Summary of Contents for MiPV 013A
- Page 1 Installation and Safety Guide MIPV Leisure Series safety and installation guide for Multiple module photovoltaic systems for Motorhomes & Caravans. Products Codes: MIPV 013A (480W) MIPV 016A (330W)
-
Page 2: Table Of Contents
Technical Specification ..........................5 Installation Safety ............................6 Required Tools ............................... 6 Bonding MIPV module to the roof of a motorhome or a caravan..............7 Preparing the Roof ............................8 Laying the panel ............................9 Installing the Cabling ........................... 11 Position the Entry Gland Cowl ........................ -
Page 3: Introduction
2. Scope This manual is for the installation of MiPV leisure series kits comprising of either three or four MIPV solar modules, a charge controller and ancillaries for installing on a caravan or motorhome. Applicable Products... -
Page 4: Disclaimer Of Liability
Before installing the modules, we recommend you cover the front of the module to prevent any electricity being produced. DO NOT shade part of the MIPV module surface from the sunlight for a long time. A shaded cell may become hot and will cause a drop in generated power and could cause failure DO NOT artificially concentrate sunlight on the module. -
Page 5: Technical Specification
Do NOT stand or step on the MiPV module. Do NOT place or allow hard objects to fall onto MiPV modules Do NOT cause the MiPV module to flex or twist excessively. A bending radius in excess of 225mm can damage the module. -
Page 6: Installation Safety
READ CAREFULLY AND STRICTLY OBSERVE THE ASSEMEBLY INSTRUCTIONS BEFORE STARTING WORK. 9. Installation Safety DO NOT install MiPV modules in wet or windy conditions to avoid risk of personal injury or damage to property. When working at height follow all national guidelines. Always use appropriate safety equipment. -
Page 7: Bonding Mipv Module To The Roof Of A Motorhome Or A Caravan
We suggest the location such that the MiPV module junction boxes are as close as possible to any trunking or service ducting within the vehicle. We would also strongly advise against installing the panel with its leading edge in position A (figure 1) which is the area of maximum aerodynamic uplift/peel force when the vehicle is in motion. -
Page 8: Preparing The Roof
IMPORTANT NOTE: Extreme care should be taken before beginning to lay the module. Once you begin the laying of the module you are committed to its positioning which cannot be later changed. MIPV Installation Manual v2.3.1... -
Page 9: Laying The Panel
Press down firmly using a dry cloth to ensure that the adhesive backing makes full and even contact with the vehicle roof (figure 6) Figure 5 Figure 6 MIPV Installation Manual v2.3.1... - Page 10 Figure 7 Figure 8 MIPV Installation Manual v2.3.1...
-
Page 11: Installing The Cabling
Do not install the module if any components or parts supplied by MiPV are not in good working condition. IMPORTANT NOTE: Do not connect the leads to the MiPV solar module. This must be done later in the installation process (see section 20). -
Page 12: Installation Wiring Diagram For Four Module Series-Parallel System
Electrical installation 16. Installation wiring diagram for four module series-parallel connection systems (Product MIPV 013A only) (*)Fuse (not required for MIPV 013A product) Figure MIPV Installation Manual v2.3.1... -
Page 13: Installation Wiring Diagram For Three Module Parallel Connection System
Electrical installation 17. Installation wiring diagram for three module parallel connection systems (Product MIPV 016A only) (*)Fuse (not required for MIPV 016A product) Figure 10 MIPV Installation Manual v2.3.1... -
Page 14: Installing The Charge Controller
Route the cables from the roof of the vehicle to the location of the charge controller. An in-line fuse is supplied for kits MiPV 010A) this should be connected to the positive (red) connection cable see figure 9. Connect the cables to the correct input terminals (red +ve, black –ve) ensuring the all securing screws are tight. -
Page 15: Connecting The Solar Modules
20. Connecting the solar modules The MiPV solar modules can now be connected to the cables you have installed into the vehicle. The solar modules should be connected together according to the appropriate circuit diagram. For product code: MiPV 013A use... -
Page 16: Accessories
Accessories 22. Accessories Accessory Part Code MiPV Module 1293 * 358 (55W) F11F-055BM MiPV Module 1293 * 674 (110W) F21F-120BM MiPV Module 1293 * 990 (165W) F31F-165BM MiPV Module 2609 * 358 (120W) F13F-120B1 MiPV Module 2609 * 990 (360W) - Page 17 DEESIDE, FLINTSHIRE CH5 2NH WALES, UNITED KINGDOM TELEPHONE: +44 (0) 1244 892069 EMAIL: CUSTOMER.SERVICE@MIPV.CO.UK WEBSITE: WWW.MIPV.CO.UK FOR FURTHER SUPPORT AND GUIDANCE ON INSTALLING MIPV MODULES CONTACT CUSTOMER.SERVICE@MIPV.CO.UK OR TELEPHONE 01244 892069 FOR FREE ADVICE AND GUIDANCE. MIPV Installation Manual v2.3.1...
