Report No.: BL-SZ1680250-601 Revision History Version Issue Date Revisions Content Rev. 01 Nov. 15, 2016 Initial Issue Rev. 02 Dec. 06, 2016 Updating radiated spurious emission and restricted-band edge data. TABLE OF CONTENTS ADMINISTRATIVE DATA (GENERAL INFORMATION) ................ 5 Identification of the Testing Laboratory ..................5 Identification of the Responsible Testing Location ..............
Page 3
Report No.: BL-SZ1680250-601 4.4.5 For Radiated Test (Above 1 GHz) ..................15 Measurement Results Explanation Example ................16 4.5.1 For conducted test items: ....................... 16 4.5.2 For radiated band edges and spurious emission test: ............. 16 TEST ITEMS ............................17 Antenna Requirements ......................
Page 4
Report No.: BL-SZ1680250-601 5.6.3 Test Procedure ........................25 5.6.4 Test Result ..........................25 Radiated Spurious Emission ....................26 5.7.1 Limit............................26 5.7.2 Test Setup ..........................26 5.7.3 Test Procedure ........................26 5.7.4 Test Result ..........................27 Band Edge (Restricted-band band-edge) ................28 5.8.1 Limit............................
(4) The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. (5) This document may not be altered or revised in any way unless done so by BALUN and all revisions are duly noted in the revisions section.
2.3 Factory Information Factory Address 2.4 General Description for Equipment under Test (EUT) EUT Type AC1750 Wireless Daul Band Gigabit Ceiling Mount Access Point Model Name Under EAP245 Test Series Model Name Description Model name differentiation Hardware Version Software Version Dimensions (Approx.)
Report No.: BL-SZ1680250-601 2.6 Technical Information The requirement for the following technical information of the EUT was tested in this report: 802.11b/g/n(20 MHz): 2.412 GHz - 2.462 GHz = 2412 MHz + (N-1)*5 MHz, where = “Operating Frequency” in MHz, - N = “Channel Number”...
Report No.: BL-SZ1680250-601 2.7 Additional Instructions EUT Software Settings: Special software is used. The software provided by client to enable the EUT under Mode transmission condition continuously at specific channel frequencies individually. During testing. Channel and Power Controlling Software provided by the customer was used to control the operating channel as well as the output power level.
Page 10
Report No.: BL-SZ1680250-601 Run software: 10 / 129...
Report No.: BL-SZ1680250-601 3 SUMMARY OF TEST RESULTS 3.1 Test Standards Identity Document Title 47 CFR Part 15, Subpart C Miscellaneous Wireless Communications Services (10-1-15 Edition) KDB Publication Guidance for Performing Compliance Measurements on 558074 D01v03r05 Digital Transmission Systems (DTS) Operating Under §15.247 KDB Publication Emissions Testing of Transmitters with Multiple Outputs in the Same Band 662911 D01v02r01...
Report No.: BL-SZ1680250-601 4 GENERAL TEST CONFIGURATIONS 4.1 Test Environments During the measurement, the normal environmental conditions were within the listed ranges: Relative Humidity 45% - 55% Atmospheric Pressure 100 kPa - 102 kPa Temperature NT (Normal Temperature) +22℃ to +25℃ Working Voltage of the EUT NV (Normal Voltage) 12 V...
Report No.: BL-SZ1680250-601 4.3 Measurement Uncertainty The following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Value Occupied Channel Bandwidth...
Report No.: BL-SZ1680250-601 4.5 Measurement Results Explanation Example 4.5.1 For conducted test items: The offset level is set in the spectrum analyzer to compensate the RF cable loss and attenuator between EUT conducted output port and spectrum analyzer. With the offset compensation, the spectrum analyzer reading level is exactly the EUT RF output level.
Report No.: BL-SZ1680250-601 5 TEST ITEMS 5.1 Antenna Requirements 5.1.1 Standard Applicable FCC §15.203 & 15.247(b); RSS-247, 5.4 (6) An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section.
Report No.: BL-SZ1680250-601 5.2 Output Power 5.2.1 Test Limit FCC § 15.247(b); RSS-247, 5.4 (4) For systems using digital modulation in the 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz bands: 1 Watt. As an alternative to a peak power measurement, compliance with the one Watt limit can be based on a measurement of the maximum conducted output power.
Report No.: BL-SZ1680250-601 Set RBW ≥ OBW if possible; otherwise, set RBW to the largest available value. Set VBW ≥ RBW. Set detector = peak or average. The zero-span measurement method shall not be used unless both RBW and VBW are > 50/T and the number of sweep points across duration T exceeds 100.
Report No.: BL-SZ1680250-601 5.3 6dB Bandwidth 5.3.1 Limit FCC §15.247(a); RSS-GEN, 6.6 Make the measurement with the spectrum analyzer's resolution bandwidth (RBW) = 100 kHz. In order to make an accurate measurement, set the span greater than RBW. The 6 dB bandwidth must be greater than 500 kHz. 5.3.2 Test Setup See section 4.4.1 for test setup description for the antenna port.
Report No.: BL-SZ1680250-601 5.4 Conducted Spurious Emission 5.4.1 Limit FCC §15.247(d); RSS-247, 5.5 In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement.
