Caution for RT300 users in the USA:
Federal law restricts this device to sale by, or on the order of, a
practitioner licensed by the law of the state in which he or she
practices to use or order the use of the device.
RT300 Supine Service Guide
© Restorative Therapies Inc. 2017. Issue 2.1
RT300
™
Supine
Service
Guide
for build 2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Restorative Therapies RT300
Summary of Contents for Restorative Therapies RT300
- Page 1 Service Guide for build 2 Caution for RT300 users in the USA: Federal law restricts this device to sale by, or on the order of, a practitioner licensed by the law of the state in which he or she practices to use or order the use of the device.
-
Page 2: Table Of Contents
Clean Drive belt connection inspection /replacement Inspect foot and Calibration leg straps Fault correction procedures Fault correction Replace fuses Tighten drive belt Replace knee extension cable RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 12... - Page 3 C l e a n c o n t a c t a r e a s Restorative Therapies recommends that you clean the surfaces of RT300 Supine that come into contact with anybody who uses it after each use.
- Page 4 5. Remove the calf strap and wipe it down. Be sure to unclip the strap from the securing balls and then fold it off as shown below. RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 14...
- Page 5 8. Wipe down the securing straps 9. Wipe down the SAGE controller 9. Wipe down the RT300 supine’s table top, top cover and snout. Note: If you do not have an applicable cleaning policy consider using a germicidal disposable wipe such as Sani-Cloth® AF3. Be sure to follow the manufacturer’s instructions including use of protective equipment and contact time.
-
Page 6: Confirm Internet
If it contains a red X the Internet connection is not operating • 2. If the Internet connection is not operating tap on the Globe icon and then on the network manager link. RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 16... -
Page 7: Confirm Sage
Connect the RT300 Supine to the Internet by WiFi or wired Ethernet using • standard Microsoft Windows procedure. Procedures after each week C o n f i r m S A G E m o u n t i n g i s t i g h t 1. -
Page 8: Inspect Cords
1. Unplug the system from the AC mains supply 2. Inspect the AC power cord for any fraying, cuts and replace if damaged 3. Plug the system back into the AC mains RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 18... -
Page 9: General
G e n e r a l i n s p e c t i o n 1. Inspect for any damaged components and replace 2. Confirm the condition and test the operation of the RT300 Supine ergometer emergency stop switch 3. - Page 10 Please note that if and the crank arms and for any reason the calibration must carriages will begin to move be stopped press the “Cancel” button. RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 20...
- Page 11 7. Once complete the following window will display. Choose “Tap to close dialog.” to complete the process. RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 21...
-
Page 12: Connection
PCB. has bad contact Pedal crank does not rotate. Motor Control Board Change Motor Control Board (PP214675) defective. Motor is defective Change motor (PP217731) RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 25... -
Page 13: Tighten Drive Belt
Ensure that the correct RT60(s) are paired by matching the MAC address shown on the rear of each RT60. RT60 has no power Confirm the 19V power cable plugged into the RT60. RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 26... - Page 14 RT60 may be paired with Press system and stimulator and confirm another RTI device the last four characters of the MAC address match the serial number label. RT300 Supine Service Guide, © Restorative Therapies Inc. 2017. LB217394 Issue 2.1 Page 27...
