  • Page 1 Op e n Ch a n n e l N o n - Co n t a c t R A D A R F l o w Me t e r V 1 . 1 , S e p t e mb e r 2 0 1 3 R u e J .

  • Page 3: Table Of Contents

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com CONTENTS SPECIFICATIONS - 3 - GENERAL INFORMATION - 5 - - 5 - AFETY INFORMATION 2.1.1...
  • Page 4 WARRANTY STATEMENT - 30 - Copyright © 1989-2013 Flow-Tronic S.A. All printed material should not be changed or altered without permission of Flow-Tronic S.A. Any published technical data and instructions are subject to change without notice. Contact your Flow-Tronic representative for current technical data and instructions.

  • Page 5: Specifications

    Any service involving the transmitter must only be performed by FLOW-TRONIC S.A. or authorized trained personal. The user must ensure that no one is within 20 cm of the face of the radar transmitter when operating.
  • Page 6 Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com Flow measurement Method Based on continuity equation Q = V*A calculated by logger or flow monitor ±...

  • Page 7: General Information

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com General Information 2.1 Safety information Please read this entire manual before unpacking, setting up, or operating this equipment. Pay attention to all danger and caution statements.

  • Page 8: Confined Space Precautions

    The user must install this device in accordance with the supplied installation instructions and must not modify the device in any manner whatsoever.  Any service involving the transmitter must only be performed by FLOW-TRONIC S.A. or authorized trained personal. ...

  • Page 9: Product Overview

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com 2.2 Product overview ® The RAVEN-EYE sensor measures the flow velocity in open channels using radar technology. The unit is designed to withstand submersion during surcharge conditions.

  • Page 10: Theory Of Operation

    The water level is measured using an ultrasonic pulse echo sensor. Two models are available, a standard range ® 1,75 m and a long range 5,75 m sensor. The sensors can be attached to the RAVEN-EYE sensor body using specific mounting hardware. For both sensors a sound pulse is sent to the water surface and a portion of the signal is returned to the sensor.

  • Page 11: Installation

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com Installation 3.1 Unpack the instrument Before opening the shiping boxes, check them for any visible outside damage, and report the damages immediately.

  • Page 12: Mechanical Installation

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com 3.2 Mechanical installation 3.2.1 Site location guidelines For best accuracy, install the sensor where the flow is not turbulent. An ideal location is in a long, straight channel or pipe.
  • Page 13 Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com Figure 3: Sensor location near a curve, elbow or junction Acceptable upstream sensor location...

  • Page 14: Sensor Installation

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com 3.2.2 Sensor installation CAUTION Potential hearing loss risk. Hearing protection required. The level transducer emits ultrasonic sound energy when powered.

  • Page 15: Install The Mounting Hardware On The Wall

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com 550 mm ® Figure 6: RAVEN-EYE sensor dimensions top view with level sensor as installed 3.2.2.1 Install the mounting hardware on the wall...

  • Page 16: Attach The Sensor To The Mounting Hardware

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com Figure 7: Wall installation Distance from crown of pipe to wall bracket 3.2.2.2 Attach the sensor to the mounting hardware The sensor is equipped with 4 threads (M5) to be attached to the mounting hardware.
  • Page 17 Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com Figure 8: Assembling the mounting hardware Ball mount Threads for mounting hardware attachment...

  • Page 18: A Lign The Sensor Vertically

    25 mm (Figure 9). It may be necessary to install the 200 mm or ® the 300 mm (optional) spacer to position the RAVEN-EYE farther from the wall. Tighten the wing nut and make sure that the radar beam is not blocked by the wall or pipe. If the beam is blocked, move the frame further away from the wall using the 200 mm or the 300 mm (optional) spacer or lower the frame.

  • Page 19: Attach The Level Sensor

    Prerequisites ®  Attach the level sensor support to the RAVEN-EYE  Tighten the level sensor to the level sensor support. The sensor must be aligned vertically to make sure that the sensor is above the flow and that the radar beam will not be blocked by the wall or pipe (Figure 11).
  • Page 20 25 mm (Figure 11). It may be necessary to install the 200 mm or ® the 300 mm (optional) spacer to position the RAVEN-EYE farther from the wall. Tighten the wing nut and make sure that the radar beam is not blocked by the wall or pipe. If the beam is blocked, move the frame further away from the wall using the 200 mm or the 300 mm (optional) spacer or lower the frame.

  • Page 21: Align The Sensor Horizontally

    Figure 12: Horizontal alignment of the RAVEN-EYE sensor Procedure ® Use a bubble level and position it on the horizontal platform of the RAVEN-EYE (see point 1 on Figure 12). Slightly loosen the wing nut and position the sensor so that the platform is positioned horizontally.

  • Page 22: Measure The Sensor Offset

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com 3.2.2.8 Measure the sensor offset This section applies to ULS-02 and ULS-06 level sensors only. If you are using another type of level sensor, please refer to the instructions of the leveling device used.

  • Page 23: Sensor Offset Calculation

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com Measure the distance from the bottom of the rod to the mark. This is the sensor offset.

  • Page 24: Measure The Pipe Diameter

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com 3.2.3 Measure the pipe diameter The correct diameter of the pipe or channel is necessary for accurate flow calculations.

  • Page 25: Electrical Connections

    Electrocution hazard. Always disconnect power to the instrument when making any electrical connections. DANGER ® Potential confined space hazards. If conduit is installed from the RAVEN-EYE to the PLC or controller, the conduit must be sealed to keep sewer gases out of the electronics of the PLC or controller.

  • Page 26: Operation

    ® it has. The PLC can then read the different registers (refer to Table 2 on page - 25 -) from the RAVEN-EYE All the parameters from the measuring site are configured using the RTQ-Log software. Refer to the RTQ-Log software installation &...

  • Page 27: Parameters

    Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com 4.3.2 Parameters ® The RAVEN-EYE acts as MODBUS ASCII slave serial device. The PLC is the master device.
  • Page 28 Maintenance CAUTION Radar RF Exposure Hazard. Although the RAVEN-EYE® microwave power level is very small (~15 mW) and is well below government stated exposure limits for uncontrolled environments, users of this product should follow proper safety protocols for the handling of devices with radar frequency transmitters.
  • Page 29 Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790 E-mail : info@flow-tronic.com | www.flow-tronic.com Cleaning the instrument Regular cleaning is not necessary because the sensor does not contact the flow unless a surcharge condition occurs.
  • Page 30 Belgium www.flow-tronic.com Outside Belgium and Luxembourg Flow-Tronic maintains a large network of representatives and distributors. To locate a representative, send an email to info@flow-tronic.com or visit www.flow-tronic.com. 7.3 Technical Support Technical and Customer Service Department personnel are eager to answer questions about our products and their use.
  • Page 31 Form. Completion of this form will enable us to provide you with application information, software upgrades or product change notices. Please fax (+32 (0)87 899 799) or e-mail (info@flow-tronic.com) this copy to Flow-Tronic or request the e-mail registration form at service@flow-tronic.com If you have any questions or concerns regarding technical support, parts or service, please call Customer Service at +32 (0)87 899 797 or e-mail us at service@flow-tronic.com...
  • Page 32 S.A., postage paid, within twelve (12) months after date of shipment by Flow-Tronic S.A. If the purchaser believes the return of the product to be impractical, Flow-Tronic S.A. shall have the option, but will not be required, to inspect the product wherever located. In any event, if the purchaser requests Flow-Tronic S.A. visit their location, the purchaser agrees to pay the non-warranty expenses of travel, lodging and subsistence for the field service response.
