ACL Variable Sync VCO User Manual

Eurorack synthesizer modules
Hide thumbs

Advertisement

Table of Contents

Variable Sync VCO
User's Manual
16
Eurorack Synthesizer Modules
HP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Variable Sync VCO and is the answer not in the manual?

Questions and answers

Summary of Contents for ACL Variable Sync VCO

  • Page 1 Variable Sync VCO User’s Manual Eurorack Synthesizer Modules...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1.INTRODUCTION 2.WARRANTY 3.INSTALLATION 4.FUNCTION OF PANEL COMPONENTS 5.SPECIFICATIONS...

  • Page 3: Introduction

    1. INTRODUCTION Audiophile Circuits League . -Variable Sync VCO module consists of one ramp core oscillator with several wave shaper subcircuits, all having that classical vintage tone, loved by a lot of musicians and soundsynthesists. The VCO is capable of delivering that without sacri�icing tracking precision and low temperature drift.

  • Page 4: Warranty

    2. WARRANTY Is it a malfunction? In the event of a fault in use, we will repair or replace it free of charge under the warranty terms stated below. The warranty period is valid for one year from the Please read the user's manual carefully and check again. If you think that there is day of purchase.

  • Page 5: Installation

    3. INSTALLATION ⚠ WARNING *Always turn the Eurorack unit off and unplug the power cord before pluging GATE the Eurorack power cable. *When attaching the Eurorack power cable, please be careful not to touch the terminal part. +12V Connect to the Eurorack's system power supply (+ 12V) using the supplied Eurorack power cable.

  • Page 6: Function Of Panel Components

    4. FUNCTION OF PANEL COMPONENTS ① "TUNE" dial Fine tune with 10 turn precision pot approximately 4&1/2 octaves. ② "FREQ" selector Three frequency ranges – with a little bit more than 2 octaves apart. ③ "EXP FM 1&2" knob Two independent exponential type attenuators for CV signal input from ④...
  • Page 7 ⑦ "SYNC CV" knob ⑭ "PWM" input jack It is an attenuverter for the CV signal to control the "THRESHOLD" of the sync This is an input jack for controlling Pulse Width Modulation (PWM) with a CV type. Input a CV signal from the ⑫ "SYNC CV" input jack. signal.

  • Page 8: Specifications

    5. SPECIFICATIONS Power Eurorack system power supply Width 16 HP Depth 22 mm Power consumption Ca. 35mA on -12V / ca. 40mA on +12V Accessories · Eurorack power cable x1 · Mounting screws x4 ACL-E-VCO-1709-1...
