FIRST
P
n
e
u
m
o
L
a
s
h
P
n
e
u
m
o
L
a
s
h
read these
pneumatic tensioner for
instructions
cord and composite strap
up to 50 mm
LCV
Stock no. 089192
Operating Instructions
and Spare Parts List
Do not destroy these operating instruct-
ions! The customer is obliged to make
these operating instructions available to
all operators and service personnel and to
ascertain that these persons understand
the contents.
Adhere to safety instructions and warn-
ings! Erroneous operation may cause seri-
ous injuries!
Advertisement
Summary of Contents for GREINER PneumoLash LCV
- Page 1 FIRST read these pneumatic tensioner for instructions cord and composite strap up to 50 mm Stock no. 089192 Operating Instructions and Spare Parts List Do not destroy these operating instruct- ions! The customer is obliged to make these operating instructions available to all operators and service personnel and to ascertain that these persons understand the contents.
- Page 2 Field of Application for the PneumoLash The PneumoLash central strapping tool is suitable exclusively for strapping all kinds of goods to be packaged, for securing cargo load units respectively using conven- tional cord and composite strap. Warning and Safety Recommendations Use safety glasses with lateral guards and protective gloves during cutting operations while working with strapping tools for cord and composite strap.
- Page 3 Suitable Cord and Composite Strap and Buckles Use commercial size textile and composite strap 0.5 to 2.4 mm thick and 50 mm (2") max. wide exclusively. Use commercial type locking buckles of suitable size only. The buckles must be used together with the proper textile or com- posite strap as released by the strap producer.
-
Page 4: Motor Lubrication
FRC-3/8-D-5M-MINI conditioning unit. For connecting the compressed air supply a hose with 9 mm clear width should be used and connected to the unit using the coupling 005-720, which comes with the set. For minimum pressure drop the air feed hose must not be longer than 10 m. Motor Lubrication In order to guarantee optimal life and performance the air motor requires appr. - Page 5 • Hose unit (Stock no. 089901) consisting of: 10 m RectuSoft - PVC 9.0 x 14.5 mm hose, 25KA TF09 MPN clutch, GT17/09N screw sock- et mounted via KB1417 two-ear hose clips. Connection of the PneumoCord to the service unit. •...
- Page 6 Mounting the Locking Buckle Depending on the type of buckle, different methods can be used to thread the cord and composite strap into the locking buckle. Option I can be used for buckles with open ends. Option II can be used for closed buckles.
- Page 7 Option II 1. Placing the first strap end 2. Inserting the strap end 3. Inserting the strap end into the buckle – first step – second step Run the first strap end from Run the strap end from below Now push the strap end from below through the middle buck- around the buckle opening above through the middle open-...
-
Page 8: Operation
Operation PneumoLash of the central strapping tool 1. Mounting strap in locking buckle First the strap is cut to the required length. The length of strap should be long enough to reach around the item at the position to be strapped and there should be an overhang of at least 50 cm. - Page 9 5. Strap tensioning Now, the left hand guides the strap. The right hand holds the tool motor and depresses the lever at its rear 3. Placing the strapping tool left end until the desired tension has unto the strap. been obtained. Hold the free strap end with your In order to obtain a repeatable strap left hand and press down the lever...
-
Page 10: Specifications
PneumoLash Maintenance The clamp plate 040-053 requires daily cleaning from strap residue either by com- pressed air, wire brush or another suitable mechanical accessory. More frequent cleaning may be indicated depending on the strap used or frequency of applica- tion. Otherwise the PneumoLash strapping tool requires no service.
