Endres TSE 150 Operating Instructions Manual

Rai sed toilet seat
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operati ng Instructions
Rai s ed T oilet Seat
R E F 520 1000
R E F 520 0500
TSE 150
with armrests
without armres ts
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSE 150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Endres TSE 150

  • Page 1 Operati ng Instructions Rai s ed T oilet Seat TSE 150 R E F 520 1000 with armrests R E F 520 0500 without armres ts...

  • Page 2: Table Of Contents

    Table of contents 1. Parts of raised toilet seat..............2 2. Indication ..................4 3. Scope of delivery contents ..............4 4. Mounting ................... 4 5. Height adjustment ................5 6. Assembling lid................... 7 7. Safety instructions................7 8. Maintenance and Care..............7 9.
  • Page 3 clamp cross bars height adjusters / slides locking nuts hygienic recesses from above side front side rear side...

  • Page 4: Indication

    2. Indication The toilet seat enables a higher degree of independence during the use of the toilet by compensating reduced or missing functions of the musculoskeletal system. 3. Scope of delivery contents Contents supplied: § Height adjustable toilet seat § Operating instructions §...

  • Page 5: Height Adjustment

    5. Height adjustment The toilet seat comes readily positioned at the 10 cm height, if a further adjustment is required then proceed as follows. Release the two height adjusters on the rear sides of the toilet seat underneath the armrests by pressing the locking mechanism. Then withdraw the rear height adjusters together with the cross bar that they are attached to.
  • Page 6 height 6,5 cm adjusters / slides 10 cm 13,5 cm cross bar locking nuts clamp Diagram 2 Adjustment cross bar front 6,5 cm height adjusters 10 cm 13,5 cm cross bar...

  • Page 7: Assembling Lid

    6. Assembling lid If necessary, the lid can be removed or changed easily. Therefore open completely (see picture) then the lid can be removed by taking from adapters. If necessary, insert the new lid accordingly from rear side into the adapters adapters and fold it down.

  • Page 8: Technical Data

    Height adjustment 3 steps, 6.5 / 10 / 13.5 cm Material Plastic (PP), white Subject to technical changes. Errors and omissions accepted. ENDRES UK Limited Globe Industrial Park Globe Lane - Stockport DUKINFIELD GB Cheshire SK16 4RE Phone + 44 870 4436044...
