Barco DML-1200 User Manual

Barco DML-1200 User Manual

With embedded media player
Hide thumbs Also See for DML-1200:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
DML-1200
User guide
With embedded media player
R9050110
R59770209/02
02/02/2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DML-1200 and is the answer not in the manual?

Questions and answers

Related Manuals for Barco DML-1200

Summary of Contents for Barco DML-1200

  • Page 1 DML-1200 User guide With embedded media player R9050110 R59770209/02 02/02/2009...
  • Page 2 Barco nv Media & Entertainment Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.883.86 E-mail: sales.events@barco.com Visit us at the web: www.barco.com Printed in Belgium...
  • Page 3 GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged.
  • Page 4 Pre-installed media All libraries pre-installed on the system are supplied by Barco. Any queries regarding the use of these should be directed to Barco. Copy- right laws may apply.

  • Page 5: Table Of Contents

    10.6 CTO (Color temperature origin) ..................... 54 R59770209 DML-1200 02/02/2009...
  • Page 6 12.3.14.6 Softlight ....................... . . 97 R59770209 DML-1200 02/02/2009...
  • Page 7 Spare part order info .......................157 R59770209 DML-1200 02/02/2009...
  • Page 8 Table of contents R59770209 DML-1200 02/02/2009...

  • Page 9: Safety

    This will prevent damage to the device due to lightning and AC power-line surges. • Do not guide the power cord over the base unit of the device. Ensure that the power cord cannot make contact with moving head. R59770209 DML-1200 02/02/2009...
  • Page 10 Heat sensitive materials should not be placed in the path of the exhausted air. Leave at least a free safety area of 2 meter (80”) around the projector head. R59770209 DML-1200 02/02/2009...
  • Page 11 Refer all servicing to qualified service personnel. • Fence off a restricted area of at least 3 meters around the projector using an eye-catching fence and “KEEP OUT” signs. This to prevent unauthorized persons coming near the projector during servicing. R59770209 DML-1200 02/02/2009...

  • Page 12: Important Warnings Concerning Dml Flight Cases

    If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replace- ment parts. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.
  • Page 13 Disposal options for mercury-containing lamps • Recycle through a municipal or solid waste district household hazardous waste collection program in accordance with local regulations. • Direct shipment to lamp recycler • Shipment through a hazardous waste transporter R59770209 DML-1200 02/02/2009...
  • Page 14 1. Safety R59770209 DML-1200 02/02/2009...

  • Page 15: General

    Device weight Do not underestimate the weight of one DML-1200, which is about ±75 kg (±166 lb.). Be sure that the table or truss installation on which the device(s) has to be installed is capable of handling five (5) times the complete load of the complete system.
  • Page 16 3. Take off the cover with the wheels. Image 2-2 Open flight case 4. Take out the device by its carrying handles and place it on its foot. Caution: Lift it up with 2 persons while a 3rd person pushes away the flight case. R59770209 DML-1200 02/02/2009...
  • Page 17 2. General Image 2-3 AUTION Never use the head as carrying handle to lift up the DML-1200. For rigged operation 1. Leave the flight case on its wheels and open the 6 locks. Image 2-4 Open flight case 2. Take off the L-shaped cover.

  • Page 18: Projector Air Inlets And Outlets

    Air flow base The DML-1200 has an air inlet at the lens side of the head and an air outlet at the back side of the head. The base has an air inlet at the back side and an air outlet at the right side and left side.

  • Page 19: Physical Installation

    Truss mounting of the DML-1200 Pan and tilt locking AUTION Unlock the tilt and pan lock before operating the DML-1200 ! Tilt lock The projector head can be locked each 45° starting from its packing position (7 lock positions). Image 3-1 Different lock positions To lock the head, turn it in one of the 7 possible lock positions and press the red button on the rotation axis (F).
  • Page 20 To lock the yoke, rotate it in one of the 4 possible positions and then move the handle from the upper position (U) to the lower positions (L). Image 3-4 To unlock the yoke, move the handle from the lower position (L) to the upper position (U). R59770209 DML-1200 02/02/2009...

  • Page 21: Mounting The Dml-1200 Upright

    How to mount To mount the DML-1200 upright, place the device on a sturdy, stable surface that will support more than 75 kg (165.4 lbs). If the surface is above floor height, use safety cables to secure the device to the surface.
  • Page 22 1. Measure the distance, center tube as reference, between the two used support bars of the truss. X mm Image 3-7 2. Push the rigging point downwards and slide it at the same time to its place, according the measured distance. Release the rigging point. R59770209 DML-1200 02/02/2009...
  • Page 23 4. Place all four rigging clamps in open position. 5. Place the device under the truss installation and lower the truss until the support bars of the truss are nearby the rigging clamps mounted on the device. R59770209 DML-1200 02/02/2009...
  • Page 24 Stretch the security cable completely. If necessary, turn the security cable a few times around the truss before closing the con- nection so that the cable is stretched as much as possible. Image 3-11 Mount safety cable 8. Lift up the truss with attached device to the desired height. R59770209 DML-1200 02/02/2009...

  • Page 25: Connections

    Homing the device When the DML-1200 is connected to an appropriately-rated power source, it automatically begins a homing procedure to verify that the major functions of the device are oriented properly. This homing procedure includes movements of the projector head and yoke.

  • Page 26: Input Connections

    G(s) : 1Vpp ±3dB (0,7Vpp G + 0,3Vpp Sync) 75 Ohm termination. B : 0,7Vpp ±3dB 75 Ohm termination. SDI / HD-SDI, specifications • 1 input (BNC), 1 active loop-through output (BNC) • 10 bit/color • SDI: 525/625 interlaced. • Coax (75 Ohm). R59770209 DML-1200 02/02/2009...

