Elite Pro I & II Adjustable Basketball System
Models: GP10A72, GP10G72
Installation, Operation and Maintenance Instructions
Please read all instructions before attempting installation or operation of these units
SAVE THESE INSTRUCTIONS FOR FUTURE USE
P
N
. 4 5 1 7 5 4 5 9 5
UBLICATION
O
Advertisement
Summary of Contents for PSS Gared GP10A72
- Page 1 Elite Pro I & II Adjustable Basketball System Models: GP10A72, GP10G72 Installation, Operation and Maintenance Instructions Please read all instructions before attempting installation or operation of these units SAVE THESE INSTRUCTIONS FOR FUTURE USE . 4 5 1 7 5 4 5 9 5 UBLICATION...
- Page 3 Elite Pro I & II Adjustable Basketball System Table of Contents Section Page No. Introduction Cautions and Warnings Parts Checklist Assembly and Setup 5-18 Unit Operation Padding Options...
- Page 4 Gared, Performance Sports Systems, or one of our authorized dealers. When contacting Gared or PSS, please have information regarding the dealer/installer who sold the unit, the name of the project, and any applicable warranty information.
- Page 5 Elite Pro I & II Adjustable Basketball System Parts Checklist Verify all parts listed on packing list are present prior to installation. The following parts have been packed separately Please refer to your packing slip to verify the correct board and goal has been received. Item Basic Items 6”...
-
Page 6: Installation Instructions
Flat washers (3/8”) Lock washers (3/8”) #8 x 5/8” Sheet metal screws Contact Gared Customer Service at 800-325-2682 or PSS Customer Service at 800-848-8034 for assistance with replacement of any parts missing or damaged. INSTALLATION INSTRUCTIONS Tools and Materials Required for Assembly: 1. - Page 7 Elite Pro I & II Adjustable Basketball System Use the illustration below to assemble the template plate and J-bolts.
- Page 8 Elite Pro I & II Adjustable Basketball System Use the illustration below to dig and prepare the hole for casting and anchoring the template plate. This hole is designed to use 1/2 yard of concrete.
- Page 9 Elite Pro I & II Adjustable Basketball System Set the J-bolt assembly in the concrete as shown in the illustration below. Make sure that the Nut coupler is facing toward the playing area.
- Page 10 Elite Pro I & II Adjustable Basketball System Begin the assembly of the Elite Pro Basketball System by raising and securing the main post as shown on the following two pages. This will give a good secure base on which to attach the remaining parts. *Note: This unit can be assembled lying down, but it will take twice as many people to raise it into final vertical position.
- Page 11 Elite Pro I & II Adjustable Basketball System The following illustration shows where to add the final flange nuts and washers to the base and how to level the main post.
- Page 12 Elite Pro I & II Adjustable Basketball System Unpack the backboard and mounting hardware. Use 3 sets of #5/16-18 bolts and nylon locking nuts to mount each of the 4 brackets.
- Page 13 Elite Pro I & II Adjustable Basketball System Unpack the goal and attachment hardware. Included should be the goal, the net, 4-bushings, bolts, nuts, washers, the cover plate and screws. Follow the steps illustrated below to assemble the goal to the backboard.
- Page 14 Elite Pro I & II Adjustable Basketball System The following illustration shows how to attach the LSCE72 Pro Mold Recreational Backboard Padding (if purchased). The padding may be attached before or after the backboard has been mounted in final position.
- Page 15 Elite Pro I & II Adjustable Basketball System The following pages give step by step instructions to complete the assembly of the GP10 Adjustable Basketball System. Follow the steps shown below to assemble the unit safely and in the proper order.
- Page 16 Elite Pro I & II Adjustable Basketball System STEP 1: Assemble the actuator brackets as shown.
- Page 17 Elite Pro I & II Adjustable Basketball System STEP 2: Attach the lower support arms as shown in the illustration below. *Note: Use as much help as is needed to complete this process safely.
- Page 18 Elite Pro I & II Adjustable Basketball System STEP 3: Attach the bottom of the height adjustment actuator to the anchor plates and the top to the end of the lower support arms as shown in the illustration below.
- Page 19 Elite Pro I & II Adjustable Basketball System STEP 4: Attach the upper pivot arms as shown in the illustration below.
- Page 20 Elite Pro I & II Adjustable Basketball System STEP 5: Attach the backboard to the upper and lower extension arms. You will need at least three strong men with ladders to complete this operation. *Helpful hint* Working out of the bed of a truck may be easier than using ladders. Make sure that you have enough help to complete this operation safely!
- Page 21 Elite Pro I & II Adjustable Basketball System Note: Height adjustment is continuously variable from 7’-6” to 10’-0”.
- Page 22 Elite Pro I & II Adjustable Basketball System Note: The padding options shown below are purchased separately.
- Page 23 Elite Pro I & II Adjustable Basketball System...
- Page 24 Gared Holdings, LLC Performance Sports Systems Gared Sports 9200 E. 146 Street 707 North 2 Street Noblesville, IN 46060 St. Louis, MO 63102 800-848-8034 800-325-2682 www.perfsports.com www.garedsports.com...
