"Smarter Timing Solutions"
FDC3302
Frequency Distribution Chassis
User Manual
USM3302-0000-000 Revision 9
January 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FDC3302 and is the answer not in the manual?

Questions and answers

Summary of Contents for EndRun FDC3302

  • Page 1 "Smarter Timing Solutions" FDC3302 Frequency Distribution Chassis User Manual USM3302-0000-000 Revision 9 January 2018...

  • Page 3: Preface

    EndRun Technologies is dedicated to the development and refinement of the technologies required to fulfill the demanding needs of the time and frequency community. The instruments produced by EndRun Technologies have been selected as the timing reference for a variety of industries and applications - computer networks, satellite earth stations, power utilities, test ranges, broadcast and telecommunications systems and more.

  • Page 4: About This Manual

    U.S.A. then Buyer shall pay all duties and taxes, if any. Products not manufactured by EndRun Technologies but included as an integral part of a system (e.g. peripherals, options) are warranted for ninety days, or longer as provided by the original equipment manufacturer, from date of shipment.

  • Page 5: Warranty Repair

    If the warranty period has expired, we offer repair services for equipment you have purchased from EndRun. Call and ask for a customer service agent. It is important to contact us first as many prob- lems may be resolved with a phone call. Please have the serial number of the unit and the nature of the problem available before you call.
  • Page 6 F D C 3 3 0 2 U s e r M a n u a l...

  • Page 7: Table Of Contents

    ..........6 FDC3302 Physical Description .
  • Page 8 Chapter Three - Control and Status Commands ......9 ........... . 9 Available User Commands .
  • Page 9 Appendix C - Network Port Option ........21 .
  • Page 10 F D C 3 3 0 2 U s e r M a n u a l...

  • Page 11: Chapter One - Introduction

    Main Features Overview The FDC3302 may be employed either as a simple, single-input, ten-output signal distributor for non- critical applications, or, by making use of its intelligent dual-input failover switching and redundant power supply capabilities, high-availability signal distribution systems for top tier commercial and military applications may be efficiently implemented.

  • Page 12: Free Flash Upgrades

    AC or DC input voltages. (Installation of the second power sup- ply is an option for the FDC3302.) The presence of proper voltage at the output of each of the two internal DC-DC converters is detected and monitored by the alarm logic and CPU. The outputs of these two power supplies are diode “OR’d”...
  • Page 13 F D C 3 3 0 2 U s e r M a n u a l...
  • Page 14 C H A P T E R O N E F D C 3 3 0 2 U s e r M a n u a l...

  • Page 15: Chapter Two - Basic Installation

    This chapter will guide you through the most basic checkout and physical installation of your FDC3302 Frequency Distribution Chassis. Subsequent chapters and appendices will give you the information needed to configure your installation for the maximum performance in your operating environment.

  • Page 16: Fdc3302 Physical Description

    Shown with optional Network Port and Dual AC Power Supplies RS-232 Connector This DB-9M connector provides the RS-232 serial I/O interface to the FDC3302. This allows the user to initialize, monitor and control the FDC3302. See Chapter 3 - RS-232 Serial I/O Port Signal Definitions for detailed information.

  • Page 17: Installing The Fdc3302

    Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord. If your FDC3302 has dual power supplies, then multiple power cords may be installed. To de-energize this equipment, disconnect all power cords from the device.

  • Page 18: Connect Serial I/O To Host Computer

    If the source(s) of your reference signal(s) has (have) compatible TTL alarm output(s) that you would like to use to force signal input switching on your FDC3302, connect these using coaxial cables to the Disable A and/or Disable B input(s) on the FDC3302. The factory default for the FDC3302 dis- setting is to ignore these inputs.

  • Page 19: Chapter Three - Control And Status Commands

    Chapter Control and Status Commands This chapter describes the FDC3302 control and status commands. The FDC3302 supports com- mands for performing initialization/setup and for monitoring the performance and status of the unit. The serial I/O port physical and electrical characteristics are defined as well.

  • Page 20: Detailed Command Descriptions

    C H A P T E R T H R E E All entered commands are assumed to be terminated with a carriage return. Line feeds are ignored. All responses from the FDC3302 are terminated with a carriage return and a line feed. Detailed Command...

  • Page 21: Disablemode

    C O N T R O L A N D S T A T U S C O M M A N D S disablemode This command allows you to select external alarm inputs from the reference source (if any) as speci- fied in Appendix D.

  • Page 22: Disablestat

    C H A P T E R T H R E E Query: disablemode Chassis response: y,n,on Factory default setting: disablestat This query-only command shows the status (signal levels) of the Disable A and Disable B inputs. The first character is for Disable A and the second character is for Disable B. A ‘0’ means the disable input is low, and a ‘1’...

  • Page 23: Reset

    C O N T R O L A N D S T A T U S C O M M A N D S supply). A one ‘1’ means the power supply is good. An ‘x’ means the optional power supply is not installed.

  • Page 24: Selectedin

    C H A P T E R T H R E E Command: return Chassis response: (The chassis will return to the primary input.) selectedin This query-only command shows the currently selected signal input, either A, B or NONE. Query: selectedin Chassis response: (Currently selected input is Signal Input A.)

  • Page 25: Switchmode

    C O N T R O L A N D S T A T U S C O M M A N D S switchmode This command sets the switching mode in case a fault is detected. A fault is either lack of sig- nal presence or a logic high level on Disable A or Disable B, provided these have been config- ured properly (see ).