  • Page 27: Communication Connections

    HDCP DVI ENTER LMP 1 LMP 2 10 / 100 / 1000 LMP 3 LMP 4 EXIT Image 4-3 Communications DMX512 data in, data out Ethernet connection LCD communication display Function buttons and jog dial USB inputs R59770209 DML-1200 02/02/2009...
  • Page 28 DMX512 standard. You can use the DMX input port (A) to connect a DMX device or lighting console. This way you can control the DML-1200 from that lighting console. The DMX output port (G) can be connected to the next device in the daisy chain. The DMX output port is a passive loop through and is functional even when the device is not powered.
  • Page 29 ON : indicates a warning in the head during operation. A warning allows normal operation, but some hardware in the device does not match the required specifications ON - OFF (blinking): indicates a fatal error. Service is required. OFF : no errors detected R59770209 DML-1200 02/02/2009...

  • Page 30: Linking Dml-1200'S

    DMX linking Therefore, one DMX universe can contain up to 4 DML-1200 devices with a Media Player and up to 10 devices without Media Player. To control a DML-1200 without Media Player, 51 DMX channel are necessary. When the Media Player is available, 128 channels are required.
  • Page 31 4. Connections DMX Universe 2 DMX Universe 1 Ethernet ArtNet Ethernet cable Image 4-5 DMX on Ethernet Alternative setup: DMX Universe 2 DMX Universe 1 ArtNet Ethernet cable Image 4-6 DMX on Ethernet, alternative setup R59770209 DML-1200 02/02/2009...
  • Page 32 4. Connections R59770209 DML-1200 02/02/2009...

  • Page 33: Start Up Of The Adjustment Mode

    Both bottom lines on the display are used to indicate the last error or warning which has occurred. The first line of these two indicates the status, warning or error and the second line gives a description of the warning or error. To see an overview of all warnings and errors, see "Error list", page 151. R59770209 DML-1200 02/02/2009...
  • Page 34 5. Start up of the Adjustment mode R59770209 DML-1200 02/02/2009...

  • Page 35: Input Menu

    2. Turn the jog dial to select Input and press Enter. The input selection menu opens. 3. Turn the jog dial until the second page of the input menu is displayed and turn further to select Auto image alignment and press Enter. R59770209 DML-1200 02/02/2009...

  • Page 36: Reset To Factory Presets

    3. Turn the jog dial until the second page of the input menu is displayed and turn further to select Reset to factory presets and press Enter. A reset is executed. Image 6-7 Image 6-8 Image 6-6 R59770209 DML-1200 02/02/2009...

  • Page 37: Lamp Menu

    These parameters are useful when calling for a service intervention. How to display 1. Press Enter to start up the main menu. 2. Turn the jog dial to select Lamp and press Enter. 3. Turn the jog dial to select Identification. and press Enter. R59770209 DML-1200 02/02/2009...

  • Page 38: Status And Run Time Overview Lamps

    2. Turn the jog dial to select Lamp and press Enter. 3. Turn the jog dial to select Overview and press Enter. The lamp overview menu appears. The status and the run time for each lamp is indicated. Image 7-6 Image 7-5 Image 7-4 R59770209 DML-1200 02/02/2009...

  • Page 39: Control Menu

    Startup What happens When the device is started up, lamps start up and waits until new commands are sent to the device. R59770209 DML-1200 02/02/2009...

  • Page 40: Standby

    What can be done ? Within the DML-1200 a demo run is programmed. When the demo mode is activated, the demo run starts with an interval of x seconds. The number of times the demo run has been started is indicated in Demo cycles.

  • Page 41: Dmx Data

    1. Press Enter to start up the main menu. 2. Turn the jog dial to select Control and press Enter. 3. Turn the jog dial to select DMX data and press Enter. 4. Turn the jog dial to select a DMX channel and press Enter. R59770209 DML-1200 02/02/2009...

  • Page 42: Dmx Address

    What can be done ? One DMX universe can contain up to 4 DML-1200 devices with a Media Player and up to 10 devices without Media Player. If you have more devices to control, group them in different DMX universes.

  • Page 43: Media Player On - Off

    3. Turn the jog dial until the second page of the control menu is displayed and turn further to select LCD contrast and press Enter. 4. Turn the jog dial to adjust the local contrast and press Enter. R59770209 DML-1200 02/02/2009...

  • Page 44: Pan And Tilt Encoder

    8.10 Pan and Tilt encoder What is possible ? When the DML-1200 is panned or tilted due to an external intervention, e.g. a push, it can always return to its original position when pan and or tilt encoder is enabled.

  • Page 45: Network

    3. Turn the jog dial until the second page of the control menu is displayed and turn further to select Network and press Enter. 4. Turn the jog dial to select the desired network setting, DHCP, Art-Net or preset. Image 8-29 Image 8-30 Image 8-28 R59770209 DML-1200 02/02/2009...
  • Page 46 8. Control menu R59770209 DML-1200 02/02/2009...

  • Page 47: Service Menu

    Installed software package How to consult 1. Press Enter to start up the main menu. 2. Turn the jog dial to select Service and press Enter. 3. Turn the jog dial to select Identification and press Enter R59770209 DML-1200 02/02/2009...

  • Page 48: Diagnosis

    The first page of the version table is displayed. As there are more items than space available on the LCD, when turning the jog dial further than the last item a new page will be displayed. Image 9-6 Image 9-5 Image 9-4 R59770209 DML-1200 02/02/2009...

