Table of Contents Chapter ����������������������������������������������������������������������������������������������������������������������������������������������� Page Safety Recommendations ������������������������������������������������������������������������������������������������������������������������3 Introduction ��������������������������������������������������������������������������������������������������������������������������������������3 1�1 Intended Use ������������������������������������������������������������������������������������������������������������������������������������3 1�2 Principle of Operation ����������������������������������������������������������������������������������������������������������������������4 1�3 Distinguishing Feature ���������������������������������������������������������������������������������������������������������������������4 Description ���������������������������������������������������������������������������������������������������������������������������������������4 2�1 Components �������������������������������������������������������������������������������������������������������������������������������������4 2�2 Technical Data ����������������������������������������������������������������������������������������������������������������������������������5 Installation of Mains Plug ���������������������������������������������������������������������������������������������������������������5 Preparation for Use ��������������������������������������������������������������������������������������������������������������������������6 Operation ������������������������������������������������������������������������������������������������������������������������������������������7 5�1 Function of Displays ������������������������������������������������������������������������������������������������������������������������7 5�2 Function of Buttons �������������������������������������������������������������������������������������������������������������������������8...
Examples of acceptable workpieces include bushings, shrink rings, pulleys, and gears� All bearings that fit over the inductive coil and between the vertical supports with the top yoke in place can be heated using the IHN080/120� In addition, smaller bearings can be placed over either of the three standard yokes�...
Distinguishing Feature The distinguishing feature of the IHN080/120 induction heater is the location of the workpiece at the same position on the core as the inductive coil� This design improves efficiency, resulting in less power consumption and faster heating, which reduces the cost to heat each bearing�...
3 Installation of Mains Plug Due to the many types of mains plugs, no mains plug is supplied with the IHN080/120� A qualified electrician must install a suitable mains plug� The correct supply voltage is shown on the type plate / underside of the heater�...
Connect the IHN120 to only two of the three phases� Verify that the correct circuit breaker is installed� See section 2�2 for circuit breaker specifications� 4 Preparation for Use › Place the IHN080/120 in the horizontal position on a stable surface� › Connect the mains plug to a suitable mains supply� ›...
Function of Buttons Button Function POWER Press to adjust the power in steps of 20%� The selected power is indicated on the power display� MODE Press to switch between TIME MODE and TEMP MODE� UP (+) Press to increase the value shown on the main display� DOWN (-) Press to decrease the value shown on the main display�...
The workpiece is automatically demagnetised when heating is complete� Demagnetisation will not occur if the power is interrupted or the main switch is switched off� To use the IHN080/120 for demagnetisation only, select TIME MODE and set the time to 0�1 minute (6 seconds)�...
› When using the small yoke, never exceed 40% power� › When using the medium yoke, never exceed 60% power� 6 Safety Features The IHN080/120 is equipped with the following safety features: › Automatic overheating protection� › Automatic current control�...
Spare temperature probe IHNP2SENSOR Spare protective gloves IHNGLOVES Spare set support yoke 55 x 55 x 100 mm for IHN080/120 IHN080/120-YS Spare yoke 10 x 10 x 275 mm for IHN080/120 IHN080/120-Y1 Spare yoke 14 x 14 x 275 mm for IHN080/120...
