DIY Educational Kit for Green Energy
Mini Wind T urbine Kit MT-150
- A Wind Power Generator with 14V, 6mA
- Well Designed Kit for Easy Assembling
Have the basic idea of the
wind power generation.
Assembling Guide
You can make it work
with folding fan!
www.minisolarworld.com
Advertisement
Summary of Contents for MiniSolar MT-150
- Page 1 DIY Educational Kit for Green Energy Mini Wind T urbine Kit MT-150 Assembling Guide - A Wind Power Generator with 14V, 6mA - Well Designed Kit for Easy Assembling You can make it work with folding fan! Have the basic idea of the wind power generation.
- Page 2 MT-150 Assembling Guide Components of Mini-Turbine MT-150 � � ⑮ ③ ⑬ ⑭ ① ⑦ ⑪ ④ ⑨ ⑩ ② ⑧ ⑤ ⑥ ⑫ ◉ MT-150 Components Num. Name Q’ ty Remarks Num. Name Q’ ty Remarks ① Roof of MT-150 rectangle , 50×150mm...
- Page 3 MT-150 Assembling Guide Assembling and Experiment steps Fix the magnets to lower plate. Fix the 4 magnets at the prepared places on the bottom of the ‘lower plate’ (component #3) using double-sided tape, refer to <Fig. 1>. Keep the sequence of magnet’ s polarity, N-S-N-S, refer to <Fig. 1-c>.
- Page 4 MT-150 Assembling Guide Assemble the upper plate to the pivot (aluminum pipe, <Fig. 5> component #10) Assemble the upper plate with the wings downward to the pivot thru the hole. Assemble the upper plate and lower plate to make a <Fig.
- Page 5 MT-150 Assembling Guide Set the coil windings to the base body of Mini-Turbine. 8.1. Connect the coil(A, left) to the terminal hole. Put the mini washer on the hole of terminal #1 and lead the black wire to the terminal and fix the terminal with a nut and black bolt(soket).
- Page 6 MT-150 Assembling Guide Mount the rotating body of Mini-Turbine on the <Fig. 9> base body. Put the pivot (aluminum pipe) on the iron ball in the central hole of base body. Joint two aluminum pipes (pillars, <Fig. 10> 7mm diameter, component #9).
- Page 7 LED, while you are blowing. The gauge (WT-01) <Fig. 15> The gauge for wind power generator, Mini-Turbine MT-150 is a testing equipment to see the output of the generator, such as ‘type of electric current’ , ‘brightness of LED’ s’ and ‘melody’ .
- Page 8 minisolarworld www. .com...