  • Page 49: Voltages

    1. Press Enter to start up the main menu. 2. Turn the jog dial to select Service and press Enter. 3. Turn the jog dial to select Diagnosis and press Enter. 4. Turn the jog dial to select Temperatures and press Enter. R59770209 DML-1200 02/02/2009...

  • Page 50: Fan Speeds

    The first page of the fan speeds table is displayed. As there are more items than space available on the LCD, when turning the jog dial further than the last item a new page will be displayed. Image 9-18 Image 9-17 Image 9-16 R59770209 DML-1200 02/02/2009...

  • Page 51: Device Status

    A full logging can be requested since the device is electrically connected. This logging contains info lines, warnings and errors. An info, warning or error is always displayed in two lines. The structure of the logging is as follow: R59770209 DML-1200 02/02/2009...

  • Page 52: Service Patterns

    The first page of the error logging table is displayed. If there are more error than space available on the LCD, when turning the jog dial further than the last error a new page will be displayed. Image 9-26 Image 9-25 Image 9-24 Image 9-27 Service patterns What is possible ? Different patterns are available for service purposes. R59770209 DML-1200 02/02/2009...

  • Page 53: Calibration

    The index delay value should be adjusted so that the phase of the color wheel is correctly aligned. When correctly align a mono- chrome red image e.g. will be correctly displayed. When there is a misalignment, this image will show color distortion (discoloration) at the top and the bottom of the image. This setting is normally factory aligned. R59770209 DML-1200 02/02/2009...

  • Page 54: Aperture Calibration

    4. Turn the jog dial over the last item to open the second page. 5. Turn the jog dial to select Aperture cal and press Enter. 6. Turn the jog dial to change the current value and press Enter. R59770209 DML-1200 02/02/2009...

  • Page 55: Device Calibration

    4. Turn the jog dial to select an item or turn the jog dial over the last item to open the second menu and select an item and press Enter. 5. Turn the jog dial to change the current value and press Enter. Image 9-40 Image 9-39 Image 9-41 R59770209 DML-1200 02/02/2009...
  • Page 56 9. Service menu R59770209 DML-1200 02/02/2009...

  • Page 57: Moving Light Control Via Dmx

    0 - 255 128 Changes from close to distant focus 10.4 Shutter - Strobe Channel 8 Value Default Action 0 - 31 Shutter open 32 - 47 Strobe from slow to fast 48 - 255 For future expansion R59770209 DML-1200 02/02/2009...

  • Page 58: Cyan - Magenta - Yellow

    Adjustments are done between 3000°K (DMX value zero) and 6200°K (DMX value 255).. 10.7 Mode selection About mode selection The DML-1200 can be used in: • Light mode : circular light beam that can change in color (monochrome video). •...

  • Page 59: Iris

    48 - 63 Homing without pan and tilt 64 - 79 Homing, pan and tilt only 80 - 95 Homing CMY only 96 - 127 Lamp on 128 - 159 Lamp off 160 - 255 For future expansion R59770209 DML-1200 02/02/2009...
  • Page 60 10. Moving light control via DMX R59770209 DML-1200 02/02/2009...

  • Page 61: Image Control Via Dmx

    Channel 19 adjusts the saturation between 0 and 100% when sending a value between 0 and 255. 11.4 Orientation Channel 20 Value Default Action 0 - 31 Normal 32 - 63 Mirror 64 - 95 Flip 96 -127 Flip + Mirror 128 - 255 For future expansion R59770209 DML-1200 02/02/2009...

  • Page 62: Blanking

    Image 11-2 Blanking adjustment Top blanking Bottom blanking Left blanking Right blanking Channels Channel Description Value Default Action Blanking left Coarse 0 - 255 0 Adjust the left blanking 0 - 255 0 Blanking left Fine R59770209 DML-1200 02/02/2009...

  • Page 63: Soft Edge

    Image warping is the process of digitally manipulating an image to compensate for the distortion of the screen. Consequently, it can also be used to generate an image with irregular shape. While an image can be transformed in various ways, pure warping doesn’t affect the colors. Some examples of warped images, using the warp geometry settings: R59770209 DML-1200 02/02/2009...
  • Page 64 Load warp file 14 120 - 127 Load warp file 15 128 - 135 Load warp parameters 136 - 247 For future expansion 248 - 255 Warp enabled Channel 36 and 37 Warp parameters. Reserved for future expansion. R59770209 DML-1200 02/02/2009...

  • Page 65: Embedded Media Player

    All images and clips used by the media player are stored in banks. A bank is ’virtual folder’ containing clips and stills. Each bank can contain up to 256 clips or stills. The DML-1200 can contain 256 banks where bank 0 and bank 1 are pre-loaded banks. All other banks are user defined. Use Barco’s MediaManager to upload your own clips and stills.

  • Page 66: In Frame - Out Frame

    Any change in DMX values for OUT frame will reduce the length of effective playing part of the clip. Situation C: Clip duration is higher that 43 minutes 41.439 seconds. OUT frame start point (DMX values 0 for both channels) is somewhere inside the clip. The complete clip cannot be played. R59770209 DML-1200 02/02/2009...

  • Page 67: Image Transition

    Shear flip 38 - 41 Shutter 42 - 45 Spherical Zoom 46 - 49 Top to bottom 50 - 53 Zoom 54 - 57 SuperBall 1 58 - 61 SuperBall 2 62 - 255 For future expansion R59770209 DML-1200 02/02/2009...

