Summary of Contents for H&K CST059
- Page 1 H&K DALLAS INC. “Our Quality Shines Through” HOT DOG COOKER BUN CABINET MODEL CST059 H&K DALLAS INC., 1343 S.HENDERSON AVE., DALLAS, TX 75223.
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION..............WARRANTY STATEMENT ..........SERVICE INFORMATION ..........POWER REQUIREMENTS ..........INSTALLATION..............OPERATING PROCEDURE..........MAINTENANCE..............TROUBLESHOOTING ............UNIT PRINT ................ ELECTRICAL SCHEMATIC ..........REPLACEMENT PARTS ............ H&K DALLAS INC., 1343 S.HENDERSON AVE., DALLAS, TX 75223. -
Page 3: Introduction
INTRODUCTION The hot dog cooker is designed to cook and hold hot dogs at a temperature of 165°F. The bun cabinet is designed to hold buns at 120-130°F temperature. WARRANTY STATEMENT H&K Dallas makes the following limited warranties to the original purchaser only for this equipment and replacement parts: H&K warrants all components to be free of defects in material and workmanship, if properly installed, operated and maintained, for a period of one (1) year from the date of the delivery. -
Page 4: Service Information
H&K shall not be liable for loss, damages or expenses arising from misuse, abuse, altera- tion, accident or improper installation of the equipment such as: • Improper or unauthorized repair; • Failure to follow proper installation instruction; • Improper maintenance; •... -
Page 5: Installation
INSTALLATION 1. Inspection: Upon receipt, examine the equipment carefully for any damage. Notify the carrier and H&K immediately if damage has occurred. 2. Unpacking: Remove the unit from the packaging. H&K recommends that the unit re- main crated until it has reached the installation location. 3. -
Page 6: Operating Procedure
OPERATING PROCEDURE 1. Initial Start-Up: Turn all the breakers and switches to the OFF position before turning the main power ON. Turn all the breakers ON. The refrigerator will start operating as soon as the refrigerator breaker is turned ON. Daily Start-Up: Close the drains and open the faucets;... -
Page 7: Maintenance
MAINTENANCE 1. Exterior Cleaning: The exterior of the unit should be cleaned with a soap and water mixture. Do not use abrasive cleaners to clean the exterior of the cabinet as this might damage the stainless steel finish. Do not use steel wool. 2. -
Page 8: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Compressor will not start 1. No power. 1. Connect power. 2. Breaker off. 2. Turn breaker on. 3. Thermostat stuck in open 3. Replace thermostat. position. Refrigerator short cycles 1. Differential set too close. 1. Increase differential. Refrigerator runs continu- 1. -
Page 9: Unit Print
H&K DALLAS INC., 1343 S.HENDERSON AVE., DALLAS, TX 75223. -
Page 10: Electrical Schematic
ELECTRICAL SCHEMATIC H&K DALLAS INC., 1343 S. HENDERSON AVE., DALLAS, TX 75223. -
Page 11: Replacement Parts
REPLACEMENT PARTS DESCRIPTION H&K PART NO. CONDENSING UNIT P-1-298 EXPANSION VALVE P-1-12-6 SWITCH E-1-19-09 HOT WELL HEATING ELEMENT E-5-30-10Z TEMPERATURE CONTROL P-1-18-9 WATER LEVEL RELAY E-4-24-0 WATER LEVEL SENSOR E-4-92 H&K DALLAS INC., 1343 S.HENDERSON AVE., DALLAS, TX 75223.
