Vinteck V-10 CLIPPER User Manual

True-bypass midi switching pedalboard

Advertisement

Quick Links

Vinteck
sas
Di Guido Michetti & C.
10128 Torino Corso Vittorio Emanuele II, 123
Tel. + 39 – 339 7626891 fax + 39 - 011 – 547712
Laboratorio Via Limone 22 10141 Torino
Nr. Iscrizione RAEE IT08020000002500
(web) http://www.vinteck.com
(e-mail) info@vinteck.com
V-10 CLIPPER
True-bypass MIDI switching Pedalboard
User manual
Ed. 01 rev. 4
SW: DCEA - 0862

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-10 CLIPPER and is the answer not in the manual?

Questions and answers

Summary of Contents for Vinteck V-10 CLIPPER

  • Page 1 Tel. + 39 – 339 7626891 fax + 39 - 011 – 547712 Laboratorio Via Limone 22 10141 Torino Nr. Iscrizione RAEE IT08020000002500 (web) http://www.vinteck.com (e-mail) info@vinteck.com V-10 CLIPPER True-bypass MIDI switching Pedalboard User manual Ed. 01 rev. 4 SW: DCEA - 0862...
  • Page 2 Vinteck pag.2 V-10 CLIPPER Thank you very much for purchase of V-8 pedalboard. We really hope that it will be good friend for several ours of music. We ask you to write us by email at support@vinteck.com any problems or any ideas about hardware &...
  • Page 3: Remaining Risk

    To order the up-to-date versions of I.M. and for any further information, please contact Vinteck sas or the nearest Vinteck sas dealer. We will be pleased to receive your suggestions to improve our quality.
  • Page 4 External Power supply, 12 VAC or unstabilized DC, 600mA Dimension 43 x 12 cm. High 4.5/6 cm. 5- installation and wiring All connection are on the back of V-10 CLIPPER Low from right to left of image:: Power IN Power supplì input. 12VAC or DC 0.6 A (note: may ne power as well in AC or DC. It is possible to use lower power supply of 0.6 A, keep in mind that in that case will be not possible to activate in...
  • Page 5 Vinteck pag.5 V-10 CLIPPER MN ST MONO STEREO switch. (in MONO connections 9R-R/S e 10R-R/S (right canne) are deactivated, only left channels works. OUTPUTS A and B got same signal coming fron 9 and 10 left loops. EXT SW external tap tempo temporary input...
  • Page 6 Vinteck pag.6 V-10 CLIPPER WIRING EXAMPLES Followings schematis are only examples. Nor to be inted as LOW !!! Personal choise in sound building is the only real referement! Ex 1. 8 effects in front, 2 effects in send/return. Mono. Edizione 01 revisione0...
  • Page 7 Vinteck pag.7 V-10 CLIPPER Ex 2 8 effects in front, 2 stereo effects in Send return on 2 amps. Line insulator on amp 2. Midi management and expressione MIDI pedal. Edizione 01 revisione0...
  • Page 8 Vinteck pag.8 V-10 CLIPPER Ex 3 8 effects in front, 2 couple of effects in stereo in fronte of 2 amps. Line insulator on amp 2. Volume pedal after distorsion pedals. Edizione 01 revisione0...
  • Page 9 Vinteck pag.9 V-10 CLIPPER 6- USE AND PROGRAMMING OF V-10 CLIPPER. MIDI MANAGEMENT FUNCTIONS OF “MD” BUTTON MD button Make selection between LOOP and PROGRAM function of buttons 1 to 10 BLU LED “L” ON buttons 1 to 10 make direct activation of single loops...
  • Page 10: Global Function

    Vinteck pag.10 V-10 CLIPPER GLOBAL FUNCTION GLOBAL allows predefinition of following operative parameters, as in following table. FUNCTION COMMAND COMMAND 2 VALUE SAVE MIDI in channel UP DW 0 – omni 1- 16 MIDI out canne, MASTER UP DW 1-16...
  • Page 11 Vinteck pag.11 V-10 CLIPPER 3- Numbering of MIDI 0-127 / 1-128 Display show MIDI followed by a number from 0 to 1 0 = 0-127 , 1= 1-128 Make selection with UP and DW (down). Save and exit with MD...
  • Page 12 Save and exit with MD 10- Bank activation V-10 CLIPPER may meorize up to 12 banks, 10programs each. For easy management it is possible to activate only some of 12 bancs. Note: Not active banks keeps in menory patchs programmed.
  • Page 13: Preset Name

    A , out B MUTE ( when MUTE is programmed no signal comes out from V-10 Clipper) MIDI program change (1-128) and out channel (1-16) Up to 5 Control Change (1-128) e related midi out channel OUT (1-16) Programming Loops, switches, buffer, mute and A/B out Whit white led “P”...
  • Page 14 Vinteck pag.14 V-10 CLIPPER PROGRAM CHANGE MIDI MAPPING. Sofware release DCEA It is possible to assign a PROGRAM CHANGE differento from patch number. Default is program change = patch number. To change program change: While on the patch (ex 003, anyway 1 to 120) with white led “P” on :...
  • Page 15: Factory Reset

    V-Series-PS External power supply 8-warranty and terms V-10 CLIPPER is covered by warranty for 24 mounth from purchase Aany warranty will be made at the vinteck labs Lab: via Limone 22 – 10141 Torino Italy Shipping cost are charged to customers after 1 year.
  • Page 16: Declaration Of Conformity

    89/336/EEC and 93/68/EEC Standard(s) to which Conformity is Daclared EN 55103-1, EN 55103-2 and 60062: 1998 Manufacturer Vinteck SAS di Guido Michetti & C. Corso Vittorio Emanuele II, 123 10128 Torino – ITALY The equipment identified here conforms to the Directive(s) and Standards specifed above...
