Summary of Contents for HGST Ultrastar Serv24 S2122-N24-4
- Page 1 Installation Guide Ultrastar Serv24 S2122-N24-4 Version 1.3 August 2018 1ET1084 ™ Long Live Data | www.hgst.com...
-
Page 2: Table Of Contents
Contents Installation Guide Contents Revision History....................4 Points of Contact.....................5 Copyright......................6 Chapter 1 Ultrastar Serv24 Overview............7 1.1 Ultrastar Serv24 Description............7 Block Diagrams..................9 1.3 Ultrastar Serv24 Specification Summary.........11 Ultrastar Serv24 Layout..............13 1.5 Ultrastar Serv24 Rack Requirements..........14 1.6 List of Replaceable Components.............14 Supported SKUs................15 1.8 List of Compatible Drives..............15 Chapter 2 Safety..................16 Electrostatic Discharge..............16... - Page 3 Contents Installation Guide Chapter 4 Installation................20 4.1 Ultrastar Serv24 Installation Overview..........20 4.2 Ultrastar Serv24 Installation Procedure...........20 Chapter 5 Initial Bringup................31 5.1 Bringing Up the Enclosure...............31 Appendix A System Operations Appendices..........35 ESD....................35 A.2 System Cooling................35 Power Requirements...............35 A.4 Host Connectivity................36...
-
Page 4: Revision History
Revision History Installation Guide Revision History Date Revision Comment November 2017 Revision 1.0 Initial Release December 2017 Revision 1.1 • Updated the Supported SKUs on page 15 • Updated the List of Compatible Drives on page 15 February 2018 Revision 1.2 Updated the Ultrastar Serv24 Installation Procedure on page 20... -
Page 5: Points Of Contact
Points of Contact Installation Guide Points of Contact For further assistance with an HGST product, contact Platform Engineering technical support. Please be prepared to provide the following information: Serial Number (S/N), product name, model number, and a brief description of the issue. -
Page 6: Copyright
Long Live Data is a trademark of HGST, Inc. and its affiliates in the United States and/or other countries. HGST trademarks are authorized for use in countries and jurisdictions in which HGST has the right to use, market and advertise the brands. -
Page 7: Chapter 1 Ultrastar Serv24 Overview
Rear Front The Ultrastar Serv24 is a 2U, 24 bay, single node storage server. The maximum data storage capacity of ™ the Ultrastar Serv24 is 184.32 TB using HGST Ultrastar SN200, SanDisk Skyhawk , and SanDisk ™ Skyhawk Ultra drives. For a full list of compatible drives and total storage capacities, see the... - Page 8 Ultrastar Serv24 Overview Installation Guide Ultrastar Serv24 Description • One dedicated 1 GbE port for IPMI...
-
Page 9: Block Diagrams
Ultrastar Serv24 Overview Installation Guide Block Diagrams 1.2 Block Diagrams Figure 2: System Block Diagram Figure 3: CPU/PCIe Switch/NVMe Drive Interface Block Diagram... - Page 10 Ultrastar Serv24 Overview Installation Guide Block Diagrams Figure 4: I2C Block Diagram...
-
Page 11: Ultrastar Serv24 Specification Summary
Ultrastar Serv24 Overview Installation Guide Ultrastar Serv24 Specification Summary 1.3 Ultrastar Serv24 Specification Summary Table 1: Environmental Specification Summary Specification Non-Operational Operational Temperature -40°C to 60°C 5°C to 35°C Temperature Gradient 30°C per hour max 20°C per hour max Temperature De-rating 1°C per 300m above 12000m 1°C per 300m above 950m Relative Humidity... - Page 12 Ultrastar Serv24 Overview Installation Guide Ultrastar Serv24 Specification Summary Specification Non-Operational Operational Altitude 950m to 12000m 950m to 3048m Table 2: Electrical Specifications Specification Value Maximum Power Consumption 1000W (low line) / 1200W (high line) Input Voltage 100-127VAC (low line) / 200-240VAC (high line) PSU Connector Type Inrush Current Maximum (per PSU) AC line inrush current shall not exceed 30A peak,...
