Summary of Contents for twaudio QDB30
- Page 1 QDB30 Operating manual...
- Page 2 Thank you for choosing a high-quality product “MADE IN GERMANY” from TW AUDiO. The QDB30 dolly is an accessory for the B30, VERA S30 or VERA S33 loudspeaker. This accessory set is characterized by a subtle look, a remarkable size to weight ratio and ease of use.
- Page 3 Operating manual QDB30 Notes on the products Before using the device, carefully read the operating manual and keep it with the QDB30 dolly. Read manual before use! General information Operation manual: OM-QDB30 Version 1.0 en, 03/2019 © by TW AUDiO 2019; all rights reserved.
-
Page 4: Table Of Contents
3. Technical specifications ....................7 Data sheet ....................... 7 4. Commissioning ....................... 8 Using QDB30 dolly with B30 or VERA S30 loudspeaker ........... 8 Using QDB30 dolly with VERA S33 loudspeaker ............ 10 5. Transport and Storage ....................12 6. CE Conformity Declaration .................... 13... -
Page 5: Safety | Intended Use
When moving the QDB30 dolly, ensure full load-bearing capacity and stability of the subst- rate. The QDB30 dolly is specified for a load of not more than four B30 or four VERA S30 or two WARNING VERA S33 loudspeaker. This load capacity must never be exceeded! -
Page 6: Overview
Operating manual QDB30 2. Overview Components Figure 2.1 - Overview Dolly - Surface Warnex textured paint 100mm castor with stopper (4 pieces) Recesses for stacking the dollys (4 pieces) Handles (4 pieces) Milling for rubberfeet for safely stacking loudspeakers (4 pieces) -
Page 7: Technical Specifications
Operating manual QDB30 3. Technical specifications Data sheet Maximum load capacity 4x B30 or 4x VERA S30 or 2x VERA S33 Dimensions (h x w x d) 800 x 700 x 150 mm (31.5 x 27.6 x 5.9 in) Weight... -
Page 8: Commissioning
Operating manual QDB30 4. Commissioning Using QDB30 dolly with B30 or VERA S30 loudspeaker Please note that two persons are always required to set up the QDB30 dolly with the B30 or VERA S30 loudspeaker! WARNING Place a maximum of four B30 or VERA S30 loudspeakers on top of each other on the QDB30 dolly. - Page 9 The QDB30 dolly can be stacked for storage. For this purpose, recesses (see figure 2.1 - Pos.3) are provided in the dolly (see figure 2.1 - Pos.1). When moving the stacked QDB30 dolly, note that there is a risk of tipping on each individual QDB30 dolly.
-
Page 10: Using Qdb30 Dolly With Vera S33 Loudspeaker
VERA S33 loudspeaker! WARNING Place a maximum of two VERA S33 loudspeakers on top of each other on the QDB30 dolly. Pay attention to the firmness of the structure in order to avoid tilting. Attach the two VERA S33 loudspeakers to the QDB30 dolly with the Cover2S33 protective WARNING cover. - Page 11 The QDB30 dolly can be stacked for storage. For this purpose, recesses (see figure 2.1 - Pos.3) are provided in the dolly (see figure 2.1 - Pos.1). When moving the stacked QDB30 dolly, note that there is a risk of tipping on each individual QDB30 dolly.
-
Page 12: Transport And Storage
Operating manual QDB30 5. Transport and Storage Ensure that the surface of the rigging frame is not damaged during transport and storage. Moisture may penetrate where steel surfaces are exposed by scratches and result in corro- sion. NOTE This is why the product should be transported in a safe, careful, dry and largely dust-free manner. -
Page 13: Ce Conformity Declaration
Operating manual QDB30 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 14 Operating manual QDB30 TW AUDiO GmbH Osterholzallee 140 71636 Ludwigsburg Germany Phone : + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
