9 . Te chnical characteristics
• Power supply: +20 V DC V via two core cable(plug specifications: Ø internal 2.1mm, Ø external 5.5mm).
• Amperage (excluding the 0/+10 V DC outlet): 100 mA
• Maximum amperage for analogue output: 5 mA per channel
• Accuracy: +/-1 bit
• DMX 512 rate: 15 mS
• Fade time: from 0.1 to 15 seconds
• Microprocessor controlled digital DMX 512 output via 5 pin XLR5
• Analogue 0/+10 V DC output via 8 pin Locking-din
• Individual channel bufffer for connection of dimmers in series
• 6 channels of analogue output variable from 0 to +10V DC
• 6 channels of digital DMX512 signal addressed 1 to 6
• Dust resistant sliders
• Over-voltage supply protection
• 4 rubber feet on rear
• FIxings for wall mounting
• Weight: 2,2 Kg
• Dimensions:
manual system
6
0/+10V-DMX 512
234 76
