POSITIONING THE VENDING MACHINE

The vending machine is not suitable for outdoor installa-
tion. It must be positioned in a dry room where the
temperature remains between 2°C and 32°C, and not
where water jets are used for cleaning (e.g. in large
kitchens, etc.).
The machine should be placed close to a wall, so that the
back panel is at a minimum distance of 4 cm from it and
correct ventilation may be ensured. The machine must
never be covered with cloth or the like.
The machine should be positioned with a maximum incli-
nation of 2°.
If necessary provide proper levelling by way of the adjust-
able feet included.
Important notice!!
Access to the machine interior for maintenance and/or
repairs is via the back panel.
Therefore the machine is designed to be rotated, thus
allowing removal of the back panel.
Installation on the cabinet
The machine can be installed on a table or on any other
suitable stand (recommended height is 820).
If possible, it is advisable to use the special cabinet, which
can house the liquid waste tray, the water supply kit, the
payment system and, in the case of very hard water, the
softener unit.

WARNING FOR INSTALLATION

The machine installation and the following mainte-
nance operations should be carried out by qualified
personnel only, who are trained in the correct use of
the machine according to the standards in force.
The machine is sold without payment system, therefore
the installer of such system has sole responsibility for any
damage to the machine or to things and persons caused
by faulty installation.
The integrity of the machine and compliance with the
standards of the relevant systems must be checked at
least once a year by qualified personnel.
All packing materials shall be disposed of in a manner
which is safe for the environment.

PRECAUTIONS IN USING THE MACHINE

The following precautions will assist in protecting the
environment:
- use biodegradable products only to clean the ma-
chine;
- adequately dispose of all containers of the products
used for loading and cleaning the machine;
- switch the machine off during periods of inactivity,
thus achieving considerable energy savings.
© by NECTA VENDING SOLUTIONS SpA

WARNING FOR SCRAPPING

Whenever the machine is to be scrapped, the laws in force
regarding environment protection should be strictly ob-
served. More specifically:
- ferrous and plastic materials and the like are to be
disposed of in authorized areas only;
- insulating materials should be recovered by qualified
companies.

TECHNICAL SPECIFICATIONS

DIMENSIONS
Height
Height with container
Width
Depth
Overall depth with door open
Height of cabinet
Weight
C
l o
b i
ì r
K
. g
Power supply voltage
Power supply frequency
Installed power
3
=
650
mm
=
740
mm
=
410
mm
=
490
mm
=
830
mm
=
820
mm
E
s
p
e r
s
s
o
n I
s
a t
3
8
3
3
~
230 V
50 Hz
1850 W
01-2003 197 00