  • Page 68: Playback Mode And Speed

    Adjusting an object’s opacity allows one object to “show through” another. You can adjust the opacity of an individual object from completely transparent to full opacity using this parameter. Increase opacity from not visible at a value of zero to full opacity at a value of 255. Image 12-2 Not transparent In between Fully transparent R59770209 DML-1200 02/02/2009...

  • Page 69: Contrast

    The X parameter moves the object along the X-axis. The midpoint of the DMX value range centers the image on the X-axis. Values below the midpoint moves the object to the left, values higher than the midpoint moves the object to the right. Default DMX value : 128 = image centered R59770209 DML-1200 02/02/2009...

  • Page 70: Aspect Ratio

    Coarse adjustment, Layer 1, channel 94- Layer 2, channel 121 Value Default Action 0- 127 rotated image between -180° and 180° (indexed position) 127 - 192 continuous rotation from slow to fast in counter clock wise direction R59770209 DML-1200 02/02/2009...

  • Page 71: Image Blur

    Effect selection Value Default Action 0 - 1 no effect 12.3.13.2 Radial blur Overview Radial blur uses repetitions of the source image to achieve a rotary blur effect. The radial blur effect is determined by 3 parameter. R59770209 DML-1200 02/02/2009...

  • Page 72: Motion Blur

    Motion blur applies a moving blur effect that will leave outlines of the animation within a clip. The motion blur effect is determined by one parameter, the amount of blur. Image 12-6 Original image Motion blur level applied. Effect selection Value Default Action 6 - 9 motion blur R59770209 DML-1200 02/02/2009...

  • Page 73: Color Trafo

    The source image is repeated over and over similar to a multi-monitor wall. The size and aspect ratio of the repeat can be defined with parameter P2 and P3. P1 defines the effect level as a ’glass wall’ effect. R59770209 DML-1200 02/02/2009...

  • Page 74: Inverted Lumakey

    The light areas of the image becomes transparent starting from certain threshold level. The softness of the cut-off is determined with the third parameter. Image 12-9 Original image P1 = 127 P2 = 127 P3 = 0 R59770209 DML-1200 02/02/2009...

  • Page 75: Shifter

    P2 = 255, image shift in X direction. Scrolling with a shifted image. P3 = 0 Shift level applied P2 = 255 P3 = 255 Effect selection Value Default Action 22 - 25 Shifter Effect parameters Parame- Value Action 0 - 255 Effect level, shift speed R59770209 DML-1200 02/02/2009...

  • Page 76: Chromakey

    0 - 255 Tolerance, range (tolerance) of selected key color P2 and P3 have no effect on the image when P1 equals 0. 12.3.13.9 Scroller Overview The layer continually scrolls across, with individual controls for direction across X and Y planes and speed. R59770209 DML-1200 02/02/2009...

  • Page 77: Color Studio

    This effect allows to shift colors around the spectrum with additional brightness control Level adjustment (parameter 1) which is a brightness control has only effect when one of both other parameters are higher than zero (0). Image 12-13 R59770209 DML-1200 02/02/2009...

  • Page 78: Neon

    P1 = 255 P2 = 0, width P1 = 255 P2 = 255, width Effect selection Value Default Action 38 - 41 Neon Effect parameters Parame- Value Action 0 - 255 Effect level 0 - 255 Effect width R59770209 DML-1200 02/02/2009...

  • Page 79: Ctbo

    This color effect takes the image and desaturates the original colors before allowing the user to apply their own choice of tones for the high and low tones. This allows to select a two color scheme and have all your content fit within those colors. R59770209 DML-1200 02/02/2009...

  • Page 80: Palette

    P2 and P3 have no effect on the image when P1 equals 0. 12.3.13.14 Palette Overview This effect allows to shift each of the individual colors around the spectrum. Image 12-17 Original image P1 = 127 P2 and P3 = 0 R59770209 DML-1200 02/02/2009...

  • Page 81: Bloom

    P2 = 127, a white glow is added to the outlines Effect selection Value Default Action 54 - 57 Bloom Effect parameters Parame- Value Action 0 - 255 Effect level, adjusts the brightness of the image 0 - 255 Bloom blur, amount of blur in the image. R59770209 DML-1200 02/02/2009...

  • Page 82: Interlace

    0 - 255 Saturation, saturation of the stripes, more original image visible P2 and P3 have no effect on the image when P1 equals 0. 12.3.13.17 Noise Overview This effect creates a distorted pixilated effect with controls for grain size, frequency and color. Image 12-20 R59770209 DML-1200 02/02/2009...

  • Page 83: Rings

    Effect selection Value Default Action 66 - 69 Rings Effect parameters Parame- Value Action 0 - 255 Effect level, determines the shift between the rings 0 - 255 Rings, defines the number of rings visible in the image R59770209 DML-1200 02/02/2009...

  • Page 84: Cubestyle

    0 - 255 Size, cube size 0 - 255 Speed, speed of the moving cubes P2 and P3 have no effect on the image when P1 equals 0. 12.3.13.20 LED Overview This effect creates the look of a LED wall. R59770209 DML-1200 02/02/2009...

  • Page 85: Pixetlate

    P2 and P3 have no effect on the image when P1 equals 0. 12.3.13.21 Pixetlate Overview This effect introduces visible pixels in the image. Image 12-24 Original image P1 = 128 P2 = 128 P1 = 255 P2 = 128 P1 = 128 P2 = 255 R59770209 DML-1200 02/02/2009...

  • Page 86: Halftone

    0 - 255 Effect level, brightness of grid. 0 - 255 Size, size of print grid 0 - 255 Angle, determines the angle of the color dots. P2 and P3 have no effect on the image when P1 equals 0. R59770209 DML-1200 02/02/2009...

