Plantronics CS500 Series Fact Sheet
Installing Handset Lifter..............................................................................2
●
Installing Handset Lifter Ringer Microphone...............................................3
●
Subscribing (Pairing) Headset to Base.......................................................4
●
Conferencing Additional Headsets.............................................................5
●
Warranty Date Code Location....................................................................5
●
Replacing Battery CS540...........................................................................6
●
Replace Battery CS510, CS520.................................................................7
●
Index
1
Advertisement
Related Manuals for Plantronics CS500 Series
Summary of Contents for Plantronics CS500 Series
- Page 1 Plantronics CS500 Series Fact Sheet Index Installing Handset Lifter................2 ● Installing Handset Lifter Ringer Microphone..........3 ● Subscribing (Pairing) Headset to Base............4 ● Conferencing Additional Headsets.............5 ● Warranty Date Code Location..............5 ● Replacing Battery CS540................6 ● Replace Battery CS510, CS520..............7 ●...
- Page 2 CS500 SERIES: HOW TO SET UP THE HL10 LIFTER The HL10 handset lifter automatically lifts the hand receiver of your phone when you press the call control button on your headset. Follow the instructions below to set up an HL10 with your CS500 Series system. PROCEDURE...
- Page 3 6. While wearing your headset, press the call control button on your headset to activate the lifter. 7. If you do not hear a dial tone, skip to the section titled "Troubleshooting No Dial Tone." If you do hear a dial tone, the lifter is set correctly and needs no adjustment.
- Page 4 3. Place the ringer microphone over the phone speaker. Remove the adhesive tape and attach. CS500 SERIES: HOW TO SUBSCRIBE (PAIR) A HEADSET TO THE BASE The headset and base unit are subscribed to each other right out of the box. If you need to use a replacement headset with the base, you have to subscribe (or introduce) it to the base.
- Page 5 A single tone sounds in the master headset as each guest leaves the call. CS500 SERIES DATE CODE LOCATION The Date Code for the CS500 Series is located on the label on the bottom of the base, and consists of four digits (MMYY).
- Page 6 CS540: HOW TO CHANGE THE BATTERY PROCEDURE If you notice that a fully charged battery is no longer lasting long enough, you can replace it. Its Part Number is 86180-01 Slide the battery cover off and remove it from the headset. 1.
- Page 7 If you are on a call and the headset battery is critically low, you will hear a repeated single low tone every 15 seconds indicating the battery is low. You should recharge the headset immediately. If you are not on a call and press the call button, you will hear three low tones if the battery is critically low. You should recharge the headset immediately.
- Page 8 2. Pull out the battery. If you are unable to reach the battery with your fingers, you can use a paper clip or a toothpick to pull the battery out by the wire as demonstrated below. 3.Detach the battery from its connector.
- Page 9 To replace the battery, simply reverse the above process: re-attach the battery to its connector, place the battery back in its housing, and close the cover.
