Klingenburg AS2 Manual

Cleaning device for cleaning rotary heat exchangers

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

AS2 Cleaning Device for

Cleaning Rotary Heat Exchangers

Page 2

1. Cleaning Options

Page 3

2. Cleaning Device

Page 6

3. Cleaning Sensors

Page 10

4. AS2 Cleaning Control System

Page 16

5. Menu navigation

Page 23

6. Troubleshooting

Page 25

7. Technical Data

E N E R G Y

R E C O V E R Y

Table of Contents

Need help?

Do you have a question about the AS2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Klingenburg AS2

Page 1 R E C O V E R Y Page 2 1. Cleaning Options Page 3 2. Cleaning Device Page 6 3. Cleaning Sensors Page 10 4. AS2 Cleaning Control System Page 16 5. Menu navigation Page 23 6. Troubleshooting Page 25 7. Technical Data...
Page 2: Cleaning Options
1. Cleaning options Self-cleaning effect Under the usual conditions for the operation of ventilation systems and air conditioning systems, rotary heat exchangers do not tend to become contaminated. This is due to the laminar airflow in the rotor mass and the counter-current circuitry.
Page 3: Cleaning Device
2. Cleaning device If strongly adhesive contamination is present in the air, the installation of an automatic cleaning apparatus may be sensible. Usually, blowing out with compressed air is sufficient. Cleaning with high-pressure warm water is necessary only with tenacious viscous and greasy contamination. Please note that the residual water is to be blown out of the rotor following cleaning.
Page 4 Pulse sensor (for rotor speed) is located in the rotor casing Rotor circumference sensor* Rotor centre sensor* (1) AS2 drive motor (3) Toothed belt (5) Clamping screw (2) Nozzle slide (4) Idler...
Page 5 On reaching the centre sensor, the air relay switches off and the carriage travels to the starting position. During the cleaning procedure, the rotor runs with variable speed under the control of the AS2 control system. The external control signal (0 - 10 Volt) is not processed during the cleaning procedure, so this process should...
Page 6: Cleaning Sensors
Sensing distance <=30 mm Connect. wire colours blue / brown / black Usage Rotors Sorption wheel, Klingenburg Secatec Pulse sensor cleaning device Connection to controller: KR4/7 Clamp 4 = blue; Clamp 5 = brown; Clamp 6 = black KR15 and Premium Clamp 6 = blue;...
Page 7 Manufacturer Steute EEX-RC-M 14W Model Chanceover contact Reed contact IP code IP67 Atex changeover contact up to 250V Power supply AC/DC Contact Magnet Sensing distance <=7 mm Connect. wire colours gr-yel / grey / brown / black Usage Rotor, End position switch slide, Steute pulse sensor cleaning device Connection to controller:...
Page 8 Manufacturer Schmersal IFL-N4-12-10P Model PNP N/O Inductively IP code IP67 Power supply 10-30 Volt = Contact Steel contact tabs Sensing distance <=3 mm Connect. wire colours blue / brown / black Usage Cleaning device standard Schmersal Connection to controller KR4/7 clamp 4 = blue;...
Page 9 Manufacturer Pepperl & Fuchs NBB 8-18GM50-E2-3G-3D Model PNP N/O Inductively IP code IP67Atex Power supply 10-30 Volt= Contact Steel contact tabs Sensing distance <=7 mm Connect. wire colours blue / brown / black Usage ATEX cleaning decice, Rotors Pepperl & Fuchs Connection to controller KR4/7 clamp 4 = blue;...
Page 10 4. AS2 Cleaning Control System Functional characteristics Processor-controlled monitoring of the cleaning sequence Coloured display Detailed error messages Menu navigation Cleaning takes place from the inside to the outside (the contaminated water runs towards the outside)
Page 11: Functional Description
Functional description The cleaning control system enables the automatic, electronic cleaning of the contaminated thermal mass of a rotary heat exchanger. Standby indicates readiness for operation. A start signal from an external contact, the start button or an optional time switch activates the cleaning procedure. Following the start command, the carriage travels without media to the centre of the rotor.
Page 12 Scope of delivery The standard version of the cleaning device includes the following: Control box for AS 2 cleaning control system, degree of protection IP 54 (dimensions: see dimension sheet: page 25 Cleaning mechanism for compressed air cleaning Standard guide rail with covering on the inlet side Carriage with corresponding nozzle supports Pneumatic nozzle, including hose connections ca.
Page 13 In the inspection window, the display shows the status of the cleaning procedure S t a n d b y P a r k i n g p o s i t i o n Button description (Selection) (Enter) (Selection) for menu navigation Reset Start...
Page 14: Connection And Commissioning
