STC SPACE SAVER 30504 Installation Manual

Full motion wall mount for flat panel tvs. low prfile extends from 4.5 to 20.3, fits displays from 30 to 55, supports up to 105 lbs (47.7 kgs)
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation Manual
model # 30504
M o u n t i n g
S y s t e m s
Full Motion Wall Mount
For Flat Panel TVs
Low Pro le Extends from 4.5" to 20.3"
Fits Displays from 30" to 55''
Supports Up to 105 lbs (47.7 kgs)
Systems Trading Corporation
450 7th Avenue, Suite 2809, New York, NY 10123
hone: (212) 239-8230 Toll Free: (800) 293-2923 Email: customerservice@stcny.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPACE SAVER 30504 and is the answer not in the manual?

Questions and answers

Summary of Contents for STC SPACE SAVER 30504

  • Page 1 Installation Manual model # 30504 M o u n t i n g S y s t e m s Full Motion Wall Mount For Flat Panel TVs Low Pro le Extends from 4.5” to 20.3“ Fits Displays from 30” to 55’’ Supports Up to 105 lbs (47.7 kgs) Systems Trading Corporation 450 7th Avenue, Suite 2809, New York, NY 10123...

  • Page 2: Table Of Contents

    BEFORE YOU BEGIN, MAKE SURE YOU CAREFULLY READ AND UNDERSTAND THE INSTRUCTIONS IN THIS MANUAL. This bracket system incorporates a slip on mount design. Our goal is to make this installation easy for you. Please follow the instructions in the order presented in this manual and be sure to observe all warnings and cautions.

  • Page 3: Unpack

    Make certain the following installation hardware and components are included. If any of the parts are missing or damaged please contact STC Customer Care at (800) 293-2923. Parts are not shown actual size. M4 x 16mm screw & washer M5 x 20mm screw &...
  • Page 4 identify Unplug your display before you begin. Invert the display and place it on a soft, padded, at surface. To ensure proper mounting of the brackets to your display, we have provided several sizes of screws and spacers that can be used in combination. Combinations are determined by the display back style (the area surrounding the mounting holes) and the diameter and depth of those holes.
  • Page 5 select CAUTION: When screw is longer than mark, choose a shorter screw. Several lengths have been provided for this reason. curved recessed curved recessed CAUTION: When screw is longer than mark, choose a shorter screw. Several lengths have been provided for this reason. test Gently test all fasteners together, screwing them in by hand to ensure proper t.
  • Page 6 attach Center brackets vertically to back of display. Measure the horizontal width between holes. a = b c = between 3.9 “ (100mm) to 22.5” (575mm) d = between 22.6” (576mm) to maximum 26.3” (668mm) Bracket placement for maximum width d. left right NOTE: The following steps illustrate attaching the brackets for maximum width c.

  • Page 7: Wall Placement

    The hardware included is suitable for mounting to walls made of brick, solid concrete, concrete block or wood studs covered with drywall. If your mounting situation is di erent, please consult a quali ed installer or contact STC Customer Care at (800) 293-2923.
  • Page 8 Failure to observe all safety precautions can result in serious physical injury and/or property damage. Consult a professional installer or call STC Customer Care at (800) 293-2923 if you have any questions.
  • Page 9 Failure to observe all safety precautions can result in serious physical injury and/or property damage. Consult a professional installer or call STC Customer Care at (800) 293-2923 if you have any questions. Do not drill into mortar between bricks or concrete blocks or into loose concrete.

  • Page 10: Secure Wall Plate To Wall

    secure wall plate lag bolt and washer hex key Tighten lag bolts so wall plate is rmly attached. DO NOT OVER TIGHTEN. Over tightening can damage screws and greatly reduce holding power. 9 of 13 www.stcny.com...
  • Page 11 mount Make sure both brackets are rmly tightened to tilt in the center position. Carefully lower display on the front plate of assembly arm extension. Use two or more people when lifting display. Make sure the brackets hook onto top and bottom edges of the front plate.

  • Page 12: Adjust

    Secure both display brackets to bottom of extension arm assembly front secure plate with phillips screw driver. Tighten screws rmly. DO NOT OVER TIGHTEN. Overtightening can damage bolts and greatly reduce holding power. adjust Hold display before loosening screws. Continue to hold until you have tightened the screws again.

  • Page 13: Warranty

    LIFETIME WARRANTY STC warrants that it will replace or repair this item, free of charge, at STC's sole discretion, should it prove defective in materials or workmanship. If a claim is made under this warranty, the mount should be returned, freight prepaid, with the original purchase receipt to your dealer or to a Space Saver distributor.
