NELCO CONTACT AB
Safe Operation & Maintenance Instruction
Battery Pump
NBHP 18V
–––
Version: 2017/08
Battery Pumps are carefully inspected for quality and tested for
safety. We follow ISO 9001: 2008/ ISO 14001: 2004/ IECQ QC 080001/
OHSAS 18001: 2007 Standards
ATTENTION!
Safe Operation & Maintenance Instructions must be followed.
Advertisement
Table of Contents
Summary of Contents for Nelco NBHP 18V
- Page 1 NELCO CONTACT AB Safe Operation & Maintenance Instruction Battery Pump NBHP 18V ––– Version: 2017/08 Battery Pumps are carefully inspected for quality and tested for safety. We follow ISO 9001: 2008/ ISO 14001: 2004/ IECQ QC 080001/ OHSAS 18001: 2007 Standards ATTENTION! Safe Operation &...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions .............. 1 Scope of Delivery ............... 2 Product Description ............3 Strap Installation Instruction ..........4 Functional Features ............5 Battery Charging / Battery Cartidge ........6 Strap Installation Instruction ..........6 ... -
Page 3: Safety Instructions
Thank you for using NELCO products. This manual must be read carefully prior to operating this product. Special attention should be paid to the section “Safety Instructions”. Damages and injuries caused by improper use of this product are NOT included in our warranty. We would like to remind you to work safely and to keep this manual on hand. -
Page 4: Scope Of Delivery
Scope of Delivery Description Quantity Battery pump Battery 18 V DC / Li-ion Charger Hydraulic hose Shoulder strap Instruction manual Remote controller... -
Page 5: Product Description
Maintenance warning attached: Buzzer alert at long deep if crimping or cutting is not completed and losing pressure when failure caused. Shoulder strap for high wearing comfort. 7 modes for different applications that can be selected by the functional knob. NELCO CONTACT AB... -
Page 6: Strap Installation Instruction
Product Description Battery Specifications: Brand: BOSCH Type: Lithium-ion (Li-ion) Capacity: 4.0 Ah Output Voltage: 18V Charger Specifications: Model No.: AL 1860 CV Input Voltage: 230V Approximate charging time per battery: 45mins <4.0Ah> Strap Installation The battery pumps are ready to use for overhead operation ... -
Page 7: Functional Features
8. Battery power ※ The system counts a work time when the pressure is over 200 bars. An alert signal will pop up to remind users to maintain the pump when the work time is over 5000. NELCO CONTACT AB... -
Page 8: Battery Charging / Battery Cartidge
Battery Charging 1. Plug the AC charger plug into the wall socket. Ensure the electrical outlet meets the charger’s specifications. Position the battery cartridge into the battery charger. The LED indicator light will go out when the battery is fully charged. Charging time for the 4.0 Ah battery cartridge is approx. -
Page 9: Maintenance
Hydraulic fluid temperatures over 65°C might soften packings and seals and cause fluid leaks. The hydraulic fluid pressure should only be adjusted by NELCO service representatives Inform NELCO authorized distributors in case of any abnormalities or malfunctions of the product. -
Page 10: Oil Refilling Instruction
Refilling Hydraulic Fluid 1. Make sure the oil pressure has been released to zero. 2. Remove batteries. (Picture 1) 3. Loosen the valve bolt. (Picture 1) 4. Put a funnel to easily pour in the oil. (Picture 2) 5. Pour in new hydraulic oil and make sure the amount of the hydraulic oil reach to 1500c.c. -
Page 11: Table Of Components / Diagram Of Components
NBHP 18V Table of Components Part Name Q’ty Part Name Q’ty Housing Compression Spring Housing Screw Pump Assembly Washer Circuit Board Washer Shackle Nuts Valve Bolt Connector Plug Connector (female) Screw Plug Connector (male) Screw Release Knob Adaptor Shift Lever Pin... -
Page 12: Battery Pump
Item: Battery Pump Model No.: NBHP 18V Serial No.: Date of Inspection: Q.C. Supervisor: NELCO CONTACT AB For NELCO Authorized For Industry or Individual Distributor Use Only: Buyer Use Only:...
