Summary of Contents for IMP WMZ-630T
- Page 1 Manual WMZ-630T STEREO ZOOM MICROSCOPE...
-
Page 2: Table Of Contents
DJUSTMENT OF STAND 5. C HANGING THE MAGNIFICATION 6. F OCUSING 7. A TTACHING VIDEO AND PHOTOGRAPHIC SYSTEM Assembly of the video/photo system Assembly WMZ-630T photographic system. 8. P ROTECTING AND MAINTAINING Caution during operation Maintenance 9. O PTICAL SPECIFICATIONS Manual WMZ-630T... -
Page 3: Introduction
It widely used in the various applications, such as assembly and inspection industries, educational clinical and research purposes. The microscope come with standard supper wide field, high eye point WF10X Eyepiece, enable observation over a wide area and are convenient for operators who wear glasses. Manual WMZ-630T... -
Page 4: Specification
Accessory lens provide wider field of view and logger working distance. Various objectives suitable for different markets equipment: 0.3x, 0.5x, 0.75x, 1.5x and 2x. In order to make user have good understanding of WMZ-630T microscope we make a form of optical specifications at the end of manual. -
Page 5: Attacting Wmz-630T
2 Take out binocular body, place the TM-630 into its stand carefully, make it stable by tightening the screw. 3 Take out the eyepiece cover and dust cover. 4 Put eyepieces into eyepiece tube and adjust eyepiece tube (). 5 If you use accessory lens, please twist the lens on main body. Manual WMZ-630T... -
Page 6: Adjustment Of Stand
3 Focusing hand wheel is adjustable to loosen and tighten. you can adjust it for comfortable operation by yourself (a) turn the focusing stop ring counter clockwise, focusing hand wheel is tighten. (b) turn the focusing stop ring clockwise focusing hand wheel is loosen. Manual WMZ-630T... -
Page 7: Changing The Magnification
By turning the zoom knob located in either side of the stereomicroscope. The magnification can be changed continuously over a 1:6.5 zoom ratio. The magnification can be extended by using different eyepieces or supplementary lenses in various combinations. Supplementary lens power x eyepieces power x magnification setting =total magnification Manual WMZ-630T... -
Page 8: Focusing
2 Zoom to the highest magnification by turning the zoom knob gradually. Refocus the WMZ-630T by adjusting the focusing hand wheel until a sharp image is obtained. The WMZ-630T is capable of scanning of at low magnification and then zooming to a higher magnification for critical observation without losing focusing. -
Page 9: Attaching Video And Photographic System
SSEMBLY PHOTOGRAPHIC SYSTEM Put WMZ-630T main body into its stand. 2 Attach phototube to the top hole located on the top of WMZ-630T main body, and tighten it with the screws of the module. 3 Assemble camera adapter to phototube. -
Page 10: Protecting And Maintaining
.the pack it carefully in the original container or in a crush resistant carton with shock absorbing, dustless material surrounding it. Include a detailed letter describing the problem. This information will help the service technician to efficiently and cost effectively repair the instrument. Manual WMZ-630T... -
Page 11: Optical Specifications
19-3mm WF15x (16mm) 15.8-101.3x 15.2-2.4mm WF20x (11.5mm) 21-135x 11.4-1.7mm WF25x (9mm) 26.3-168.8x 8.6-1.3mm WF5x (24mm) 7-45x 17.1-2.7mm 38mm WF10x (22mm) 14-90x 15.7-2.4mm WF10x (19mm) 14-90x 13.6-2.1mm WF15x (16mm) 21-135x 11.4-1.8mm WF20x (11.5mm) 28-180x 8.2-1.3mm WF25x (9mm) 35-225x 6.5-1mm Manual WMZ-630T... - Page 12 W03-062...
