Summary of Contents for HB Ross Manufacturing Co. ACVGD ROSS METER

  • Page 2 ® ® THE ACVGD ROSS METER USER MANUAL Published by the H.B. ROSS MANUFACTURING COMPANY, LLC. in Richmond, Virginia. U.S.A. © 2017 H.B. ROSS MANUFACTURING COMPANY. All Rights Reserved. ACVGD® and Ross Meter® are registered trademarks of the HB ROSS MANUFACTURING COMPANY, LLC. - Since 1975 -...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS ® …………………………………………………………...4 1.0 DIRECTIONS FOR USING THE ACVGD 1.1 Background….……………………………………………………………………………………..4 1.2 On the Job Site…………………………………………………………………………………..4 1.3 Taking Readings…………………………………………………………………………………..4 1.4 The Zero Reading Point…………………………………………………………………………..5 1.5 Other Reading Techniques……………………………………………………………………….6 1.5.1 The Triangulation Technique……………………………………………………………6 1.5.2 The Cable Path Technique……………………………………………………………...6 1.6 Typical Users Actual Practice…………………………………………………………………….7 ®...

  • Page 4: Directions For Using The Acvgd

    ® 1.0 DIRECTIONS FOR USING THE ACVGD 1.1 BACKGROUND – The alphabetic characters of the ® trademark, ACVGD , form an abbreviation, a symbol, for our use to more simply name the instrument which was orginially known as the 60 Hz A.C. Voltage Gradient Detector. The ®...

  • Page 5: The Zero Reading Point

    the readings by sticking them into the soil about two or three inches deep. If you go five or six inches deep, after taking readings at two inches deep, the A.C. voltage, at the deeper point, will likely provide a significantly higher reading, which could temporarily mislead you into thinking the fault point is closer than it actually is.

  • Page 6: Other Reading Techniques

    1.5 – OTHER READING TECHNIQUES Two other techniques you may choose to use in locating the point of the fault are: 1.5.1 - THE TRIANGULATION TECHNIQUE Now let's look at Figure 3. You will notice that it is essentially the same as Figure 2 but another set of readings is shown.

  • Page 7: Typical Users Actual Practice

    to continue taking readings. If you go far from the starting location without getting any readings you probably should go back to the 2/3's point, to start again, and probe in the other direction. Remember that as you get close to the source transformer (into the transformer zone) you will begin to get readings due to the a.c.
  • Page 8 again. Repeating this process until the panel meter reading reaches a maximum value and then begins to decline will bring the operator within range of the fault point. This technique allows the user to move along the cable path by walking in a straight ahead manner while moving the probes alongside their body. ®...

  • Page 9: General Information About The Acvgd

    ® 2.0 GENERAL INFORMATION ABOUT THE ACVGD 2.1 – W ARRANTY  The ACVGD ® instrument, and the probes, are guaranteed to be free from material and manufacturing defects for a period of one (1) year from the date of shipment to buyer. The probe tips are not warranted against normal wear and tear.

  • Page 10: Product Redesign Notice

    points exist anywhere along the length of these wires. This is a safety feature that is designed into the probes. The probe tips are made of stainless steel (1/4 inch solid rod) for added strength and durability. One end of the rod is threaded using a 1/4-20 NC die. The wire is secured to the end of the probe tip, within the probe's handle, by two 1/4-20 NC finished (zinc coated) hex nuts.
  • Page 11 TYPICAL LAYOUT OF FACILITIES U.G. WATER DISTRIBUTION PIPES METER BASE HOUSEHOLD GROUND UNDERGROUND SERVICE CABLE PADMOUNT TRANSFORMER GROUND CHAIN LINK FENCE Figure 1 TYPICAL PATTERN OF VOLTAGE CIRCLES NEAR THE SURFACE EACH DASHED CIRCULAR SHAPE REPRESENTS A SPECIFIC VOLTAGE AND ITS PATTERN WITHIN THE SOIL POINT OF THE FAULT TRANSFORMER ZONE...

  • Page 12: Figure 3

    TRIANGULATION METHOD OF LOCATING THE FAULT POINT EACH DASHED CIRCULAR SHAPE REPRESENTS A SPECIFIC VOLTAGE AND ITS PATTERN WITHIN THE SOIL POINT OF THE FAULT TRANSFORMER ZONE FAULT ZONE Figure 3...

  • Page 13: What's Included With The Acvgd

    ® ® WHAT IS INCLUDED WITH THE ACVGD ROSS METER 1. Utility Dry Box – (Outside Width: 7.75", Length: 15", Height: 6.5", Volume: 5.6 Liters) Orange in color. Extra-thick co-polymer construction wall will not warp from sun, cold, or rough handling. ®...

  • Page 14: Manufacturer Contact Information

    This manual as well as instruction and training videos are available online on our website, located at http://www.hbrossmfg.co Quickly access our website on your phone using this handy QR Code...