-
Page 13: Ultrastar Serv24 Layout
Ultrastar Serv24 Overview Installation Guide Ultrastar Serv24 Layout Specification Non-Operational Operational Rack Units (U) Table 4: Data Capacity Specifications Specification Value Number of Drive Slots Max Raw Data Storage Capacity 184.32 TB 1.4 Ultrastar Serv24 Layout Figure 5: Ultrastar Serv24 Layout Table 5: Ultrastar Serv24 Layout Number Component... -
Page 14: Ultrastar Serv24 Rack Requirements
2U of rackspace, and it should be installed into the rack at the lowest possible U height to keep the load on the rack balanced. 1.6 List of Replaceable Components Table 6: List of Replaceable Components Component HGST Part Number L6 Enclosure 1EX1036 • Chassis • Redundant PSUs (1200W) •... -
Page 15: Supported Skus
Ultrastar Serv24 Overview Installation Guide Supported SKUs 1.7 Supported SKUs The following table lists the versions of this HGST product that are supported by this document. SKUs 1ES0412 1ES0415 1ES1004 1ES1005 1ES1006 1ES1007 1ES1008 1ES1009 1ES1010 1ES1011 1ES1012 1ES1013 1ES1014... -
Page 16: Chapter 2 Safety
2.1 Electrostatic Discharge CAUTION Electrostatic discharge can harm delicate components inside HGST products. Electrostatic discharge (ESD) is a discharge of stored static electricity that can damage equipment and impair electrical circuitry. It occurs when electronic components are improperly handled and can result in complete or intermittent failures. -
Page 17: Power Cords
All maintenance and service actions appropriate to the end-users are described in the product documentation. All other servicing should be referred to a HGST-authorized service technician. To avoid shock hazard, turn off power to the unit by unplugging both power cords before servicing the unit. -
Page 18: Safety Warnings And Cautions
Safety Installation Guide Safety Warnings and Cautions The power supply in this product contains no user-serviceable parts. Do not open the power supply. Hazardous voltage, current and energy levels are present inside the power supply. Return to manufacturer for servicing. Use caution when accessing part of the product that are labeled as potential shock hazards, hazardous access to moving parts such as fan blades or caution labels. -
Page 19: Chapter 3 Packaging
Packaging Installation Guide Ultrastar Serv24 Packaging Overview Chapter 3 Packaging 3.1 Ultrastar Serv24 Packaging Overview The main box of the Ultrastar Serv24 packaging consists of two layers of packaging totaling 39.5 kg / 87.2 lbs: The first layer contains the Rail Kit, CMA box, and foam protection. The chassis is on the second layer of the box. -
Page 20: Chapter 4 Installation
Installation Installation Guide Ultrastar Serv24 Installation Overview Chapter 4 Installation 4.1 Ultrastar Serv24 Installation Overview Table 9: Require Equipment Equipment Number Needed Notes #2 Phillips Screwdriver The #2 Phillips Screwdriver is used to install the provided screws into the rack mounted rails. Once the entire contents of the system are unpacked and accounted for, the installation process for the Ultrastar Serv24 can begin. - Page 21 Installation Installation Guide Ultrastar Serv24 Installation Procedure b) Locate the white tab on the outside of the inner rail. Figure 7: White Tab c) Slide the white tab and pull the inner rail free of the outer rail. d) Repeat the previous steps to remove the remaining inner rail. Install the inner rail onto the chassis.
- Page 22 Installation Installation Guide Ultrastar Serv24 Installation Procedure c) Mount the rail on the side of the enclosure and slide toward the rear to lock it in place. Figure 9: Inner Rail Lock d) Follow these steps for the second inner rail on the opposite side of the enclosure. Install the outer rails into the rack.
- Page 23 Installation Installation Guide Ultrastar Serv24 Installation Procedure c) Align the posts at the U-height desired for installation. The bottom of the rail will align with the lowest hole in the U. d) Pull the rail toward the rack step with the support posts aimed at the holes on the rack stems until the tool-less latching mechanism engages the rack.
