INSTALLATION AND OPERATIONS
Corporate Office & Tech Support:
5900 S. Lake Forest Drive, Suite 230
McKinney, TX 75070
Phone: (972) 385-7899
Toll Free: (800) 367-0387
Fax: (972) 385-9887
MODEL B3X SERIES
HYDRAULIC BOLLARD
MANUAL
B&B ARMR
E-mail:
info@bb-armr.com
techsupport@bb-armr.com
www.bb-armr.com
MADE IN THE USA
Advertisement
Table of Contents
Summary of Contents for B&B ARMR B3 Series
- Page 1 MODEL B3X SERIES HYDRAULIC BOLLARD INSTALLATION AND OPERATIONS MANUAL B&B ARMR Corporate Office & Tech Support: 5900 S. Lake Forest Drive, Suite 230 McKinney, TX 75070 Phone: (972) 385-7899 Toll Free: (800) 367-0387 Fax: (972) 385-9887 E-mail: info@bb-armr.com techsupport@bb-armr.com www.bb-armr.com MADE IN THE USA...
-
Page 2: Introduction
Installation and Operations Manual — Model B3X Series Your safety is extremely important to us. If you have any questions or are in doubt about any aspect of the equipment, please contact us. INTRODUCTION Welcome! Congratulations on your purchase of a B&B ARMR vehicle barrier. In addition to providing detailed operating instructions, this manual describes how to install, maintain, and troubleshoot your vehicle barrier. -
Page 3: How To Contact Us
Installation and Operations Manual — Model B3X Series SYMBOL MEANING: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of non-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 4: Table Of Contents
Installation and Operations Manual — Model B3X Series Table of Contents INTRODUCTION ......................ii Safety ..........................ii How to Contact Us ...................... iii ORIENTATION ....................4 Overview ............................4 1.1.1 Hydraulic Cylinder ......................... 6 1.1.2 Cylinder Weldment Assembly ....................6 1.1.3 Tube Cover Plate ........................6 1.1.4 Proximity Switch Bracket ....................... - Page 5 Installation and Operations Manual — Model B3X Series friction surfaces. The Model B3X is offered in a variety of drive solutions: Automatic (HPU Driven), Semi-automatic (Manual) and fixed are the standard drive options available. The bollard system has been tested to Department of State specifications STD 02.01. The bollard system is designed to stop a 15,000-pound vehicle traveling at 40 mph.
-
Page 6: Hydraulic Cylinder
Installation and Operations Manual — Model B3X Series Figure 1: Model B3X Bollard Frame (Automatic Product Shown) 1.1.1 Hydraulic Cylinder On the automatic system, the hydraulic cylinder provides the force when pressurized to raise or lower the bollard by a hydraulic pumping unit. On the semi-automatic product, this is a pre-pressurized gas cylinder to allow the bollard to be manually lifted and lowered. -
Page 7: Housing Weldment
Installation and Operations Manual — Model B3X Series 1.1.5 Housing Weldment The housing provides the necessary structure to hold the bollard cylinder and position it when raising and lowering. 1.1.6 Collision Pins The collision pins are used as the elements to hold the bollard cylinder into the housing during impact. -
Page 8: Operation
Installation and Operations Manual — Model B3X Series A traffic control gate arm to warn the vehicle operator. This gate arm is positioned on the attack side of the barrier and does not open to allow traffic until the barrier is fully lowered (stowed), and the gate lowers to block traffic before the barrier starts to rise (deploy). -
Page 9: Maintenance
Installation and Operations Manual — Model B3X Series 3 MAINTENANCE Do not attempt repairs unless you are trained and qualified. This vehicle barrier can cause equipment damage and severe injury if it is operated or maintained improperly. 3.1 Introduction The B3X Bollards are designed to be largely maintenance free. As with any complex electromechanical device, they must be regularly inspected to ensure they are operating correctly. -
Page 10: Monthly Inspections
Installation and Operations Manual — Model B3X Series Failure MTBF Part Number Description Mode Cycles XPROX-FCM2-1204 Proximity Switch Electrical XCABLE-R-FA4TZ Proximity Switch Cable Electrical B30-3129 Guide Strip, Delrin Wear 200,000 B30-2006 Hydraulic Cylinder Wear 200,000 3.3 Monthly Inspections We recommend you perform the following visual inspections monthly on the barrier system. -
Page 11: Six-Month Inspections
Installation and Operations Manual — Model B3X Series Check hoses for wear. Check the operation of the control panel(s). Check the control panel’s buttons and lights for proper operation and replace if necessary. Update the operation and maintenance log. ... - Page 12 Installation and Operations Manual — Model B3X Series Symptom Actions directional control valve to see if problem is mechanical or electrical. Q. If mechanical: 5. Check for binding between moving plate and frame. Check connection of linkage between frame and plate. Check for foreign debris. Q, If not: Check PLC input 7.
- Page 13 Installation and Operations Manual — Model B3X Series Symptom Actions lubrication (multi-grade grease). 1. Check that the pressure relief valve is closed (fully clockwise) Hydraulic unit is excessively hot 2. Check that the pressure switch is adjusted to shut the motor off before 1900 PSI 3.
-
Page 14: Warranty
Installation and Operations Manual — Model B3X Series APPENDIX 5 WARRANTY BBRSS warranties for a period of one (1) year FOB manufacturing facility, unless otherwise specified by BBRSS in writing, from defects due to faulty material or workmanship. Damage due to handling during shipment and installation are not covered under warranty.
