Deltran Battery Tender BTL09A150CW Installation Instructions

IMPORTANT SAFETY INSTRUCTIONS

1) SAVE THESE INSTRUCTIONS
Do not throw away the box or any foam packing until after the installation is
2)
complete.
CAUTIONS
a) Do not immerse in water.
b) Do not short terminals together.
c) Do not use or store the battery near sources of fire or heat.
d) Do not reverse the positive (+) or negative (-) terminals.
e) Do not put the battery into a fire or apply direct heat to it.
f) Do not pierce the battery casing.
g) Do not strike, throw, or subject the battery to severe physical shock.
h) Do not solder directly to the battery terminals.
i) Do not attempt to modify the battery in any way.
j) Do not place the battery in a microwave oven or pressurized container.
k) Do not use the battery if it gives off an odor or generates heat.
l) Do not allow charge voltage in excess of 14.8Volts.
m) The batteries optimal operating range is 0ºC (32ºF) to 45 ºC (113ºF). (See
Usage section, paragraph (f) for cold weather use.
n) Do NOT use lead-acid chargers which employ a high-voltage "anti-
sulfation" routine.
o) Keep batteries away from pets and children.
Fully discharge before disposal.
p)
WARNING
a) Be extra cautious to reduce risk of dropping a metal tool onto battery. It
might spark or short-circuit battery or other electrical parts that may cause
explosion.
b)
Remove personal metal items such as rings, bracelets, necklaces, and
watches when working with any battery. A battery can produce a short-
circuit current high enough to weld a ring or the like to metal, causing a
.
severe burn
c) To reduce risk of battery explosion, follow these instructions and those
published by the manufacturer of any equipment you intend to use in
vicinity of this battery. Review cautionary markings on these products and
on engine.
Deltran Battery Tender
LITHIUM IRON PHOSPHATE
12Volt LiFePO4 BATTERY
Manual P/N 392-0393-R0
1
INSTALLATION INSTRUCTIONS

a) Before installing your new battery there are first a couple of procedures to
perform.
b) The retail box contains a wire harness that will allow you to charge your
battery when not in use and also reset the battery if it should go into one
of the Battery Management System (BMS) fault modes.
c) If you do not install this harness you will not be able to reset the battery.
d) Use the supplied 3mm screw to attach the battery reset button terminal
ring to the top of the battery. The harness can exit either side of the
battery. Choose the side that best suits your configuration.
e) Carefully remove the existing lead-acid battery from your vehicle following
the manufacture's guidelines.
f) Next place the original battery next to your Battery Tender® Lithium
battery to compare the variation in size. The original battery may be the
same width but is longer in length and taller in height. To make up the
difference apply the appropriate amount of the adhesive foam to either the
Lithium battery or the battery box.
FOAM – Add
As Required
2
