Rowe 650 Field Service Manual And Parts Catalog

Showcase merchandiser
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R
650
Showcase Merchandiser
Field Service Manual
and
Parts Catalog
Including Direct Access
Programming Instructions
Part No. 90065001
First Edition
August 1996
900-65001 A
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 650 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rowe 650

  • Page 1 Showcase Merchandiser Field Service Manual Parts Catalog Including Direct Access Programming Instructions Part No. 90065001 First Edition August 1996 900-65001 A...
  • Page 2 900-65001 A...
  • Page 3 Section 6 is an illustrated parts catalog that can be used to identify parts available for purchase from your Rowe distributor. Keep a copy of this manual with the vendor at all times for reference. Part Number 900-65001 A...
  • Page 4 This page intentionally left blank. 900-65001 A...

  • Page 5: Table Of Contents

    Refrigeration ............ 5-18 Service Mode Map ..........3-3 Power Supply Indicator Lights ......5-19 Numeric Keypad ..........3-4 650 System Schematic ........5-20 Navigating the Menu Structure ......3-4 Universal Controller Board ......5-22 Direct Access ............ 3-4 Power Supply ..........5-26 Quick Reference Guide ........
  • Page 6 SPECIFICATIONS: 650 Showcase Merchandiser GENERAL Depth .................. 30 in. Width .................. 44 in. Height ................. 72 in. Net Weight ................. 800 lb. Shipping Weight ..............825 lb. Maximum Location Ambient Temperature ......100 F @ 25% Relative Humidity POWER REQUIREMENTS Voltage ................

  • Page 7: How To Use This Manual

    Described below is a brief outline of the numbered sections and the information discussed there. SECTION 1 - DESCRIPTION - Section 1 contains a general introduction to the 650 Showcase Merchandiser. It provides descriptions of the major components and features of the machine and a listing of point of sale messages.

  • Page 8: Coin Mech. Chart

    COIN MECH. CHART ROWE VENDING MACHINE COIN MECH USAGE 548/ 550/ Coin Acceptors 5900 6 PUMP 8 PUMP Coinco WO\BA W\BA WO\BA W\BA W.A.D. WO\BA W\BA W.A.D. Single Price $12.75 Max 9300S 120 VAC Single Price $12.75 Max 9340S 120 VAC...

  • Page 9: Features

    650 Features MESSAGE CENTER FLEXIBLE PRICING The 650's message center has a 20 character vacuum The 650 offers flexible pricing, up to $99.95, settable fluorescent display that can scroll up to 255 characters. in increments of 5¢ (U.S. and Canadian). Prices are set It can be programmed to display a custom message, the directly using the numeric keypad.
  • Page 10 This page intentionally left blank. 900-65001 A...

  • Page 11: Introduction

    As a safety precaution the inner delivery door will not close if the outer delivery door is open. Audit Data The 650 provides detailed audit information in a printed or displayed format. Audit data includes vital diagnostic information, and sales information such as total cash collected and sales totals. Audit information is accessed by entering the appropriate code in the service menu (Refer to Section 3).

  • Page 12: Delivery Doors

    Delivery Doors The 650 incorporates a dual delivery door system. The outer delivery door spans the width of the delivery section. Each of the six inner delivery doors, called baffles, accesses one 4" shelf section. When an item is selected for purchase the baffle corresponding to the purchased item is opened.

  • Page 13: Service Door

    Description - 1 Service Door The service door provides access to the slide-out service panel, main door latches, and the conveyor motor assembly. It also houses the message center, coin mech, bill acceptor, and cash box. When the service door is unlatched, the machine is automatically placed in the service mode. In the service mode the operator can access all of the programming functions using the keypad on the message center.

  • Page 14: Universal Control Board

    The Rowe Universal Control Board is the “brain” of the 650 General Merchandiser. The UCB controls all of the 650’s peripheral devices, such as the coin mech, bill acceptor and refrigeration unit, as well as all of the vending functions and special features. The Universal Control Board also collects and stores vital machine information, such as error messages and audit data.

  • Page 15: Shelves

    Shelves The 650 vends product from a series of sixteen 24" horizontal shelves which can be rotated up or down by the customer. Each shelf is divided into six 4" sections. The shelves can be easily configured, by removing or adding shelf dividers, to house any combination of 4"...

  • Page 16: Connector Panel

    650 Showcase Merchandiser Connector Panel The connector panel houses the main door switch, as well as the harness quick-disconnects for the main door. This allows the main door to be quickly removed if necessary. Main Power Switch Assembly The main power switch assembly (Figure 1-6) is located at the lower left side of the cabinet interior. It houses the main power switch, the refrigeration power circuit breaker, the vend power circuit breaker and the refrigeration interlock switch.

  • Page 17: Drive Mechanism

    Description - 1 Drive Mechanism The shelves are mounted on individual carrier assemblies, which travel on a fixed guide track. The carriers are connected to drive chains, which are turned by drive sprockets. The drive sprockets are powered by a 24V motor located in the service compartment.

