1)
Miravue VIP-1 Driver Configuration ................................................................................................................................ 2
2)
Setting up Miravue VIP-1 as Expansion Device ............................................................................................................... 5
3)
Miravue VIP-1 Programming Options ............................................................................................................................. 7
4)
The RTI | Miravue VIP-1 Web Interface .......................................................................................................................... 9
a. Accessing the Setup Web Interface ............................................................................................................................ 9
b. HDMI Configuration .................................................................................................................................................. 10
c. Network Configuration ............................................................................................................................................. 11
d. Network Video Streams ............................................................................................................................................ 12
e. Other Settings ........................................................................................................................................................... 12
f. Firmware ................................................................................................................................................................... 13
g. Actions....................................................................................................................................................................... 13
5)
VIP-1 Front Panel Ports ................................................................................................................................................. 14
6)
VIP-1 Rear Panel Ports ................................................................................................................................................... 15
7)
VIP-1 Accessories ........................................................................................................................................................... 16
8)
Distributed vs. Centralized Design ................................................................................................................................ 17
9)
Unicast vs. Multicast ..................................................................................................................................................... 19
10) Frequently Asked Question ........................................................................................................................................... 21
RTI | Miravue VIP-1 Manual
1 |
P a g e
01/2019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RTI Miravue VIP-1
Summary of Contents for RTI Miravue VIP-1
-
Page 1: Table Of Contents
RTI | Miravue VIP-1 Manual Contents Miravue VIP-1 Driver Configuration ..........................2 Setting up Miravue VIP-1 as Expansion Device ....................... 5 Miravue VIP-1 Programming Options ..........................7 The RTI | Miravue VIP-1 Web Interface .......................... 9 a. Accessing the Setup Web Interface ..........................9 b. -
Page 2: Miravue Vip-1 Driver Configuration
1) Miravue VIP-1 Driver Configuration Download the current version of the Miravue driver and documentation on the RTI dealer site. Unzip the contents of the driver to the directory where APEX points to for drivers. This can be changed by clicking the “Options” tab in the top toolbar and selecting “set directories.”... - Page 3 Continue this process adding all the Miravue devices to the project file. Repeat the process to add additional devices, making sure the ”Instance” drop-down field is set to the existing driver. This will continue to increment the Miravue count as you add more Miravue VIP-1’s. P a g e...
- Page 4 RTI | Miravue VIP-1 Manual Once all VIP-1 devices are added, you must configure the driver properties before continuing. Select the Miravue driver from the driver section of the system tree and select “driver properties.” Enter the transceiver count to match the number of Miravue units in your project file. This will open configuration options for all your devices.
-
Page 5: Setting Up Miravue Vip-1 As Expansion Device
RTI | Miravue VIP-1 Manual 2) Setting up Miravue VIP-1 as Expansion Device If Miravue devices are being utilized for IR or RS-232 port routing, you must set them up as expansion devices. Select the processor in the system tree and then “Expansion Devices” in the partition to the right. Next, select “Add Expansion Device”... - Page 6 RTI | Miravue VIP-1 Manual Continue to add expansion devices as needed, repeating the process as described. Miravue devices will now be available as a routable MPIO or RS-232 port when adding devices in the software. P a g e...
