Kill Shot CM-HLDR Instructions Manual

Strap-on camera arm

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

General Guidelines

• For use with cameras having 1/4-20 UNC mounting threads.

• It is the user's responsibility to read and follow all instructions.

• Keep these instructions with the product at all times and review before each use.

• It is the responsibility of this product's owner to furnish the instructions to any person that borrows

or purchases the product.

• Inspect the product before use to ensure it is assembled properly and all parts are in safe working

order and free of defects.

• Never modify this product in any way.

• All circumstances cannot be addressed in these instructions. Please use common sense and

practice general safety measures when using this product.

• Parts and/or instructions are subject to change without notice.

Safety

• The camera arm is designed only as a support mount for cameras weighing up to 4 lbs.

• Do NOT use the product for anything other than its intended purpose of supporting a camera.

• Do NOT use this product as a step or climbing aid.

• You must stay connected to the tree with your safety harness at all times when installing the cam-

era arm above ground level.

• Attach camera arm to attachment devices at ground level. Never attempt to make such attachment

at height.

Rev. 062518

Strap-On Camera Arm

Instructions for Part # CM-HLDR

DiscountRamps.com • 1-888-651-3431

Page 1

Table of Contents

Need help?

Do you have a question about the CM-HLDR and is the answer not in the manual?

Questions and answers

Summary of Contents for Kill Shot CM-HLDR

Page 1 Strap-On Camera Arm Instructions for Part # CM-HLDR General Guidelines • For use with cameras having 1/4-20 UNC mounting threads. • It is the user’s responsibility to read and follow all instructions. • Keep these instructions with the product at all times and review before each use.
Page 2 Parts Part Description Quantity Part Description Quantity Head Assembly with Handle Attachment Knuckle Extension Arm Assembly Ratchet Strap Base Assembly Step 1. Remove camera arm handle from head assembly (A) by turning counter-clockwise. Be sure not to lose the 10mm nut that secures the handle to the head assembly. Fig.
Page 3 Step 2. Place attachment knuckle (D) into hole on the head assembly (A) with the head assembly opposite of the camera arm. Replace nut and handle. Turn handle clockwise to tighten. Loosening the handle will allow the head assembly to rotate on the knuckle. Fig.
Page 4 Fig. 3c Fig. 3d Fig. 3e Fig. 3f Step 4. With the button facing upward, depress the button and insert the extension arm assembly (B) into the base (C) until the button seats itself into one of the two drilled adjustment holes in the base. Fig.
Page 5 Step 6. Using the provided ratchet strap (E), snap hook in place making sure that the flat (backside) of the ratchet is against the tree and the strap is not twisted. Wrap strap around tree and snap sec- ond hook into camera arm base. Pull excess strap tight and ratchet until the camera arm base is tight against the tree.
Page 6 Product Warranty and Liability GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of receipt, and will meet the specifications stated at the place of purchase transaction or online at the Dealer’s website, under normal use and service when correctly installed, operated and maintained.
