MINI-VEGA LIGHTBAR WITH MULTI-TONE SIREN
1.
DESCRIPTIONS ................................................................................................................................... 2
2.
DIMENSIONS & WEIGHT ..................................................................................................................... 3
3.
ELECTRICAL CHARACTERISTICS ..................................................................................................... 3
4.
MOUNTING INSTRUCTIONS ............................................................................................................... 4
5.
OPERATING INSTRUCTIONS .............................................................................................................. 4
The Installer is fully responsible for the mounting of equipment in the vehicle.
The Installer must define the means and the material necessary for mounting of equipment in order to deliver
the vehicle equipped according to the regulations.
MERCURA is not responsable for failures occuring due to incorrect definition of the type of mounting system,
reinforcements, drilling holes in roof panel, state and quality of mounting system, use of vehicle
manufacturer anchoring points and the system power supply and protection definition in accordance with the
vehicle energy source.
GT-0637-RAM IndB
TECHNICAL GUIDE FOR BLUE
WARNING CONCERNING MOUNTING OF MERCURA MATERIAL
Headquarters : Zone d'Activités « Les Gailletrous » - 4 rue Louis Pasteur- 41260 LA CHAUSSEE SAINT VICTOR- France
Tel : 00 33 2 54 57 52 52 - Fax 00 33 2 54 56 80 00
SAS with Capital 102. 400 € - APE (NAF) 2790 Z - SIRET 310 999 891 00040
MINI- VEGA LIGHTBARS
07/06/2016
SUMMARY
Page 1
29810-01
Advertisement
Table of Contents
Related Manuals for Mercura MINI-VEGA
Summary of Contents for Mercura MINI-VEGA
- Page 1 The Installer must define the means and the material necessary for mounting of equipment in order to deliver the vehicle equipped according to the regulations. MERCURA is not responsable for failures occuring due to incorrect definition of the type of mounting system, reinforcements, drilling holes in roof panel, state and quality of mounting system, use of vehicle manufacturer anchoring points and the system power supply and protection definition in accordance with the vehicle energy source.
- Page 2 MINI- VEGA LIGHTBARS 07/06/2016 DESCRIPTIONS Each light-bar is equipped with 4 x corner light modules, a siren module with loud-speaker, 4 magnetic pads for easy removal from the vehicle and a 4,5m length cable with cigar lighter plug, The cable exit is placed in the centre of the lightbar base.
- Page 3 MINI- VEGA LIGHTBARS 07/06/2016 DIMENSIONS & WEIGHT Weight: 6,4 Kg ELECTRICAL CHARACTERISTICS VOLTAGE : 10-15 volts CONSUMPTION Flash Mode only • 6,3A peak at 13,5 volts • 2,2A average at13,5 volts Flash Mode with Siren • 8A peak at 13,5 volts •...
-
Page 4: Operating Instructions
MINI- VEGA LIGHTBARS 07/06/2016 MOUNTING INSTRUCTIONS Before mounting the MINI VEGA lightbar on the vehicle roof panel, make sure that the surface on which the magnetic pads are placed is suitable and in good condition. The surface chosen must be flat and clean in order to optimize the magnetic contact between the roof panel and the magnetic pads. - Page 5 MINI- VEGA LIGHTBARS 07/06/2016 Lightbar cable Cigar lighter plug SIREN & FLASH MODE control switch FLASH MODE ONLY control switch The SIREN & FLASH MODE is activated using the ON/OFF switch on the cigar lighter plug (4) : Switch with red LED light which lights up when ON NB : The SIREN can only function if the FLASH MODE is activated.
