNECT YOUR IPAD to the Home Screen.
  • Page 25 SET UP YOUR S3 TURN ON YOUR SCANNER AND CHECK YOUR EQUIPMENT CONNECT IT TO YOUR IPAD MINI CHARGE YOUR DEVICES VIA BLUETOOTH ACTIVATE YOUR IPAD MINI TO FIND YOUR SCANNER IN THE S3 APP: CONNECT YOUR IPAD Make sure the Bluetooth button on the S3 is blinking. Tap on the S3 Scanner app.
  • Page 26 SET UP YOUR S3 TURN ON YOUR SCANNER AND CHECK YOUR EQUIPMENT CONNECT IT TO YOUR IPAD MINI CHARGE YOUR DEVICES VIA BLUETOOTH ACTIVATE YOUR IPAD MINI CONNECT YOUR IPAD INSTALL THE S3 APP CONNECT VIA BLUETOOTH Tap on your S3’s CS number. A window will ask if you would like to connect to the scanner.
  • Page 27 SET UP YOUR S3 TURN ON YOUR SCANNER AND CHECK YOUR EQUIPMENT CONNECT IT TO YOUR IPAD MINI CHARGE YOUR DEVICES VIA BLUETOOTH ACTIVATE YOUR IPAD MINI Once the S3 and iPad mini are linked, they will automatically try to detect CONNECT YOUR IPAD and communicate with each other when you turn them on, unless you choose to disconnect them in the STATUS tab window.
  • Page 28 SET UP YOUR S3 TURN ON YOUR SCANNER AND CHECK YOUR EQUIPMENT CONNECT IT TO YOUR IPAD MINI CHARGE YOUR DEVICES VIA BLUETOOTH ACTIVATE YOUR IPAD MINI Bluetooth is different than Wi-Fi. Wi-Fi allows a device to access the CONNECT YOUR IPAD Internet.
  • Page 29 SCAN WITH YOUR S3 THE STATUS TAB THE STATUS TAB AND S3 CALIBRATION SCAN TAB Use the Status tab to connect to your scanner, check the status of RESULT SCREEN—PROFILE your scanner, and perform the Dark and Operator calibration scans. NOTE: If you are unable to connect to your scanner because it has been locked, contact your local support team for assistance.
  • Page 30 SCAN WITH YOUR S3 THE STATUS TAB THE STATUS TAB AND S3 CALIBRATION SCAN TAB RESULT SCREEN—PROFILE REMINDER: Only one S3 unit can be linked to your iPad mini at a time. When an S3 is linked to the S3 Scanner app, the status tab will display the CS number and connection status at the top.
  • Page 31 SCAN WITH YOUR S3 THE STATUS TAB THE STATUS TAB AND S3 CALIBRATION SCAN TAB Next, you will need to perform Dark and Operator scans. These RESULT SCREEN—PROFILE calibration scans are used as quality assurance tools to track scanner consistency. Make sure the dark cap is on the S3 nose and press the Dark Scan icon.
  • Page 32 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB To scan a person, you must either purchase digital scan credits SCAN TAB or use a scan card. RESULT SCREEN—PROFILE > CONTINUE...
  • Page 33 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB A. SCAN WITH DIGITAL SCAN CREDITS SCAN TAB To purchase scan credits, tap the Purchase Scan Credits button. RESULT SCREEN—PROFILE A new window will open, where you’ll need to log in to your distributor account.
  • Page 34 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB You can purchase scan credits in units of 1, 20, or 100 by tapping on the SCAN TAB appropriate icons on the screen. RESULT SCREEN—PROFILE Once you have chosen a final amount of credits, tap the Check Out button to purchase them and add them to your S3.
  • Page 35 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB SCAN TAB NOTE: After you have purchased scan credits, you will notice that the RESULT SCREEN—PROFILE Digital Scan icon at the top will display the total number of available scan credits. Keep an eye on them to know when to purchase more scan credits.
  • Page 36 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB B. SCAN WITH A SCAN CARD SCAN TAB TO SCAN WITH A SCAN CARD: RESULT SCREEN—PROFILE Press the Scan Card button to capture a scan card with the iPad mini’ s camera, or enter the scan card number using the digital keyboard.
  • Page 37 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB > The camera lens is located in the upper-left corner of the back plate of SCAN TAB the iPad mini, just beneath the main power button. RESULT SCREEN—PROFILE IMPORTANT: Be sure that you are not covering the camera lens when trying to scan a card’...
  • Page 38 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB Put the scan card on a flat surface, and hold the iPad parallel above SCAN TAB the card. When the card is centered in the camera, the S3 Scanner app will RESULT SCREEN—PROFILE automatically recognize the barcode, enter the data into the app, and return to the Scan tab window ready to perform a scan.
  • Page 39 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB The app will verify the scan number and begin the hand scan sequence. If SCAN TAB you enter the scan card number incorrectly, the S3 Scanner app will display an error message. RESULT SCREEN—PROFILE If you want to return to the Scan tab window without scanning or typing in a scan card number, tap Cancel.
  • Page 40 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB SCAN TAB The Hand Placement information RESULT SCREEN—PROFILE button shows how subjects should place their hand for a proper scan. Select Cancel Scan to cancel the scan session and return to the Scan tab window. The scan takes about 30 seconds.
  • Page 41 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB After the scan is complete, the scan screen will show several options: SCAN TAB • You can set up an automatic order for the scanee by pressing the ORDER button (the name and scan number will automatically be RESULT SCREEN—PROFILE added to the automatic order).
  • Page 42 SCAN WITH YOUR S3 THE SCAN TAB THE STATUS TAB To exit the scan session, press Done. You will return to the Scan tab home SCAN TAB page where you can choose to use digital scan credits or enter a scan card. RESULT SCREEN—PROFILE Once you tap the Done button, you will no longer be able to see the subject’s score.
  • Page 43 SCAN WITH YOUR S3 RESULT SCREEN—PROFILE THE STATUS TAB Tapping the PROFILE button at the end of a scan will bring up a grid SCAN TAB of demographic questions. Tap on each question and select the option that best describes a person’s profile. This information will help Nu Skin® RESULT SCREEN—PROFILE record the subject’...

