Summary of Contents for Talboys 1000-3
- Page 1 InstructIon Manual advanced 1000-3 orbital shaker advanced 1000MP Microplate shaker...
-
Page 2: Package Contents
Advanced 1000-3 Orbital Shaker or Advanced 1000MP Microplate Shaker Manufacturer warrants this product to be free from defects in material and workmanship Non-skid rubber mat (Orbital Shaker only) when used under normal conditions for five (5) years. Please complete and return the 92”... -
Page 3: Installation
Always ensure the power is disconnected from the unit prior to any cleaning. If the unit ever requires service, contact your Talboys representative. -
Page 4: Safety Instructions
& r afety nstruCtions tanDarDs egulations Please read the entire instruction manual before operating the Orbital/Microplate Henry Troemner LLC hereby declares under it’s sole responsibility that the Shaker. construction of this product conforms in accordance with the following standards: Safety standards: WArning! do not use the Orbital/Microplate Shaker in a hazardous IEC 61010-1 Safety requirements for electrical equipment for measurment,... - Page 5 ontrol anel The front panel of the Orbital/Microplate Shaker contains all the controls and displays E. time display: Displays accumulated time (continuous mode) or how much time is needed to operate the unit. remaining (timed mode). The display range is from 0 to 9,999 minutes in one (1) second increments.
- Page 6 1000-3 o DvanCeD rbital haker PeCifiCations overall dimensions (L x W x H): 17 x 11 x 4” (43.2 x 27.9 x 10.2cm) tray dimensions (L x W): 11.75 x 7.75” (29.9 x 19.7cm) Electrical (50/60 Hz): 120 volts: 5 amps, 25 watts...
- Page 7 1000-3 o DvanCeD rbital haker The Orbital Shaker is supplied with a tray designed to hold a variety of accessories. 1. Flat containers can be shaken by placing them on the non-skid rubber mat provided with the unit. 2. The tray also has mounting holes ready for use with flask/media bottle clamps or test tube racks. See below for tray configurations.
- Page 8 1000MP M DvanCeD iCroPlate haker PeCifiCations overall dimensions (L x W x H): 17 x 11 x 4” (43.2 x 27.9 x 10.2cm) tray dimensions (L x W): 11 x 7.75” (27.9 x 19.7cm) Electrical (50/60 Hz): 120 volts: 5 amps, 25 watts 230 volts: 5 amps, 25 watts Fuses:...
- Page 9 1000MP M DvanCeD iCroPlate haker The Microplate Shaker is designed to hold two (2) or four (4) microplates, or two (2) Micro-Tube Racks. 1. Place two (2) microplates or deep well blocks diagonally on the tray, or place four (4) microplates or deep well blocks on the tray. The plates/blocks do not have to be filled. 2.
- Page 10 DvanCeD rbital iCroPlate haker Perating nstruCtions The Orbital/Microplate Shakers have been designed for the speed and time functions b. Simultaneously press both the up and down arrows, the display will indicate to work independently of one another. The speed can be reset without resetting zero (0:00).
-
Page 11: Operating Tips
As a safety feature, a built-in program will shut power off to the motor if the tray is load capacity before restarting the unit. If the E04 error persists, switch the unit off and prevented from rotating, or the unit is overloaded beyond its recommended weight contact your Talboys representative for repairs. capacity. Error Code... - Page 12 1000-3 o DvanCeD rbital haker ePlaCeMent arts esCriPtion uMber 1. Front panel membrane switch 385703-00 2. Tray 580050-00 3. Display board 380780-00 4. Belt 580019-00 5. Motor 380712-00 6. Motor transition board 380415-00 7. Connection cable 380720-00 8. IEC power entry module 386122-00 9.
- Page 13 1000MP M DvanCeD iCroPlate haker ePlaCeMent arts esCriPtion uMber 1. Front panel membrane switch 385702-00 2. Tray assembly 880761-00 3. Display board 380780-00 4. Belt 580019-00 5. Motor 380712-00 6. Motor transition board 380415-00 7. Connection cable 380720-00 8. IEC power entry module 386122-00 9.
- Page 14 CCessories tESt tuBE rACkS FLASk CLAMPS latforM latforM esCriPtion aPaCity aPaCity uMber esCriPtion aterial aPaCity uMber 10 to 13mm Test Tube Rack 980193 10mL Erlenmeyer Flask Clamp stainless steel 980078 14 to 16mm Test Tube Rack 980194 25mL Erlenmeyer Flask Clamp stainless steel 980079 18 to 20mm Test Tube Rack...
- Page 15 CCessories univErSAL HArnESS 2-BAr AdjuStABLE PLAtForM latforM The 2-Bar Adjustable Platform has a non-skid rubber surface with adjustable clamping esCriPtion iCroPlate aPaCity aPaCity uMber bars to accommodate various vessel types. Stainless steel construction. Universal Harness 2 or 4 980192 latforM esCriPtion aPaCity uMber...
- Page 16 Manufactured by: 201 Wolf Drive • PO Box 87 • Thorofare, NJ 08086 • Phone: 1-888-TALBOYS • Fax: 856-686-1601 E-mail: troemner@troemner.com • www.troemner.com 715082-00 (REV 6 - 5/15)