  • Page 87: Plasma

    This effect distorts the image into a pattern similar to the petals of a flower. Image 12-27 Original image P1 = 128 P2 = 128 P1 = 128 P2 = 255 P1 = 255 P2 = 255 R59770209 DML-1200 02/02/2009...

  • Page 88: Flip

    P2 = between 64 and 126 P3 = 0 P1 = 128 P2 = 0 P3 = between 1 and 63 P1 = 128 P2 = 0 P3 = between 64 and 128 Effect selection Value Default Action 94 - 97 Flip R59770209 DML-1200 02/02/2009...

  • Page 89: Rotozoom

    98 - 101 Rotozoom Effect parameters Parame- Value Action 0 - 127 Circular zoom out. From normal image to zoomed out image with extra repetitions. 128 - Circular zoom in. From repeated image to a normal image. R59770209 DML-1200 02/02/2009...

  • Page 90: Glass

    Parame- Value Action 0 - 255 Effect level 0 - 255 Distortion level P2 has no effect when P1 equals 0. 12.3.13.28 Aqua Overview This effect simulates distortions created by ripples on a water surface. Image 12-31 R59770209 DML-1200 02/02/2009...

  • Page 91: Tunnel

    P2 = 0 P3 = 0 P1 = 127 P2 = 127 P3 = 0 P1 = 127 P2 = 127 P3 = 255, camera speed almost not visible Effect selection Value Default Action 110 - 113 Tunnel R59770209 DML-1200 02/02/2009...

  • Page 92: Planes

    0 - 255 Wip, creates a wip effect of the image on the planes 0 - 255 Distortion, zoom out of the image on the planes. A repetition of the image happens. P2 and P3 have no effect when P1 equals 0. R59770209 DML-1200 02/02/2009...

  • Page 93: Fluid Distortion

    P2 and P3 have no effect when P1 equals 0. 12.3.13.32 Alphabet Overview This effect introduces characters all over the image. Image 12-35 Original image P1 = 127 P2 = 127 P3 = 127 P1 = 127 P2 = 255 P3 = 127 R59770209 DML-1200 02/02/2009...

  • Page 94: Ripple

    0 - 126 Number of waves from inside to the outside No waves, image stands still 128 - Number of waves from the outside to the inside P2 and P3 have no effect when P1 equals 0. P1 has no effect when P2 equals 0 R59770209 DML-1200 02/02/2009...

  • Page 95: Wave

    This effect lets jump the image randomly in the x and y plane with defined offset and rotation, speed and zoom. Image 12-38 Original image P1 = 255 P2 = 0 P3 = 0 P1 = 255 P2 = 0 P3 = 255 R59770209 DML-1200 02/02/2009...

  • Page 96: Stripes

    0 - 255 Effect level. Sets the transparency of the strips. 0 - 255 Frequency of the randomization. 0 - 255 Scale. Sets the size (width) of the stripes. P2 and P3 have no effect when P1 equals 0. R59770209 DML-1200 02/02/2009...

  • Page 97: Infinite Zoom

    This effect continually zooms the image from a larger image to its original size. Both directions are possible, from out to in or from in to out. Image 12-41 Original image P1 = Brightness set on certain value P2 = zoom speed and direction value set Effect selection Value Default Action 146 - 149 Infinity R59770209 DML-1200 02/02/2009...

  • Page 98: Blinder

    The combination modes explained in the next topics use two fixed images where possible. By switching the combination mode of layer 2 you get the results. The Matte layer is set to Color with DMX parameter values all to zero (0) (Matte layer is black). Layer interaction Layers are structured as follow: R59770209 DML-1200 02/02/2009...

  • Page 99: Add

    Higher pixels values represent lighter colors, adding layers with overlapping pixels lightens the image. Black areas in both layers remain black. White in either layer results in white. Image 12-44 Combination mode selection Value Default Action 0 - 7 Additive dissolve R59770209 DML-1200 02/02/2009...

  • Page 100: Sub

    When using ’Lighten’, the black parts of the upper layer disappear and anything brighter than black has the potential of lightening the underlying image. Lighten mode compares the active layer to the underlying image only allowing those areas that are lighter than the underlying image to show up. R59770209 DML-1200 02/02/2009...

  • Page 101: Softlight

    Depending on the image, soft ligth can also be used to produce soft shadows and highlights. Image 12-50 Image 12-51 Combination mode selection Value Default Action 56 - 71 Soft light 12.3.14.7 Softlight inverse Overview The same as soft light but just more intense. R59770209 DML-1200 02/02/2009...

  • Page 102: Hardlight

    If the colors being applied are lighter than mid gray, screen mode (lightens) is applied. If the colors being applied are darker than middle gray, multiply mode (darkens) is applied. Image 12-54 Image 12-55 Combination mode selection Value Default Action 88 - 103 Hard light R59770209 DML-1200 02/02/2009...

  • Page 103: Overlay

    Therefore, blending with white inverts the color values (the color value is subtracted from 100% and gives the inverse color). Blending with black makes no changes as you subtract 0 from the color value. Combination mode difference changes the colors and not the brightness. Image 12-58 Image 12-59 R59770209 DML-1200 02/02/2009...

  • Page 104: Multiply

    Screen mode is used for highlighting, and making the layer appear lighter. Since highlights cannot be shown with black, no effect will appear by applying the Screen mode to an entirely black layer, or part of a layer. Image 12-62 R59770209 DML-1200 02/02/2009...

