D I M M A BLE
SAFETY & WARNINGS
1. Install in accordance with national and local electrical
code regulations.
2. This product is intended to be installed and serviced by a
qualified, licensed electrician.
3. Do not modify or disassemble this product beyond
instructions or the warranty will be void.
4. Only install with a Listed Class 2 DC LED driver.
5. Do not exceed maximum run recommended for Strip
Light.
6. Diode LED Strip Light is designed to be cut at designated
cut points only. Cutting anywhere other than the cut
points will result in damage to the Strip Light.
7. Failure to follow safety warnings, and installation
instructions will void the warranty for this product.
HYDROLUME
SLIM 24V LED STRIP LIGHT INSTALLATION GUIDE
®
HYDROLUME
®
24VDC
UV RESISTANT
POWER SUPPLY
CLASS
2
®
SLIM 24V LED Strip Light
IP68
SUBMERSIBLE
QUICK SPECS / MODELS
Input
Power
Max Run
Ambient
Temp †
† Do not install product in environment outside listed
temperature.
1 OF 8
Installation GUIDE
24VDC Constant Voltage
1.22W/ft. (1.5W/cut
Standard
point)
2.44W/ft. (1.0W/cut
Plus
point)
Standard
65 ft.
Plus
32 ft.
-4° - 122°F (-20° - 50°C)
IG022719-1.0