  • Page 44: Sync Your S3

    SYNC YOUR S3 SYNC YOUR S3 The S3 Scanner app will keep a digital copy of all your completed scans in the Records tab. Tap on the Records tab to open the Records window. You will see a list of the scans you have completed in chronological order by date and time (most recent scan first).
  • Page 45 SYNC YOUR S3 SYNC YOUR S3 IMPORTANT: You must sync the S3 Scanner app to the Nu Skin® server at least once a month and no later than the last day of the month. If you fail to do so, your scans will not count for your monthly scanner maintenance, free program, personal sales volume (PSV), or commissions.

  • Page 46: Operator Tab

    OPERATOR TAB THE OPERATOR TAB In the operator tab you can create, edit, or delete scanner operators in order to keep track of who performed what scans. The operator tab is also where you can make setting changes, such as your region or preferred language.

  • Page 47: Turn Off Your S3

    TURN OFF YOUR S3 TURN OFF YOUR S3 • Disconnect from the S3 Scanner app by selecting the Status tab and clicking on the Disconnect button. • Exit the S3 Scanner app by pressing the iPad home button. • Shut off the iPad screen by tapping the Power button briefly. •...
  • Page 48 SUPPORT SUPPORT • The support tab displays information about the iPad, the Scanner App, and the Scanner itself. This information can be used in troubleshooting specific issues with your support representative over the phone. CONTACT button: provides the email address of your local scanner support and website links where you can obtain support.

  • Page 49: Tips And Tricks

    TIPS AND TRICKS TIPS AND TRICKS The S3 Scanner app does not load when I tap on it on the Home Screen. Press and hold the S3 Scanner app icon on the Home Screen. Uninstall the app and then reinstall it by following the instructions in this manual. This step should only be taken as a last resort, as it will delete any unused digital scan credits you have purchased and will erase any un-synced scan records.
  • Page 50 TIPS AND TRICKS TIPS AND TRICKS The S3 Scanner app won’t let me perform a scan. There are several reasons why this could be happening: The scanner might not be linked to the iPad mini via Bluetooth. The iPad mini and scanner may be out of range of each other. Make sure they are within 30 m (98 ft) of each other.
  • Page 51 TIPS AND TRICKS TIPS AND TRICKS The S3 Scanner app says that my scan card is invalid. The Scan Card has probably been used. Use a different scan card or purchase a digital scan credit using the Scan tab. Where does the S3 Scanner app keep my completed scans? The app stores a list of your completed scans in the Records tab.
  • Page 52 TIPS AND TRICKS TIPS AND TRICKS SYNC Make sure your iPad mini is connected to a Wi-Fi network. If an error displays, indicating that the server does not answer, wait 10 minutes and try syncing again. If the error comes up again, contact Technical Support. If the time for syncing has expired, press the Sync button.
  • Page 53 TIPS AND TRICKS TIPS AND TRICKS SCORE VARIABILITY Score variability is common because the scanner measures carotenoids, which are found at trace levels in biological tissue. Two types of factors influence the Skin Carotenoid Score: Personal factors (genetics, diet, body mass index, environment, smoking, and sun exposure).
  • Page 54 TIPS AND TRICKS TIPS AND TRICKS BLUETOOTH To maintain your Bluetooth connection: Do not shut off the scanner while the S3 Scanner app is still running. Do not press the Bluetooth button on the back of the Scanner once you have connected.
  • Page 55 TIPS AND TRICKS TIPS AND TRICKS If you cannot establish a Bluetooth connection, first try the Bluetooth Refresh Fix. BLUETOOTH REFRESH FIX Press the Bluetooth button on the back of the scanner for five seconds until it blinks. Exit the app as normal. Reload the S3 Scanner app, and check the Status tab to see if your device has successfully reconnected to the iPad.
  • Page 56 TIPS AND TRICKS TIPS AND TRICKS POWER REFRESH FIX Shut down the S3 app. Shut off the S3 Scanner by holding the Power button down for three seconds. Power down the iPad by holding the Power button down for five seconds and swiping the red arrow when it appears.

  • Page 57: Technical Specs

    TECHNICAL SPECS TECHNICAL SPECIFICATIONS • Operating temperature: 50 ° to 95 °  (10 ° to 35 °  • Storage temperature: 40 ° to 110 °  (5 ° to 40 °  • Relative humidity: 10 to 90% non-condensing • Operating altitude: 0 to 3,000 m •...
  • Page 58 TECHNICAL SPECS TECHNICAL SPECIFICATIONS The CE marking on a product is a manufacturer’ s declaration that the product conforms with the requirements of the European Council Directives 73/23/EE and 89/336/EEC. This symbol designates that this unit is listed by Underwriters Laboratories. This symbol designates that this unit is listed by the Canadian Standards Association.
