V10 / V15
Point-source kit for all purposes
OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V10 and is the answer not in the manual?

Questions and answers

Related Manuals for Routline V10

Summary of Contents for Routline V10

  • Page 1 V10 / V15 Point-source kit for all purposes OPERATING MANUAL...

  • Page 2: Table Of Contents

    CONTENTS 1. SAFETY REGULATIONS ..................... 3 1.1. DISPOSAL OF WASTE MATERIALS .......................3 1.2. CONFORMITY AND WARRANTY ........................3 2. SYSTEMS’ DESCRIPTION ....................4 2.1. VEGAS 10 AND VEGAS 15 ..........................5 2.2. SUB 118 - SP12/SP23 ...........................6 3. WIRING ..........................7 3.1. CONNECTORS SPECIFICATIONS .........................8 3.2.

  • Page 3: Safety Regulations

    • always make sure to check the conformity and The V10 and V15 kits have been designed for me- good condition of the stands, tripods, supports, dium-small venues, but due to their high perfor- support surfaces and everything concerning the mance, they could cause hearing damage.

  • Page 4: Systems' Description

    (EU) Wheelboard-01 NL2FX/NL2FX loudspeaker cable The V10 kit contains two Vegas 10 and one self-powered Sub118 - SP23 , two audio speakON cables NL2FX/ • NL2FX (10 m), one power cord Powercon True1/Powercord (EU) and one wheelboard; speaker...

  • Page 5: Vegas 10 And Vegas 15

    Two point source models are used as the systems’ The Baltic birch plywood cabinet, with two bass- satellites: Vegas 10 for the V10 kit and Vegas 15 for reflex ports of the same material, allows to achie- the V15 kit.

  • Page 6: Sub 118 - Sp12/Sp23

    2.2. SUB 118 - SP12/SP23 Sub118-SP12/SP23 is the self-powered subwoofer for the reproduction of the low frequencies in the V10 and V15 kits. Its single 18’’ neodymium direct radia- tion woofer with dedicated bass reflex ports ensures a frequency response down to 35 Hz.

  • Page 7: Wiring

    3. WIRING After having analyzed the two different subwoofer panels and their relative input/output structures, here under you will find the drawings of the cross over system and of the connection panel of the Vegas 10 and Vegas 15 enclosures which are the same for the two models: INPUT / LINK INPUT / LINK The electro-acoustic features of the components are...

  • Page 8: Connectors Specifications

    3.1. CONNECTORS SPECIFICATIONS The cable used for cabling the point-source like Ve- use longer cables or, using a special cable adaptor, to gas and the Sub118 SP is the speakON NL2FX cable extend those already included with cables of the same (four-pole chassis and 1+ / 1- contacts).

  • Page 9: Cables And Pictures

    3.2. CABLES AND PICTURES NAME / CODE DESCRIPTION NL2FX / 10 m / 2 m speakON audio cables for satellites (1+ / 1- ) NL2FX PowerCON True 1 / 1.8 m professional power cable for the amplifier Powercord (EU) Type A / Type B Connection cable between the DSP of the kit USB cable...

  • Page 10: Amplification

    6 kW (order of protection, with an output to further power up to three kits in parallel at 220 V or two kits in parallel at 110 V (connection also valid to power the kits V10 and V15 in parallel).

  • Page 11: Dsp And Control Through Pc

    4.1. DSP AND CONTROL THROUGH PC The internal digital processor (DSP) integrated into the Sub118 SP amplification system, allows control and routing of the input signal to the relative output channels, following precise frequency cuts between Vegas and Sub118. As already mentioned, besides the control of the amplifier gain through the relative po- tentiometer, the DSP allows the choice of four diffe- rent presets (chapter 5).
  • Page 12 It will be possible to modify the mix between the two inputs for the V10 kit, by choosing between stereo (default) and mono mix in the “Scheme” section.

  • Page 13: Presets And Uses

    5. PRESETS AND USES The great peculiarity of the two kits is that when you with minimum effort. In fact, depending on different have a power supply and an analog input signal, they needs and tastes, but in the absence of necessary are immediately ready for use in plug &...
  • Page 14 The four default presets (shared by both kits), aim to Therefore the environmental and consequently acou- satisfy the needs of end users for different circum- stic variables are many and often not modifiable. stances and venues. However, the user can pay proper attention to the It is however important to know the intended use for positioning and aiming at the venue of the satellite, each of the two kits, which changes depending on the...
  • Page 15 In the example above, with a V10 kit in a space of 15 Logically, the more distance there is between the sa- m x 10 m, it is possible to see that the most even co- tellites, the more the aiming should be made inwards.