3.4 Connection and commissioning The mechanical components (rail, carriage, motor, supports, and sensors) are pre-mounted and must be attached to the frame with screws. The frame is also prepared with rivet-down nuts. Adjust the pneumatic nozzles and, if necessary, the high-pressure nozzles so that these end around 20 - 30 mm before the thermal mass.
Page 15 Start the cleaning procedure with the Start button. The cleaning carriage must continuously drive towards the centre of the rotor. If this is not the case, stop cleaning and reverse the direction of rotation of the motor by switching two phases of the motor. When the direction of travel is correct (after changing the direction of rotation, restart the cleaning control), the carriage drives to the centre of the sensor and then begins the actual cleaning process.
Page 16: Menu Navigation
5. Menu navigation The operational readiness of the AS2 is indicated by: S t a n d b y P a r k i n g p o s i t i o n To access the menu hold down the Stop button ( ) and press the Reset and the Enter buttons ( Attention: The cleaning procedure can be stopped and then started again with these buttons.
Page 17: Language Selection
Holding down the Stop button ( ) and then pressing the Reset and Enter buttons ( takes you to the Settings menu P r o g . m o d e L a n g u a g e The Enter button then takes you to the sub-menu.
Page 18 After setting the teach-in run, program the start of the AS2. It is immaterial where the nozzle carriage is positi- oned, as the initial movement is the reset travel. Following the teach-in run, the AS2 automatically switches to...
Page 19: Speed Limit
Runtime: R u n t i m e p e r R u n t i m e c l o c k T a k t i m p u l s 1 , 5 In this menu item, you can set the travel time for the cleaning carriage. The nozzles should advance by a maximum of 10 mm per clock pulse.
Page 20 Tolerance limit: T o l e r a n c e l i m i t T o l e r a n c e l i m i t s : 1 0 % Here, a safety margin is set in % (5, 10 and 20%) for the steps / cycles counted in the learning trip. This is used to compensate for mechanical gear tolerances and to balance out heat technology-related situations (hot / cold).
Page 21 This menu item can be used to improve drying, by allowing the cleaning slide to advance only at every 2nd, 3rd or 4th turn of the rotor. This removes as much remaining water from the accumulation as possible. Caution: Cleaning will take longer with this function. Tresholds: T r e s h o l d s H / R...
Page 22 During the cleaning procedure the displays are as follows: Continuous travel to cleaning position (centre of the rotor) M o v i n g m i d d l e s x x x x Cleaning with air and water: W a i t T r i g g e r C l e a n i n g...
Page 23: Troubleshooting
Cleaning completed, return to park position M o v i n g r e s e t ! s x x x x The teach-in run is indicated by a large symbol “L” at the lower left. Otherwise, the display is the same as for the cleaning procedure.
Page 24 Once this has been done, it is ready to start cleaning again. Caution: The AS2 has a resettable fuse in the control circuit. It can be reset by briefly disconnecting the AS2 from the power (approx. 1 min.).
Page 25: Technical Data
7. Technical data Dimensions of cleaning device AS2...
Page 26 Technical data Controller type Cleaning device AS2 Power 0,09 kW Fuse (external) min. 4 A Fuse (internal) 3 x 1A motor / 1 x 0,08 A Control Mains voltage 380 - 420 Volt 3Ph / N / PE 50-60 Hz Ambient temperature -10°C to +40°C...
Page 27 Maintenance notices (e.g. V-belts re-tensioned on:)
Page 28 5) LED yellow: Sensor Cycle 10) LED yellow: Solenoid valve water external setpoint be monitored with a PTC relays. Sensor cycle value Please see the conection plan „AS2 with PTC brown / black / blue 0 - 10 Volt Relays“. operation Without ATEX:...
Page 29 Control unit release (external Supply air signal potential free contact closed AS2 with 4-20mA control signal Jumper position in AS2 to the right for mA input Thermostat relay motor For Rotor control the jumper has to be Optional: PTC-resistor motor inserted for 0-10V...
Page 30 Terminal connection plan for AS 2 Connected to a ATEX-PTC-Relay 1) LED yellow: Start 6) LED yellow: Motor thermo safety contact 2) LED yellow: Sensor middle 7) LED yellow: Solenoid valve air 3) LED green: in Operation 8) LED yellow: Error 4) LED yellow: Sensor Extend 9) LED yellow: Status message 5) LED yellow: Sensor Cycle...
Page 31 ATEX-PTC-Relay : 250 V AC15 A1 A2 14 11 12 24 2 22 T1 T2 Y1 Y2 400 V ~ 0,09 kW 230 V~ 1-6 PTC Relay...
Page 32 E N E R G Y R E C O V E R Y Klingenburg GmbH Boystraße 115 45968 Gladbeck Germany Tel.: +49-20 43-96 36-0 Fax: +49-20 43-7 23 62 E-mail: klingenburg@klingenburg.de www.klingenburg.de...
