The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar "Konformitätserklärung"). Before using the
device the first time, please read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
If you drill a hole in the wall, please make sure that power cables, electrical
cords and/or pipelines are not damaged. When using the supplied mounting
material, we do not take the liability for a professional installation. You are
entirely responsible to ensure that the mounting material is suitable for the
particular masonry, and that the installation is done properly. Also ensure that
the mounting place is strong enough to hold this heavy device. When working
at higher altitudes, there is danger of falling! Therefore, use suitable
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Enjoy your product * Share your experience on Amazon
Features
LED light with 250 lumen brightness (3.3W) up to ~8m distance
(open areas) & luminous time ~20 seconds
PIR motion detection of 120° angle up to ~7m (open areas)
PIR trigger time 0.6 seconds
Stand alone device powered by batteries
Wall mounting (360° rotation, 180° up/down)
Many other mounting possibilities e.g. in the garden with the
Protection class IP65 (dust & waterproof)
Technaxx
LED Outdoor Lamp TX-107
Free Email: support@technaxx.de
®
* User Manual
safeguards.
Warranty 2 years
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Technaxx TX-107
- Page 1 LED Outdoor Lamp TX-107 The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, please read the user manual carefully. Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks).
-
Page 2: Technical Specifications
Weight / Dimensions 330g / (L) 19.5 x (W) 15.0 (H) 10.5 cm Package LED Outdoor Lamp TX-107, 1x Ground mounting Contents holder, 3x Screws with dowels, User Manual Note: These parts are needed to operate but are not included. - Page 3 Product overview Angle adjustment LED light Mounting base thumb Mounting base How to use the lamp Remove front cover rotating counter-clockwise picture A.1 and A.2. Open the lock picture B.1. Insert 4D-Cell batteries picture B.2. Note: Install batteries with polarity in correct position.
- Page 4 By removing the screw 2, you can remove the head from the mounting base for angle adjustments. Hold the base to the installation surface and mark the screw holes with a pencil. Hold the base to the surface you want to install it on mark the screw holes with a pencil drill holes on...
- Page 5 Put the head back on the basis tighten the screw 2 Loosen the screw 1 (little by little) turn the device to the right position (max. 360° around) tighten the screw 1 Loosen the screw 2 (little by little) bend the device to the right postion (max.
- Page 6 ON Mode After inserting the batteries the light mode is turned on and will be activated automatically when movement is triggered. Light shuts off after 20 seconds if there is no more movement. If during 20 seconds there is still movement the light will continue shining for 20 seconds.
- Page 7 Only use accessories as recommended in this manual. TECHNAXX recommends using 4 pieces of D-Size Alkaline batteries of very high standard, this product can model to obtain maximum battery life (do not mix old and new batteries).