-
Page 7: Miravue Vip-1 Programming Options
RTI | Miravue VIP-1 Manual 3) Miravue VIP-1 Programming Options When programming the Miravue driver, there are many macro options available. Select Source From List Each display has scrolling source list capability. This command can be used to select a source from that scrolling last. - Page 8 RTI | Miravue VIP-1 Manual Each Miravue device comes with several variables that can be used to poll a device and provide two-way feedback. Button State / Text Feedback Button State / Reversed and Visible States Object-based Feedback (2-way scrolling lists)
-
Page 9: The Rti | Miravue Vip-1 Web Interface
RTI control system or not. IMPORTANT NOTE: If an RTI control system is used, the VIP-1 settings are configured via the two-way driver in the Integration Designer programming software and will overwrite settings made via the web interface. -
Page 10: Hdmi Configuration
RTI | Miravue VIP-1 Manual Transceiver Info Serial: Product serial number MAC address: Unique network identifier; can be used by a DHCP server to assign a specific IP address Firmware: Software version number Hardware: Hardware version number Important: The serial number, firmware version... -
Page 11: Network Configuration
RTI | Miravue VIP-1 Manual c. Network Configuration Transmit & Receive Interface Select Ethernet (default) to distribute video over a wired network or WiFi to distribute video over WiFi (requires 5Ghz wireless access point). Always choose wired over wireless when practical. -
Page 12: Network Video Streams
Stereo audio out port. Dolby 5.1 audio is downmixed when applicable. *NOTE: This must be configured via the web interface. Serial Port This functionality is only used with non-RTI control systems. 12 | P a g e 01/2019... -
Page 13: Firmware
RTI | Miravue VIP-1 Manual f. Firmware Updates It is recommended that firmware updates are completed via a USB drive, following the instructions included with the firmware file. Via Setup Select the update file using the file browse feature (make sure this file is on the local network). Proceed with the update. -
Page 14: Vip-1 Front Panel Ports
RESET Button power cycles the VIP-1 if pressed and released. IR-OUT Infrared output connects to a standard IR emitter. Used to forward infrared commands over IP from an RTI control system to a device (eg., TV, Blu-ray). RS232 Serial output connects to a single RS232 controlled device with a standard 3.5mm cable (Tip=Rx In, Ring=Tx Out, Sleeve=GND). -
Page 15: Vip-1 Rear Panel Ports
Infrared input for infrared control of the VIP-1 using an infrared receiver (purchased separately). IMPORTANT NOTES: • The VIP-1 IR-IN input is not compatible with IR delivered using a hard-wired cable directly from an RTI control processor. • IR passthrough is not supported. -
Page 16: Vip-1 Accessories
RTI | Miravue VIP-1 Manual Connects to the included 5VDC/2.4 Amp power supply. NOTE: Power may also be supplied to the VIP-1 via the Ethernet - PoE port. This port may be used to pass signals through to another device (e.g., a display). NOTE: This is for low bandwidth applications where control signals are passed through. -
Page 17: Distributed Vs. Centralized Design
RTI | Miravue VIP-1 Manual 8) Distributed vs. Centralized Design In this Distributed Design, a video source and display are connected to a VIP-1 transceiver, and each transceiver is connected to a network switch. One of the benefits of this non-traditional approach is that it requires fewer transceivers compared to a centralized (rack-based) model. - Page 18 RTI | Miravue VIP-1 Manual In this Centralized Design, the video sources are in a rack, each connected to a VIP-1 transceiver. In this configuration, each TV is also connected to a VIP-1. Therefore, this traditional “rack-based” approach requires more transceivers compared to a fully distributed model because each source and each TV use a VIP-1.
-
Page 19: Unicast Vs. Multicast
RTI | Miravue VIP-1 Manual 9) Unicast vs. Multicast Unicast Mode the network contains a copy of each video stream being viewed on a display (e.g., displays do not share source video streams). If a source is not being viewed, there is no stream on the network for that source. - Page 20 RTI | Miravue VIP-1 Manual Multicast Mode the network contains one copy of each video source stream and shares it with every device on the network (whether being viewed or not). Multicast mode is useful for networks with a smaller number of sources to TVs.
-
Page 21: Frequently Asked Question
• Automatically provides stereo downmix with lipsync adjust for distributed audio systems How do I become an RTI | Miravue Authorized Dealer? If you are a qualified integrator/dealer (or distributor), the first step is to visit the RTI – Become a Dealer webpage for information. - Page 22 RTI | Miravue VIP-1 Manual What’s the Difference Between Distributed and Centralized Video Sources? In a distributed source model, both a video source and a video display are connected to each VIP-1 transceiver. The advantage of this approach is that it requires fewer VIP-1 transceivers than a centralized model. In a centralized source model, the video sources are racked, and the video displays are distributed.
- Page 23 The settings that may be adjusted via the web interface are dependent on whether the VIP-1 will be used with an RTI control system or not. IMPORTANT NOTE: If an RTI control system is used, the VIP-1 settings are configured via the two-way driver in the Integration Designer programming software and will overwrite settings made via the web interface.
- Page 24 What about 720p or stereo only Displays? The RTI | Miravue VIP-1 transceiver encodes H.264 up to its highest supported resolution and audio (i.e., 1080p and Dolby 5.1). If the end display cannot support the video resolution or audio format, the stream is downscaled or downmixed accordingly.
- Page 25 How is the VIP-1 Controlled? The VIP-1 can be controlled can be via the RTI control system (via IP, using two-way driver), via on-screen source select (using CEC) or via infrared. If IR is used for control, the built-in infrared receiver on the unit or an infrared receiver may be plugged into the IR-IN input.