  • Page 105: Opaque

    Sprite works very similar to Opaque. It fully covers the underneath layer when zoom is 100% or more. When re-sizing the layer using the layer zoom to a value less than 100% then the underlying layer is revealed. This can be used to create a window in a window. R59770209 DML-1200 02/02/2009...

  • Page 106: Luminance Key

    The value of parameter 1 determines the threshold at which the luminance key works. This is useful for removing black surrounds from images and video clips. Image 12-68 Image 12-69 Combination mode selection Value Default Action 200 - 215 Luminance key R59770209 DML-1200 02/02/2009...

  • Page 107: Matte

    Speed Size Color (R+C) 26 - 29 Interference Retro2 Speed Size Color (R+C) 30 - 33 Interference (R+R) Speed Size Color 34 - 37 Interference Retro Speed Size Color (R+R) 2. C = concentric, R = radial R59770209 DML-1200 02/02/2009...

  • Page 108: Color

    A circular white ring pattern generated internally where the squeeze factor for the X and the Y direction can be adapted. The roll out determines a zoom effect of the rings When adding the ring pattern with layer 1, the following result can be obtained: Image 12-70 Together with layer 1 and the combination mode Add: R59770209 DML-1200 02/02/2009...

  • Page 109: Chess

    A white moving chessboard pattern is generate (framework of boxes). The number of vertical and horizontal bars can be selected with parameter P1 and P2. The amplitude of the moving bars can be determined by parameter P3 (zoom function for the boxes). Image 12-72 Together with layer 1 and the combination mode Add: Image 12-73 R59770209 DML-1200 02/02/2009...

  • Page 110: Interference (C+C)

    P1. The size is determined by parameter P2. The color is determined by parameter P3. Image 12-74 Image 12-75 Selection Value Default Action 10 - 13 Interference Selection parameters Parame- Value Action 0 - 255 Speed 0 - 255 Size 0 - 255 Color R59770209 DML-1200 02/02/2009...

  • Page 111: Interferences, Retro (C+C)

    Selection parameters Parame- Value Action 0 - 255 Speed 0 - 255 Red1 0 - 255 Green1 12.3.15.7 Interferences (R+C) Overview Generates both a set of concentric swirling rings and a radial fan that swirl around the screen. R59770209 DML-1200 02/02/2009...

  • Page 112: Interference, Retro (R+C)

    0 - 255 Speed 0 - 255 Size 0 - 255 Color 12.3.15.8 Interference, Retro (R+C) Overview Creates a tunnels like effect that zooms in and generates a swirling flower effect that move around the screen randomly. Image 12-80 R59770209 DML-1200 02/02/2009...

  • Page 113: Interference, Retro2 (R+C)

    0 - 255 Size 0 - 255 Color 12.3.15.9 Interference, Retro2 (R+C) Overview Creates a tunnels like effect that zooms in and generates a swirling flower effect that move around the screen randomly. Image 12-82 Image 12-83 R59770209 DML-1200 02/02/2009...

  • Page 114: Interference (R+R)

    Creates two swirling radial fans that move around the screen. Image 12-84 Image 12-85 Selection Value Default Action 30 - 33 Interference (R+R) Selection parameters Parame- Value Action 0 - 255 Speed 0 - 255 Size 0 - 255 Color R59770209 DML-1200 02/02/2009...

  • Page 115: Interference Retro (R+R)

    Interference Retro (R+R) Selection parameters Parame- Value Action 0 - 255 Speed 0 - 255 Size 0 - 255 Color 12.3.15.12 Clouds Overview Generates darker or lighter moving clouds which are scalable to create a cloudy overlay. R59770209 DML-1200 02/02/2009...

  • Page 116: Flowers

    Generates a multi flower pattern. Each flower in the pattern can rotate clockwise or counter clockwise. Neighbor flower are turning in opposite direction. The flowers can be zoomed in or out and the color can be changed. Image 12-90 R59770209 DML-1200 02/02/2009...

  • Page 117: Fog

    128 - Rotation speed, direction 2 0 - 255 Softness 0 - 255 Scale 12.3.15.14 Fog Overview Generates a blurred cloudy fog with lighter and darker parts which can move randomly over the image. Image 12-92 Image 12-93 R59770209 DML-1200 02/02/2009...

  • Page 118: Rain

    Generates a rain pattern which moves from top to bottom. The density of the raindrop and the falling angle is adjustable. Image 12-94 Image 12-95 Selection Value Default Action 50 - 53 Rain Selection parameters Parame- Value Action 0 - 255 Density 0 - 255 Angle 0 - 255 Speed R59770209 DML-1200 02/02/2009...

  • Page 119: Starfield

    Stand still 128 - Speed, moving from middle to outside 0 - 255 Brightness 12.3.15.17 Gradient Overview Generates a top to bottom or bottom to top moving, gradually changing pattern. The color and the speed is adjustable. R59770209 DML-1200 02/02/2009...

  • Page 120: Warp Selection And Warp Transition

    A mask is an overlay pattern on the master layer to cover some parts of the image or to create special effects. Different masks are available and selectable on channel 58. The size, the indexed position (rotation) and the aspect ratio are con- trollable via channels 59, 60 and 61. One example : R59770209 DML-1200 02/02/2009...
  • Page 121 Default Action 0 - 3 Open (no masking) 4 - 7 Circular 8 - 11 polygon with 16-sided 12 - 15 polygon 12-sided 16 - 19 octagon (shape with 8 sides) 20 - 23 hexagon (shape with 6-sided) R59770209 DML-1200 02/02/2009...

