- Page 1 Model 470-/H/PRO/IC Operating and Assembly Manual Midwest Equipment Manufacturing, Inc. 5225 Serum Plant Road Thorntown, IN 46071 11-11-11...
-
Page 2: Safety Rules
SAFETY RULES Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using power equipment. This symbol means Attention!!!!! It is used to point out safety precautions. ▪... - Page 3 Trac-Vac Model 470-/H/PRO/K/IC 6-04-12...
- Page 4 Model 470 Parts List Part No. Qty. Description 47010 Frame, Engine Assembly 56022 Engine (5.5 HP Honda) 56021 Engine (5.5 HP Intek) 56018 Engine (6.5 HP Briggs Intek) 56030 Turbine Housing (5.5 Honda, 5.5 Briggs) 46242 Turbine Housing (6.5 Briggs Intek) 56040 Turbine (5.5 HP Honda, 5.5 HP Briggs) 46253...
- Page 5 MOUNTING INSTRUCTIONS, MODEL 470 1. Locate hitch (32) across rear of mowing machine. Most mowers have holes that match holes in hitch; however, it is advisable to drill on far right of some models. (Fig. 1.) Secure with a minimum of three (3) bolts provided. 2.
- Page 6 Fig. 2 Fig. 3 Fig. 1 Eyebolt (2x) 5/16" Freenut (2x) Eyebolt Bracket Note: Bunch a few ribs of the hose up behind the 5/16" Whizlock Nut (2x) hose clamp to achieve a good tight seal to top. Fig. 4 Fig.
- Page 7 3/8" x 2 1/8" Clevis Pin 1/2" x 2 1/2" Hexbolt 1/2" Nylon Locknut 1/8" Cotter Pin Fig. 11 Fig. 10 Fig. 12 Fig. 13 Fig. 14...
-
Page 8: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Engine fails to start 1. Spark plug wire disconnected 1. Connect wire to spark plug 2. Fuel tank empty 2. Fill tank with clean fuel 3. Faulty spark plug 3. Clean, adjust gap or replace Loss of power or erratic operation 1. -
Page 9: Operating Procedure
When storing a unit with Rubbermaid containers, leave containers latched to top. Store inside a clean dry area, when not in use. TRAC VAC WARRANTY POLICY Midwest Equipment Manufacturing, Inc. will repair or replace, free of charge, any part, or parts that are defective in material or workmanship or both for a period of one year residential use, and 90 day’s for commercial and rental use.