- Page 24 Installation Installation Guide Ultrastar Serv24 Installation Procedure f) Align the front of the rail with the holes on the rack stems that will receive the support posts and pull the rail toward the holes until the tool-less latching mechanism engages the rack. Figure 12: Front Rail Mechanism Operation g) Latch the front rail mount to the rack by sliding the latch over the rack holes.
- Page 25 Installation Installation Guide Ultrastar Serv24 Installation Procedure c) Remove the enclosure cover from the enclosure. Figure 14: Removing the Enclosure Cover d) Locate the VROC connector on the motherboard as seen in the following image. The connector is located next to the PCIe bracket that covers the M.2s. Figure 15: VROC Connector Location e) Pressing firmly, plug the VROC key into the VROC connector on the motherboard.
- Page 26 Installation Installation Guide Ultrastar Serv24 Installation Procedure g) Once the cover is seated, press the cover latch down until it locks. Figure 16: Locking the Enclosure Cover Slide the enclosure into the rack. a) Pull the rack mounted rails out towards the front of the rack until they are locked in place. Figure 17: Rack Mounted Rails Locked b) Line up the enclosure with the rack mounted rails and slide it in until the first set of locks engage.
- Page 27 Installation Installation Guide Ultrastar Serv24 Installation Procedure c) On either side of the enclosure rails, pull the blue release tabs and push the enclosure into the rack. The enclosure latches will engage with the rail latch when properly seated. Figure 18: Blue Tabs Figure 19: Enclosure Installed Install the CMA.
- Page 28 Installation Installation Guide Ultrastar Serv24 Installation Procedure c) Insert the connectors into the rail connections on either side as seen in the image below. Figure 20: CMA Installation d) Slowly slide the enclosure forward to ensure the CMA arm is operating properly and return it back to its proper location.
- Page 29 Installation Installation Guide Ultrastar Serv24 Installation Procedure d) Connect the power cords and cables to the enclosure. Figure 22: Standard Power Cord and Cable Connections e) Close all of the baskets. f) Reconnect the CMA at the elbow to connector A. Test for binding in the extension of the CMA by gently pulling the enclosure out of the rack to ensure the cables extend properly and that the system doesn’t bind at all.
- Page 30 Installation Installation Guide Ultrastar Serv24 Installation Procedure b) Secure the enclosure to the rack using the preinstalled screws on each side.
-
Page 31: Chapter 5 Initial Bringup
Initial Bringup Installation Guide Bringing Up the Enclosure Chapter 5 Initial Bringup 5.1 Bringing Up the Enclosure Before you begin: • Ensure that you have a bootable USB drive that contains one of the following approved Operating Systems: Table 10: Manufacturer Supported Operating Systems Operating System Support Microsoft Windows Server 2012 R2 x64... - Page 32 Initial Bringup Installation Guide Bringing Up the Enclosure Note: The BIOS may take up to five minutes to appear. Figure 24: BIOS When the Setup Utility appears, press the right arrow to move over to the Server Mgmt tab. Figure 25: Setup Utility Press the down arrow until the BMC network configuration is selected and press Enter.
- Page 33 Initial Bringup Installation Guide Bringing Up the Enclosure • (optional) The Current Configuration Address may be altered from this section to change to a DHCP or Static network configuration. Figure 27: Dedicated Link To save the changes, press F4 and select Yes. Note: The enclosure will reboot to apply the new selections.
- Page 34 Initial Bringup Installation Guide Bringing Up the Enclosure b) Log-in to Web UI using the default username admin and default password admin. Figure 29: Admin Log-in 12. Navigate to Power Control using the Navigation menu. Figure 30: Power Control 13. Verify that Web UI displays a connection to the enclosure.
-
Page 35: Appendix A System Operations Appendices
System Operations Appendices Installation Guide Appendix A System Operations Appendices A.1 ESD The enclosure is designed to dissipate all electrostatic discharge (ESD) to the chassis base. Ensure that there is sufficient electrical and mechanical connection from the chassis base to the rack rails, and that the rack itself is tied to earth ground. -
Page 36: Host Connectivity
AC cycle, after which, the input current should be no more than the specified maximum input current. A.4 Host Connectivity The following table displays the list of power cables approved by HGST: Table 12: Approved Power Cables Type Part Number...
