Summary of Contents for Woodley Vision V5000
- Page 1 Ver. 5.0.0 Vision V5000 OPERATION MANUAL Woodley Equipment Company Ltd www.woodleyequipment.com - sales@woodleyequipment.com...
-
Page 2: Table Of Contents
contents 1.0 DescRIPtIon page 4 2.0 IntRoDUctIon page 6 3.0 UnPAcKInG AnD AsseMBLY page 6 4.0 UsInG tHe MIcRoscoPe page 7 5.0 MAIntenAnce page 8 6.0 tecHnIcAL sPecIFIcAtIons page 9 7.0 RecoVeRY AnD RecYcLInG page 9 Page 2... - Page 3 sAFetY GUIDeLInes This microscope is a scientific precision instrument designed to last for many years with a minimum of main- tenance. It is built to high optical and mechanical standards and to withstand daily use. We remind you that this manual contains important information on safety and maintenance, and that it must therefore be made accessible to the instrument users.
-
Page 4: Description
1.0 DescRIPtIon EyEPIECE DIOPTrIC ADjusTMEnT rIng BInOCulAr OBsErvATIOn hEAD OBjECTIvE nOsEPIECE slIDE ClAMP sTAgE COnDEnsEr COArsE FOCusIng KnOB TrAnslATIOn KnOBs IrIs DIAPhrAgM TEnsIOn ADjusTMEnT KnOB FInE FOCusIng KnOB BrIghTnEss ADjusTMEnT IlluMInATOr KnOB Page 4... - Page 5 1.0 DescRIPtIon rEAr: TEnsIOn ADjusTMEnT KnOB On/OFF sWITCh POWEr suPPly InPuT jACK Page 5...
-
Page 6: Introduction
2.0 IntRoDUctIon This microscope is a scientific precision instrument designed to last for many years with a minimum of main- tenance. It is built to high optical and mechanical standards and to withstand daily use. We remind you that this manual contains important information on safety and maintenance, and that it must therefore be made accessible to the instrument users. -
Page 7: Using The Microscope
4.0 UsInG tHe MIcRoscoPe Adjust the observation head loosen the lock-screw, turn the observation head to a comfortable position for observation, and then lock the lock-screw. Place the specimen on the stage lock the specimen slide on the mechanical stage using the slide clamp. Ensure that the specimen is centred over the stage opening by adjusting the coaxial knobs of the stage. -
Page 8: Maintenance
(Product Code WD0383) which includes: lens Cleaning Fluid (WD0384), Air Duster (WD0385), Cotton Applicators (WD0386), Microglide lubricant (WD0387), lint-free lens paper (WD0388) and illustrated service instructions. All these products are also available individually If you need to send the microscope to Woodley for maintenance, please use the original packaging. Page 8... -
Page 9: Technical Specifications
6.0 tecHnIcAL sPecIFIcAtIons HeAD: v5000: binocular, 360° rotating, 30° inclined eYePIeces: WF 10X/ 18mm nosePIece: Quadruple, reversed oBJectIVes: Achromatic 4x, 10x, 40x, 100x (oil immersion) WoRKInG stAGe: Double layer with mechanical sliding stage, 125x115mm, moving range 50x30mm conDenseR: 1.25 n.A. Abbe type, with iris diaphragm FocUsInG sYsteM: Coaxial coarse and fine focusing system, with tension adjustment mechanism ILLUMInAtIon:... - Page 10 Woodley Equipment Company Ltd Old Station Park Buildings, St. Johns Street, Horwich, Bolton, Lancashire, BL6 7NY, United Kingdom Tel: +44 (0) 1204 669033 Fax: +44 (0) 1204 669034 Woodley Equipment Company Ltd www.woodleyequipment.com - sales@woodleyequipment.com...