  • Page 26: Rs-232 Serial I/O Port Signal Definitions

    In order to connect the distribution chassis to another computer, a null-modem adapter must be used. The serial cable provided with the shipment is wired as a null-modem adapter and can be used to con- nect the distribution chassis to your computer. FDC3302 DB9M Pin Signal Name Not Connected...

  • Page 27: Appendix A - Led Indicators

    "Smarter Timing Solutions" Appendix LED Indicators This chapter describes the distribution chassis LED indicators and what they mean. Power LEDs COLOR MEANING Green Power supply is good. One of the power supplies has failed. This condition will only exist in a unit with redundant power supplies. The redundant power supply is not installed.

  • Page 28: Output Leds

    A P P E N D I X A Output LEDs COLOR MEANING Green The output is present. The output is absent, shorted, or the output driver has failed. Alarm LED COLOR MEANING Green No alarm condition exists. An alarm condition exists. See commands alarmlist for more information.

  • Page 29: Appendix B - Upgrading The Firmware

    All such downloads are freely available to our customers, without charge. After you have downloaded the appropriate FLASH binary image file from the EndRun Tech- nologies website, you are ready to perform the upgrade to your distribution chassis.

  • Page 30: Problems With The Upgrade

    A P P E N D I X B After establishing communications with the distribution chassis using the desired port settings, issue the following command to initiate the upload: upload<CR><LF> After issuing this command, you will see the distribution chassis respond with this message: Waiting for download using XMODEM 128 or XMODEM 1K (both with CRC).

  • Page 31: Appendix C - Network Port Option

    Appendix Network Port Option This option allows you to monitor and control your FDC3302 via TCP/IP. Specifically, the telnet, ssh and snmp protocols are supported. The snmp support is MIB II compliant, however no enterprise MIB is implemented. Either telnet or ssh may be used to control and monitor the instrument state, but both protocols cannot be active at the same time.

  • Page 32: Available User Commands

    Default read-write community string is endrun_1. All entered commands are assumed to be terminated with a carriage return. Line feeds are ignored. All responses from the FDC3302 are terminated with a carriage return and a line feed. Detailed Command Descriptions netconfig This command queries or sets the IP network addressing parameters that are stored in FLASH.

  • Page 33: Netmac

    N E T W O R K P O R T O P T I O N Set: netconfig = OFF,192.168.1.135,255.255.255.0,192.168.1.1,192.168.1.1,- Chassis response: Reset network port (“netreset”) for these settings to take effect. Query: netconfig Chassis response: netconfig = OFF,192.168.1.135,255.255.255.0,192.168.1.1,192.168.1.1,0.0.0.0 Factory default setting: netconfig = ON NOTE...

  • Page 34: Netreset

    A P P E N D I X C netreset This command will reset the network port. This is needed after the network parameters are changed. For example, if you change from DHCP on to off then you will need to reset the network port. Command: netreset Chassis response:...

  • Page 35: Upgrading Firmware

    What You Need To Perform the Upgrade You will need a terminal program which can connect to your FDC3302 via Telnet and supports file uploading using protocols XMODEM 128 with CRC or XMODEM 1K with CRC. These are very common file transfer protocols and should be supported by virtually any terminal program.

  • Page 36: Problems With The Upgrade

    A P P E N D I X C After re-connecting via Telnet, issue the command and verify that it is indeed the firmware that you intended to upload to the distribution chassis. If it is, you have successfully upgraded the firm- ware.

  • Page 37: Appendix D - Specifications

    Spurious: < -110 dBc. Protection: Outputs may be shorted to ground with no damage. Connectors: Rear-panel female BNCs numbered 1 through 10. Adjacent Output to Output Isolation: EndRun Technologies FDC3302 Distribution Chassis Typical Adjacent Channel Isolation Measured Specification HP 3577A Floor...
  • Page 38 At 1 kHz < -160 dBc/Hz At 10 kHz < -163 dBc/Hz * See chart below for typical additive phase noise performance. EndRun Technologies FDC3302 Distribution Chassis Typical Phase Noise -- 10 MHz @ +13 dBm -100 -110 -120 -130...
  • Page 39 S P E C I F I C A T I O N S Network I/O (Option): Rear-panel RJ-45 jack. 10/100Base-T ethernet. Supported IPv4 Network Protocols (Option): TCP/IP Telnet DHCP SNMP v1 and v2 with community strings. Limited implementation - MIB-II only. AC Power: 90-132 VAC/180-264 VAC, 47-63 Hz, 0.6 A Max.
  • Page 40 � � � � � �� �� � ���� �� � �� ������� � ��� � � ������������� ���� �� EndRun EndRun EndRun EndRun �� ���������� ���������������� FD C3302 D IM EN SION S - AC PO WE R F D C 3 3 0 2 U s e r M a n u a l...
  • Page 41 S P E C I F I C A T I O N S ����������� �� ���������� ���������� �� ������� ����� �� ��� �� ������ �������������� ���� � ������ ������������ ���� �������������� ������� � ���� ���������� �������� ����� ����� ���������� ������ ������ ���������...
  • Page 42 A P P E N D I X D F D C 3 3 0 2 U s e r M a n u a l...
  • Page 43 Special Modifications Changes for Customer Requirements From time to time EndRun Technologies will customize the standard FDC3302 Frequency Distribu- tion Chassis for special customer requirements. If your unit has been modified then this section will describe what those changes are.
  • Page 44 S P E C I A L M O D I F I C A T I O N S F D C 3 3 0 2 U s e r M a n u a l...