  • Page 122: Master Effects

    Overview When projecting onto screens from non-perpendicular positions, the projected image will be distorted. The 8 controls, 2 per corner (channel 67 up to channel 74) allow to correct the keystone effect applied on the overall image. R59770209 DML-1200 02/02/2009...
  • Page 123 0 - 255 Corner 2 adjustment Y direction 0 - 255 Corner 3 adjustment X direction 0 - 255 Corner 3 adjustment Y direction 0 - 255 Corner 4 adjustment X direction 0 - 255 Corner 4 adjustment Y direction R59770209 DML-1200 02/02/2009...
  • Page 124 12. Embedded Media Player R59770209 DML-1200 02/02/2009...

  • Page 125: Maintenance

    Do not use liquid cleaners on the cloth as doing so will contaminate the cloth. Other lenses can also be cleaned safely with this Toraysee cloth. 13.2 Cleaning the exterior of the DML-1200 How to clean the exterior 1. Unplug the power cord.
  • Page 126 Locking head Locking button Lens side 2. Loosen both captive screws. Image 13-2 Captive screws top cover 3. Gently lift up the top cover and press on the indicated part until the arm of the cover is fixed. R59770209 DML-1200 02/02/2009...
  • Page 127 When the white indication line is in the service area, then the reservoir has to be topped-up again. To top-up the reservoir, see chapter "14. Servicing", "Top-up the reservoir with cooling liquid", page 134 When the white indication is in the good area, no corrective action should be taken. Close the top cover and fasten both captive screws. R59770209 DML-1200 02/02/2009...
  • Page 128 13. Maintenance R59770209 DML-1200 02/02/2009...

  • Page 129: Servicing

    Mounting a new lamp unit • Top-up the reservoir with cooling liquid AUTION All HEPA filters of the DML-1200 must be replaced on a regular basis, depending on the environ- ment conditions of the device. 14.1 Removal of the front cover Necessary tools...

  • Page 130: Opening The Top Cover On The Lamp Units Side

    14.2 Opening the top cover on the lamp units side Necessary tools Flat screwdriver How to open 1. Stand on the side of the locking buttons and turn the head so that the lens points to the right. R59770209 DML-1200 02/02/2009...
  • Page 131 Image 14-3 Filter location Locking of the head Lens side The upper cover can now be opened. 2. Lock the head. 3. Loosen both captive screws. Image 14-4 Captive screws top cover 4. Lift up the top cover. R59770209 DML-1200 02/02/2009...

  • Page 132: Replacement Of The Dust Filters On The Front Side

    2. Remove the front cover, see "Removal of the front cover", page 125. 3. Remove the HEPA filter on the front side by pulling the spring clamp (A) on the upper side away from the filter and then pivot the filter a little (B) and take it out (C). R59770209 DML-1200 02/02/2009...

  • Page 133: Replacement Of The Dust Filter At The Inside Of The Head

    1. Unplug the power cord from the wall outlet. 2. Open the top cover on the lamp units side, see "Opening the top cover on the lamp units side", page 126. 3. Pull out the HEPA filter. R59770209 DML-1200 02/02/2009...

  • Page 134: Replacement Of The Dust Filter In The Base

    14.5 Replacement of the dust filter in the base Necessary tools Flat screwdriver Necessary parts New HEPA filter How to replace 1. Loosen the 4 captive screws. Image 14-8 Captive screws 2. Take off the side panel. R59770209 DML-1200 02/02/2009...

  • Page 135: Removal Of A Lamp Unit

    The device head contains 4 lamps, each of them in a separate lamp house. Each lamp can be individually replaced by a spare lamp. Each lamp position has a number. That number is also used in the software to identify the parameters of the corresponding lamp. R59770209 DML-1200 02/02/2009...
  • Page 136 2. Open the top cover on the lamp units side, see "Opening the top cover on the lamp units side", page 126. 3. Unplug the cable of the lamp which must be removed. Image 14-12 Lamp cables, connection 4. Pull up the fixation handle and rotate it fully upwards. R59770209 DML-1200 02/02/2009...

  • Page 137: Mounting A New Lamp Unit

    14.7 Mounting a new lamp unit About the lamp unit All four lamp units are equal. A spare lamp can be inserted in any position without problems. ARNING This procedure may only be performed by qualified technical service personnel. R59770209 DML-1200 02/02/2009...

  • Page 138: Top-Up The Reservoir With Cooling Liquid

    14.8 Top-up the reservoir with cooling liquid Access to the reservoir 1. Unplug the device from the power outlet. 2. Standing at the tilt lock side, turn the head horizontally until the lens is pointing to the left. R59770209 DML-1200 02/02/2009...
  • Page 139 Locking button Lens side 3. Loosen both captive screws. Image 14-17 Captive screws top cover 4. Gently lift up the top cover and press on the indicated part until the arm of the cover is fixed. Image 14-18 R59770209 DML-1200 02/02/2009...
  • Page 140 Note: Be careful not to kink the tubing. If necessary, remove the cable tie around the tubing and pull on the tubes while rotating the reservoir (2 on image 14-20). 4. Turn off the main lid on top of the reservoir (A). R59770209 DML-1200 02/02/2009...
  • Page 141 9. Turn out the third lid using the back of the main lid. Image 14-23 Remove third lid 10.Top-up the reservoir with cooling liquid until the level is somewhat higher than the hole in the reservoir. Image 14-24 Top-up reservoir R59770209 DML-1200 02/02/2009...
  • Page 142 15.Pressurize the circuit by turning the bolt to the left until there is 2 cm free threat between the bolt and the bottom of the reservoir (the white indication line should be in the good area). 16.Mount the reservoir holder and turn in both screws. 17.Close the projector cover. R59770209 DML-1200 02/02/2009...