Report No.: BL-SZ1680250-601 Emission level measurement Use the following spectrum analyzer settings: Span = wide enough to capture the peak level of the in-band emission and all spurious emissions (e.g., harmonics) from the lowest frequency generated in the EUT up through the 10th harmonic. Typically, several plots are required to cover this entire span.
Report No.: BL-SZ1680250-601 5.5 Band Edge (Authorized-band band-edge) 5.5.1 Limit FCC §15.247(d); RSS-GEN, 8.9, RSS-247, 5.5 In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement.
Report No.: BL-SZ1680250-601 Reference level: As required to keep the signal from exceeding the maximum instrument input mixer level for linear operation. In general, the peak of the spectral envelope shall be more than [10 log (OBW/RBW)] below the reference level. Specific guidance is given in 4.1.5.2. Attenuation: Auto (at least 10 dB preferred).
Report No.: BL-SZ1680250-601 5.6 Conducted Emission 5.6.1 Limit FCC §15.207; RSS-GEN, 8.8 For an intentional radiator that is designed to be connected to the public utility (AC) power line, the radio frequency voltage that is conducted back onto the AC power line on any frequency within the band 150 kHz to 30 MHz shall not exceed the limits in the following table, as measured using a 50µH/50Ω...
Report No.: BL-SZ1680250-601 5.7 Radiated Spurious Emission 5.7.1 Limit FCC §15.209&15.247(c); RSS-247, 5.5 Radiated emission outside the frequency band attenuation below the general limits specified in FCC section 15.209(a) is not required. In addition, radiated emissions which fall in the restricted bands, as defined in FCC section 15.205(a), must also comply with the radiated emission limits specified in FCC section 15.209(a).
Report No.: BL-SZ1680250-601 5.8 Band Edge (Restricted-band band-edge) 5.8.1 Limit FCC §15.209&15.247(c); RSS-247, 5.5 Radiated emission outside the frequency band attenuation below the general limits specified in FCC section 15.209(a) is not required. In addition, radiated emissions which fall in the restricted bands, as defined in FCC section 15.205(a), must also comply with the radiated emission limits specified in FCC section 15.209(a).
Report No.: BL-SZ1680250-601 5.9 Power Spectral density (PSD) 5.9.1 Limit FCC §15.247(d); RSS-247, 5.2 (2) The same method of determining the conducted output power shall be used to determine the power spectral density. If a peak output power is measured, then a peak power spectral density measurement is required. If an average output power is measured, then an average power spectral density measurement should be used.
Report No.: BL-SZ1680250-601 ANNEX A TEST RESULT A.1 Output Power Duty Cycle ANT 0+ANT 1+ ANT 2 Test Mode Duty Cycle T (ms) 1/T(kHz) 802.11b 1.00 1.00 1.00 802.11g 0.98 2.01 0.50 802.11n-20 MHz 0.97 1.88 0.53 802.11n-40 MHz 0.86 0.82 1.21 Average Power Test Data...
Page 31
Report No.: BL-SZ1680250-601 802.11n-20 MHz Mode: Measured Output Peak Power Total of output Limit Channel ANT 0 ANT 1 ANT 2 Verdict power 2412 16.95 49.55 16.12 40.93 16.20 41.69 21.21 132.16 Pass 2422 22.89 194.54 22.35 171.79 22.47 176.60 27.35 542.93 Pass...
Report No.: BL-SZ1680250-601 A.2 Bandwidth Test Data 802.11b Mode: 6 dB 6 dB Bandwidth 99% Bandwidth Bandwidth (MHz) (MHz) Limits Channel (kHz) ANT 0 ANT 1 ANT 2 ANT 0 ANT 1 ANT 2 7.16 6.16 7.46 12.62 12.50 12.62 ≥...
Page 33
Report No.: BL-SZ1680250-601 802.11n-40MHz Mode: 6 dB 6 dB Bandwidth 99% Bandwidth Bandwidth (MHz) (MHz) Limits Channel (kHz) ANT 0 ANT 1 ANT 2 ANT 0 ANT 1 ANT 2 30.22 32.67 30.12 36.30 36.40 36.20 ≥ 25.12 33.92 30.17 36.50 36.00 36.00...
Page 34
Report No.: BL-SZ1680250-601 Test plots (6dBm Bandwidth) ANT 0 802.11b LOW CHANNEL 802.11b MIDDLE CHANNEL 802.11b HIGH CHANNEL 802.11g LOW CHANNEL 802.11g MIDDLE CHANNEL 802.11g HIGH CHANNEL 34 / 129...
Report No.: BL-SZ1680250-601 A.3 Conducted Spurious Emissions Test Data Note: For Multiple transmitter output, the quantity 10 log (NANT) dB is added to each spectrum value before comparing to the emission limit. When testing out-of-band and spurious emissions against relative emission limits, tests may be performed on each output individually without summing or adding 10 log(NANT) if the measurements are made relative to the in-band emissions on the individual outputs.
Page 47
Report No.: BL-SZ1680250-601 802.11n-40MHz Mode: Limit (dBm) Measured Max. Out of Band Emission (dBm) Channel Carrier Level Calculated 30 dBc Limit Verdict ANT 0 ANT 1 ANT 2 ANT 0 ANT 1 ANT 2 ANT 0 ANT 1 ANT 2 -44.37 -47.09 -46.61...
