Summary of Contents for RXTEC RX-T601
- Page 1 HDMI TO VGA+R/L Audio Converter HD Video Converter User Manual HDMI TO VGA+R/L Audio Converter MODEL:RX-T601 Bring High-Definition to your life! Thank you for purchasing our product. To ensure safety and many years'...
-
Page 2: Specifications
HDMI TO VGA+R/L Audio Converter trouble-free operation of the product, please read the manual carefully before using this product. INTRODUCTION This kind of HDMI to VGA+R/L Audio Converter converts digital HDMI signal into analog VGA video and R/L audio signal. It allows users to enjoy their high definition image and sound when watching movies or playing games on the traditional VGA monitors or projectors. -
Page 3: Panel Introduction
HDMI TO VGA+R/L Audio Converter Signal Inputs/Output Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) Input connection HDMI A female(19pin) Output connection VGA, R/L Audio HDMI video input format 480i/576i/480p/576p/720p/1080i/1080P VGA video output format 480i/576i/480p/576p/720p/1080i/1080P Audio output format 2 channel LPCM Operating Frequency... -
Page 4: Connection And Operation
HDMI TO VGA+R/L Audio Converter 5.0 CONNECTION AND OPERATION Before installation, please make sure all devices you wish to connect have been turned off. 1、Connect the HDMI input from source device to this Converter.(Inputcables are optional) 2、Connect the VGA and R/L audio output of this product to the display device. 3、Insert the DC side of 5V power supply into and then connect the AC side of the power supply into the wall outlet. - Page 5 HDMI TO VGA+R/L Audio Converter 1. If the VGA port of display doesn’t support Refresh Rate at 50Hz,the connected Display will have no image when the HDMI Source setting at 50Hz. 2. If the VGA port of display doesn’t support resolution at 720p,1080i and 1080p,the connected Display will have to image when the HDMI Source setting at 720p,1080i and 1080p.