  • Page 143: Dmx Chart

    Homing without pan and tilt 64 - 79 Homing, pan and tilt only 80 - 95 Homing CMY only 96 - 127 Lamp on 128 - 159 Lamp off 160 - 255 For future expansion 3. x indicates XFade R59770209 DML-1200 02/02/2009...

  • Page 144: Dmx Chart, Image

    0 - 255 Adjust the soft edge bottom side bottom Video function 0 - 7 Disabled select 8 - 255 For future expansion Video parameter 0 - 255 For future expansion Coarse Video parameter 0 - 255 Fine R59770209 DML-1200 02/02/2009...
  • Page 145 For future expansion For future expansion For future expansion For future expansion For future expansion For future expansion For future expansion For future expansion For future expansion For future expansion For future expansion For future expansion R59770209 DML-1200 02/02/2009...

  • Page 146: Dmx Chart, Emp

    62 - 255 Future expansion Matte layer P1 Matte layer P2 Matte layer P3 Warp selection 0 - 1 Warp 0 2 - 5 Warp 1 6 - 9 Warp 2 10 - 13 Warp 3 Warp x Warp transition R59770209 DML-1200 02/02/2009...
  • Page 147 50 - 53 Palette Level Green 54 - 57 Bloom Level Bloom 58 - 61 Interlace Level Stripes Saturation 62 - 65 Noise Level Frequency Grain 66 - 69 Rings Level Rings 70 - 73 CubeStyle Level Size SpeedB R59770209 DML-1200 02/02/2009...
  • Page 148 76 103 Clip select 0 - 255 Clip selection within a bank 77 104 IN Frame 0 - 255 Counting from beginning of clip Coarse 78 105 IN Frame Fine 0 - 255 Counting from selected coarse point R59770209 DML-1200 02/02/2009...
  • Page 149 128 = image fills 100% zoom) 91 118 Image X 0 - 255 128 = centered position 92 119 Image Y 0 - 255 128 = centered position 93 120 Aspect Ratio 0 - 255 128 = 1:1 R59770209 DML-1200 02/02/2009...
  • Page 150 Speed camera 114 - 117 Planes Level Distplanes 118 - 121 Fluid Level Speed A Speed B Distortion 122 - 125 Alphabet Level Zoom Digits 126 - 129 Rimple Level Numwaves Speed 130 - 133 Wave Level Wave R59770209 DML-1200 02/02/2009...
  • Page 151 104 - 119 Overlay 120 - 135 Difference 136 - 151 Multiply 152 - 167 Screen 168 - 183 Opaque 184 - 199 Sprite 208 - 215 Luminance key 216 - 231 Matte 232 - 255 For future expansion R59770209 DML-1200 02/02/2009...
  • Page 152 A. DMX chart R59770209 DML-1200 02/02/2009...

  • Page 153: Dimensions

    B. Dimensions B. DIMENSIONS Overview • Dimensions of the DML-1200 • Dimensions flight case B.1 Dimensions of the DML-1200 Dimensions 209,25 109,25 109,25 M10 (8x) M10 (4x) 469,9 Image B-1 Dimensions given in millimeters R59770209 DML-1200 02/02/2009...

  • Page 154: Dimensions Flight Case

    B. Dimensions Image B-2 Dimensions, rotation B.2 Dimensions flight case Dimensions Image B-3 Dimensions in millimeters R59770209 DML-1200 02/02/2009...

  • Page 155: Troubleshooting

    Frmt white peaking failed If problem persists, call a qualified service technician DMD temp low (<10°C) Warning Turning on the lamp(s) will heat up the DMD DMD temp low (≤10°C) Error Take measurements to increase the ambient temperature R59770209 DML-1200 02/02/2009...
  • Page 156 Fan lamp3 front high Warning/Error If problem persists, call a qualified service technician Fan lamp4 front low Warning/Error If problem persists, call a qualified service technician Fan lamp4 front high Warning/Error If problem persists, call a qualified service technician R59770209 DML-1200 02/02/2009...
  • Page 157 If problem persists, call a qualified service technician FCB monitoring Warning If problem persists, call a qualified service technician Housing switch open Warning/Error Close housing completely. If problem persists, call a qualified service technician Undefined Warning/Error If problem persists, call a qualified service technician R59770209 DML-1200 02/02/2009...
  • Page 158 C. Troubleshooting R59770209 DML-1200 02/02/2009...

  • Page 159: Specifications

    D. Specifications D. SPECIFICATIONS D.1 Specifications of the DML-1200 Overview AC power 200 - 240 V, 10 A, 50-60 Hz, input via 2m cable without connector Blanking horizontal & vertical, controlled over DMX Color change time 0.3 second, or as timed by control console Color Reproduction System substractive color mix (cyan, magenta, yellow) with dichroic filters...
  • Page 160 D. Specifications R59770209 DML-1200 02/02/2009...

  • Page 161: Order Info

    This list contains only customer serviceable spare parts. Description Order info R98610206 Dust filter kit, 6 pack R986102012 Dust filter kit, 12 pack R9861030 Lamp kit, single lamp R9861040 Lamp kit, two lamps R9861050 Lamp kit, four lamps R59770209 DML-1200 02/02/2009...
  • Page 162 E. Order info R59770209 DML-1200 02/02/2009...
  • Page 163 Revision Sheet Barco nv Media & Entertainment Division/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70, Fax: +32 56.36.88.24 E-mail: service.mne@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R59770209/02): page wrong correct R59770209 DML-1200 02/02/2009...
