GEMS SENSORS & CONTROLS
OPERATING & INSTALLATION INSTRUCTIONS
SERIES 2200/2600
PLEASE READ CAREFULLY BEFORE INSTALLING
Part Number: 560550-0064
Issue: F
INTRODUCTION
The Series 2200/2600 pressure transducers use molecularly bonded high output strain gauges to
provide 100mV output for full range pressure, when used with a 10V d.c. power supply.
Series 2200/2600 high output pressure transducers and transmitters are fitted with an Asic
providing various optional (at time of order) voltage outputs, and a 4-20mA current output
capable of being used in control and indicating loops without further amplification.
Series 2200/2600 with the CE Mark conform with the essential protection requirements of the
EMC Directive 2004/108/EC amended by certified type testing to EN 61326-1 and
EN 61326-2-3.
Series 2200/2600 with the CE0086 mark also complies with the requirements of the Pressure
Equipment Safety Regulations 2016 and can be used as part of a safety-related system on
Category IV pressure equipment.
HAZARDOUS PRODUCTS
The Consumer Protection Act of 1987, Section 6 of the Health and Safety at Work Act 1974 and
the Control of Substances Hazardous to Health Regulations 1988 require that we advise
recipients and users of our products of any potential hazards associated with their storage,
handling or use.
The products which our Company supplies may be classified as Electrical, Electro-Mechanical
and Electronic equipment.
These products are tested and supplied in accordance with our published specifications or
individual special requirements that are agreed in writing at time of order. They are constructed
so as not to affect adversely the safety of persons and property when properly installed,
maintained and used by qualified personnel, in the applications for which they were designed and
manufactured.
Conformity with the requirements of the CE mark only applies when the installation
conditions described in these instructions have been met. For units supplied without a
cable assembly connection to the transducer must be accomplished using Gems Sensors
approved cable. See APPROVED CABLE section.
560550-0064
Issue F
Page 1 of 7
Advertisement
Related Manuals for Gems 2200 Series
Summary of Contents for Gems 2200 Series
- Page 1 Conformity with the requirements of the CE mark only applies when the installation conditions described in these instructions have been met. For units supplied without a cable assembly connection to the transducer must be accomplished using Gems Sensors approved cable. See APPROVED CABLE section.
-
Page 2: Mechanical Installation
APPROVED CABLE Gems sensors uses cables comprising 2, 3 or 4 colour-coded cores, enclosed by an aluminised polyester screen where the screen is in intimate contact with a separate drain wire. The outer sheath is chrome PVC and overall diameter is approximately 4 mm. -
Page 3: Operation
SERVICING The transducer cannot be repaired locally and if damaged should be returned to ourselves at the address shown below or to accredited dealers when a replacement/repair is required: Gems Sensors & Controls Gems Sensors Inc Lennox Road 1 Cowles Road... -
Page 4: Maintenance
RETURN TO FACTORY PLEASE NOTE: To comply with Health and Safety requirements, the instrument must be clean and safe to handle and accompanied by a formal statement to that effect duly signed by an authorised officer of the Company. Any instrument returned without certification will be quarantined and no action will occur until cleared. - Page 5 TABLE 1 CONNECTIONS 2200/2600 SERIES TYPE CONNECTOR 4-20mA VOLTAGE NUMBER OUT+ OUT- EARTH EARTH OUT+ EARTH 2200A-A2 MINI DIN STYLE 2200A-D2 CABLE EUROPE 2200A-F2 CABLE WEATHER PROOF 2200A-22 CABLE USA 2200X-A3 MINI DIN STYLE 2200X-D3 CABLE EUROPE DRAIN DRAIN 2200X-F3 CABLE WEATHER PROOF DRAIN DRAIN...