  • Page 16: Additional Elements

    (therefore to be requested specifical- • Additional Vegas 10 (only for the V10 kit) - it will be possible to link one Vegas 10 per side in addition to the two satellites of the kit for the total of four, to get a more extensive coverage.
  • Page 17 Two-speakers adaptor STAND-ADAPT Wall bracket STAND-WALL1 #2 M8 FIXING POINT #4 M6 FIXING POINT #3 M8 FIXING POINT Fixing points for horizontal installation Fixing points for vertical installation Wall bracket Truss bracket Horizontal wall WHH100-B TH100-B bracket ADJBH-E10/E15 OUTLINE S.R.L. Tel.
  • Page 18 • Speaker pole with base plate - A much more elegant alternative to the classic tripod. Ideal for conferences and similar situations, where it is possible to place the plate on a flat and stable surface. Easy to handle and transport, thanks to the dedicated bag.

  • Page 19: Periodic Controls

    7. PERIODIC CONTROLS All the components of the system (lodspeakers, am- of each element. plifiers, cables, rigging hardware etc.) require a num- In-depth controls must be performed ar regular time ber of periodic controls to be performed at regular intervals (for example, every 6 or 12 months), after time intervals to be decided by the persons in charge.

  • Page 20: Spare Parts

    8. SPARE PARTS As for all Outline products, there are spare parts available in case of component failures. For any other type of reparation it is necessary to contact Outline directly. Below you will find the spare parts and their relative item codes: L AME3KV1SP12/23 O S18B14ND40WP8...
  • Page 21 O SCD1ND1085-8 O S1064HPL8WP Vegas 10 / Vegas 15 spares: woofer 10”, woofer 15”, same driver for the two models. O SCD1ND1085-8 O S1576HPL8WP OUTLINE S.R.L. Tel. +39 030.3581341 www.outline.it Via Leonardo da Vinci, 56 Fax +39 030.3580431 25020 Flero (Brescia) Italy info@outline.it...

  • Page 22: Technical Specifications

    9. TECHNICAL SPECIFICATIONS 9.1. VEGAS 10 PERFORMANCE AND PHYSICAL SPECIFICATIONS Frequency Response 60 Hz – 20 kHz -10 dB Nominal Dispersion 90° x 70° (H x V) Maximum SPL Output * 130 dB SPL Component Low 10” woofer Component High 1.75”...
  • Page 23 50,8 50,8 Ø36 Ø36 48,61 252,78 48,61 48,61 252,78 48,61 OUTLINE S.R.L. Tel. +39 030.3581341 www.outline.it Via Leonardo da Vinci, 56 Fax +39 030.3580431 25020 Flero (Brescia) Italy info@outline.it...

  • Page 24: Vegas 15

    9.2. VEGAS 15 PERFORMANCE AND PHYSICAL SPECIFICATIONS Frequency Response 53 Hz – 20 kHz -10 dB Nominal Dispersion 80° x 70° (H x V) Maximum SPL Output * 132 dB SPL Component Low 15” woofer Component High 1.75” diaphragm compression driver Loading Low Bass-reflex Loading High...
  • Page 25 50,8 50,8 Ø36 Ø36 56,34 337,31 56,34 56,34 337,31 56,34 OUTLINE S.R.L. Tel. +39 030.3581341 www.outline.it Via Leonardo da Vinci, 56 Fax +39 030.3580431 25020 Flero (Brescia) Italy info@outline.it...

  • Page 26: Sub118 Sp

    9.3. SUB118 SP PERFORMANCE AND PHYSICAL SPECIFICATIONS Frequency Response 35 Hz – 125 kHz -10 dB Nominal Dispersion Quasi-omnidirectional Maximum SPL Output * 140.5 dB SPL Component Low 18” woofer Loading Low Bass-reflex Amplifier Output NL4 PAR Pins 1+/1- Amplifier Input Analog - XLR (G/H/C) / jack 6, 35 mm TRS Amplifier DC Input PowerCON True 1...

  • Page 27: Appendix: Periodic Checks

    APPENDIX: PERIODIC CHECKS The table below represents an ideal check list for It is possible to use this check list both as an electro- each single element. This table shall be filled in for nic and as a printed document. each element of the system.
  • Page 28 Outline carries out on-going research for product improvement. New materials, manufacturing methods and design upgrades are introduced to existing products without prior notice as a routine result of this phi- losophy. For this reason, any current Outline product may differ is some aspect from its description, but will always equal or exceed the original design specifications unless otherwise stated.
