- Page 1 ST-780 Series NETWORK PROXIMITY ACCESS CONTROL OPERATION AND INSTALLATION MANUAL VER 15.09.01 Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be...
-
Page 2: Table Of Contents
(8) Wiring for external subreader (9) Example: Door Open point with external RELAY 8. Installation of the unit 9.Attentions 10.Troubleshooting Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 3: Attentions
Chip serial number Card number (non-serial) Example of the card (serial) The last 8-digit number of 1234567890 is 34567890. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 4: Features Introductions
Dimensions: 140L X 60W X 30H(mm) Power supply : DC12V, Power consumption: 110mA (standby); 150mA (operation). Operation temperature : 0~70 Humidity: 85%Rh Max. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 5: Installation Procedures
Data which need to be sent are:1. Time 2. User's data 3. Time Zone 4. Parameter Completion of setting Please refer to the software manual for detailed operation. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 6: Reader Front Panel & Types Of Proximity Card
The above read range stated is for reference and it is varied according to the different environment it is used. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 7: Operation Instructions
1 3 13:00:15 Date setting , enter 1 6 and then enter 2000/01/01 (6) Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 8: Setting Modes & Functions
Error. It goes back to system function Continuous beep sound. one beep sound. selection when nothing is entered. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 9: Shunt Time
Enter door open mode(2 or 3) Enter to goes back to Enter # to go system function. back to system function selection. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 10: Change System Password
# button. Nothing is entered Setting completed, Error. Enter one beep sound. Continuous beep sound. Back to system function selection. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 11: Total Cards
One beep sound to go back to system function selection. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 12: Set Date
One beep sound to go back to system function selection. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 13: Main Reader Location
Enter # to confirm It goes back to system function selection when nothing is entered. Open door Back to the display screen Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 14: Communication Mode
Enter Wiegand mode(0 or 1) Enter to goes back to Enter # to confirm system function. Back to system function selection. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 15: Card Number Door Open Mode
(0 or 1) Enter to goes back to Enter # to confirm system function. Back to system function selection. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 16: Installation Instructions
A. EL of the electric lock. Door Open Relay as dry contact with maximum load of 1A@12VDC. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 17: Wiring For Additional Reed Switch Door Sensing
(3) Wiring for additional reed switch door sensing 5-PIN 8-PIN P Blu G Br R Bla R N.O. type reed switch Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 18: Wiring On For Anti-Duress Alarm
Bla R Bla R RS-485 interface transit connector POWER TXD RS-232 AP30 CONVERTER communication line RS-232 to RS-485 RS-232 DC12V Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 19: Additional Door Bell Wiring
RELAY. Please connect a Diode for the external RELAY to absorb surge (please make sure its direction). Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 20: Installation Of The Unit
Connect base and the unit back together. the wires with the unit. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be... -
Page 21: Attentions
This is to prevent the wires pressing on the wiring on the PC board causing bad contact, short circuit and interference. Lock Control - Kouterbaan 63 - 1840 Malderen - Belgium - Tel. +32 52 57 43 02 - info@lockcontrol.be - www.lockcontrol.be...
