*** USER'S MANUAL ***
FCC ID : SBUFGPSBT04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT1.5 and is the answer not in the manual?

Questions and answers

Related Manuals for Stars Navigation Technologies BT1.5

Summary of Contents for Stars Navigation Technologies BT1.5

  • Page 1 *** USER’S MANUAL *** FCC ID : SBUFGPSBT04...
  • Page 2 The Federal Communication Commission Statement This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication.
  • Page 3 Bluetooth GPS Receiver BT1.5 User’s Manual...

  • Page 4: Table Of Contents

    Bluetooth GPS Receiver User Manual Contents Caution------------------------------------------------------------------------------------------------------------ 2 0. Quick Start----------------------------------------------------------------------------------------------------- 2 0.1. Inside the package------------------------------------------------------------------------------------ 2 0.2. Connect to your PC/PDA---------------------------------------------------------------------------- 2 1. Introduction---------------------------------------------------------------------------------------------------- 3 2. Features and Functions--------------------------------------------------------------------------------------- 3 3. Technical Specification---------------------------------------------------------------------------------------4 3.1. General------------------------------------------------------------------------------------------------- 4 3.2. Acquisition Time (Average)------------------------------------------------------------------------- 4 3.3.Precision/Accuracy------------------------------------------------------------------------------------ 4 3.4.

  • Page 5: Caution

    But some Blue tooth system is forced to enter passkey, please use [0000] in such case. E. Connect to BT1.5 Bluetooth GPS Receiver and then make sure baud rate set at 9600 bps(standard) in your application program.

  • Page 6: Introduction

    Bluetooth GPS Receiver User Manual 1. Introduction BT1.5 Bluetooth GPS Receiver is a total solution of GPS receiver. High capacity rechargeable lithium-ion battery, GPS antenna, Blue tooth transmit/receive system are included. It is designed on the most advantage SiRF starIII chip solution, got the full-function, industry-level locating capacity and low prices.

  • Page 7: Technical Specification

    Bluetooth GPS Receiver User Manual 3. Technical Specification 3.1. General Core Module: Built-in high performance SiRF starIII chipset. Satellite channel number: all-in-view 20 parallel satellites; GPS frequency: 1575.42 MHz Receiver: L1, C/A code. Antenna type: Built in passive patch antenna External connector: MMCX (standard) 3.2.

  • Page 8: Dimension /Specification

    Bluetooth GPS Receiver User Manual B)NMEA code support: GPGGA(1 sec interval) GPGSV(5 sec interval) GPGSA(1 sec interval) GPRMC(1 sec interval) GPVTG(1 sec interval) Compatible with Blue tooth devices with Serial Port Profile (SPP) Blue tooth version 1.1 compliant Blue tooth Class 2 operation (up to 10 meter range) Frequency : 2.400 to 2.480 GHz Input Sensitivity: -83dBm 3.7.

  • Page 9: Start To Use

    Bluetooth GPS Receiver User Manual 4. Start to Use Step 1: Charge the battery in first use Please fully-charge the battery with at least 4 hours before you use the GPS receiver firstly. Power indicator Connect charge cable to the power plug at the bottom and start charging Bluetooth Power...

  • Page 10: Software/Hardware Usage

    Bluetooth GPS Receiver User Manual 5. Software/Hardware Usage 5.1. Hardware description 1). Bluetooth GPS Receiver device function description is shown as below: Passive antenna Power switch inside(face to open Power/GPS LED sky) Bluetooth indicator External Antenna MMCX Plug 2). LED display description Symbol Color Behavior...

  • Page 11: Configuration Setup With Pc Connection

    Bluetooth GPS Receiver User Manual 5.2. Configuration setup with PC connection Here is a sample to show you how to connect the Bluetooth GPS Receiver with your PC, software install and basic function test. 1) First, select a PC with Bluetooth interface. Or you can purchase Bluetooth adapter for your PC. Please contact with your PC’s sales about this.
  • Page 12 Bluetooth GPS Receiver User Manual 6) Open your Bluetooth places; you should see nothing while using firstly. 7) Click the [View devices in range] and you should find a [Bluetooth GPS] show as below: 8) Right click on the icon, select the [Discover Available Services]: 9) You should find the service SPP slave, right click and select [Connect to Bluetooth Serial Port]:...
  • Page 13 Bluetooth GPS Receiver User Manual 10) The follow message will show: 11) And the connection successful message: 12) Back to the Bluetooth service view, you should see the icon changed to [Connected]: 13) If you wish to use the connection more easily next time, you can create a shortcut for this: -10-...

  • Page 14: Configuration Setup With Pda Connection

    Bluetooth GPS Receiver User Manual 14) You will see the shortcut you just created: 5.3. Configuration setup with PDA connection Following will show how to configure the Bluetooth connection on PDA. It may be different from other PDA models. 1) Power on your PDA and the Bluetooth host. 2) Power on the GPS Receiver.
  • Page 15 Bluetooth GPS Receiver User Manual 3) See the screen, click Bluetooth mark at bottom, and [Bluetooth Manager] as below: 4) If this is your first time to use Bluetooth GPS, click the Bluetooth mark at the bottom as below: 5)Then the Bluetooth connection wizard show up, select [Explore a Bluetooth device] and click [Next].

  • Page 16: Software Install/Usage Guide

    Bluetooth GPS Receiver User Manual 6) Back to the [Explore a Bluetooth device] as below. Click [Next] to list service on Bluetooth GPS. [SPP slave] should appear in the service list box, click it and click [Next] to finish shortcut creation.
  • Page 17 Bluetooth GPS Receiver User Manual 2) Insert the CD-Rom into your CD drive. If your auto-run function works, you will see the welcome screen as below: 3) Select the language you preferred. We choose the “English” here: -14-...

  • Page 18: Warranty

    Bluetooth GPS Receiver User Manual 4) Click the [Useful tools and PocketPC utility] at the left: 6. Warranty The Bluetooth GPS receiver is warranty for free from defect in material and function for 1 year from the date of purchase. Any failure of this product within the period under normal conditions will be replaced at no charge to the customers.

  • Page 19: Concerning Of Poor Gps Signal

    Bluetooth GPS Receiver User Manual Error/Problem Cause Trouble shooting input for a few minutes. Bluetooth (2) Correct with right baud rate & interface will be reset in such case. com port (2) Wrong baud rate or com port setting Unstable GPS signal (1) degrade by anti-sunlight film Plug External antenna and place on with receiver placed inside car car roof...
  • Page 20 Bluetooth GPS Receiver User Manual Inside forests, or too many covers, GPS signal is disturbed. If you use the Bluetooth GPS Receiver inside the car, some anti-sunlight windscreen film will make the GPS signal degraded or signal blank. GPS satellite is owned by America military, sometimes they will tune-down the accuracy by some reason.
