Summary of Contents for Customtronix RAX
- Page 1 Customtronix Page Page 1 (4) Stockholm 2015/03/09 Instruction Manual Customtronix RAX rear view mirror reverse camera re-route fix. PAGE 2 - INTRO 3 - Wires we need to splice 4 - RCA-style cables to do the job. www.customtronix.com...
- Page 2 All features of our RAX jailbreak products will be available for your vehicle, regardless if you choose to do this modification or not. This is no more than a convenience tweak. If you would like to do this modification, please contact us so we can send you the correct software for your navigation system.
- Page 3 Connect the cable with a yellow RCA-connector on one end and no connector on the other end to the harness in the picture by soldering, and connect the connector on the other end to your RAX- jailbreak cable harness which is situated behind your 8.4” monitor. Please use the input marked...
- Page 4 You can use any RCA-style cable to do the job. If it fits the input on the harness, you’re golden. You can buy one for cheap at Radio Shack, or simply re-use an old one you don’t need from a Sony Playstation, DVD-player or whatever.