  • Page 18: Refrigeration System

    650 Showcase Merchandiser Refrigeration System The self-contained refrigeration unit is designed to slide in and out of the vendor as a complete assembly. A normal 3 pin AC power cord supplies power to the compressor, the evaporator blower, and the condenser fan. During the normal operating cycle and also during the defrost cycle, the evaporator blower runs continuously, regardless of the temperature inside of the refrigerated compartment.

  • Page 19: Backup Temperature Control

    Description - 1 Backup Temperature Control The backup temperature control knob should be set at ‘4’. Under normal circumstances, the temperature of the vendor is controlled by the UCB, and is kept within the parameters described above. Backup Refrigeration Circuit During normal operation, the backup relay, located in the refrigeration control compartment, is held energized by electronics on the power supply board and controlled by signals from the Universal Control Board.

  • Page 20: Point Of Sale Messages

    Machine ID = xxxxxx - Machine ID = xxxxxx - Displays Machine ID number when Hot Key RESET + 4 is pressed. Rowe 650 V X. X - Rowe 650 V X. X - Rowe 650 V X. X - Rowe 650 V X.
  • Page 21 To use the hot keys, refer to the chart below. Press and hold down the RESET key, then press one of the key numbers from the chart below. Release both keys. The Message Center will now display the desired information. 650 HOT KEYS RESET + 0 Date &...

  • Page 22: Health Control

    650 Showcase Merchandiser Health Control When the 650 is configured as a refrigerated vendor, it employs a health control feature to monitor the interior cabinet temperature. After opening and closing the main door, the refrigeration unit has 30 minutes to bring the temperature below 45 F, the machine will go out of service.

  • Page 23: Installation

    Section 2: INSTALLATION INTRODUCTION This section contains instructions for unpacking the 650 General Merchandiser and installing it on location. Installation is quick and easily accomplished. Unpacking Instructions The vendor is shipped in one carton with all major assemblies in place, ready for installation. The shipping carton should be opened carefully to prevent the merchandiser from being scratched or damaged.

  • Page 24: Shelf Dividers

    “ROWE 650 - REV X” “ROWE 650 - REV X” b) “ROWE 650 - REV X” “ROWE 650 - REV X” “ROWE 650 - REV X” (X = latest revision EPROM on UCB) {Then} c) “TESTING RAM TESTING RAM TESTING RAM TESTING RAM”...

  • Page 25: Selection And Price Labels

    Installation - 2 To install the selection number labels, start with the home shelf. Install the selection number label 101 in the leftmost position of that shelf. If the entire shelf is configured as single compartments, i.e., 6 selections, then install the next selection number label, 201, followed by 301, etc.

  • Page 26: Coin Mech Loading

    Press Reset + 7 to toggle on/off. Set to ON. Load coins tubes, the totals must be through side loading tubes. The 650 will then automatically entered in the Service sense that coins are available to make change.

  • Page 27: Pre-Operation Check

    Installation - 2 PRE-OPERATION CHECK NOTE: If you have a refrigerated machine, allow the temperature to stabilize between 34° - 39° F before loading temperature sensitive product. 1. Perform the Basic Program Setup routine located in Section 3. 2. Close all machine doors. “INSERT MONEY” or other vending mode messages should display if all parameters were set correctly and no errors exist.
  • Page 28 650 Showcase Merchandiser This page intentionally left blank. 900-65001 A...

  • Page 29: Programming

    Figure 3-1. Numeric Keypad INTRODUCTION Rowe is proud to introduce a new interface that combines a menu driven interface with a direct access interface. An ‘interface’ is the method that an operator uses to interact with the electronics to set programmable options and retrieve information from the controller.

  • Page 30: Service Menu

    650 Showcase Merchandiser * SERVICE MENU * Entering the Service Menu The service mode is the programming interface that allows the operator to gain access to the programmable features of the machine. It is the starting point for all programming functions. The service menu is divided into 18 sub-menus.

  • Page 31: Service Mode Map

    Programming - 3 90701102 KEY FUNCTIONS RESET + 0 = Line UP RESET + 1 = Line DOWN RESET + 2 = Move RIGHT RESET + 3 = Move LEFT RESET + 4 = Delete RESET + 5 = Insert RESET + 6 = Copy RESET + 7 = Next/Toggle RESET + 8 = Enter...

  • Page 32: Numeric Keypad

    650 Showcase Merchandiser Numeric Keypad HOLD RESET FOR FUNCTION The keypad can be used to access either interface, Direct Access or Menu. By entering numeric codes the operator can directly program desired selections. To navigate the menus using the keypad, press the RESET key while pressing the keys listed in Table 3-1 and Figure 3-4.

  • Page 33: Quick Reference Guide

    Clear Audit Data Basic Program Setup The following list of instructions will explain how to quickly place the 650 Showcase Merchandiser into operation without programming any of the optional features. 1) Remove and/or install shelf dividers as required for all 16 shelves (See Section 2).

  • Page 34: Audits Menu

    650 Showcase Merchandiser * AUDITS MENU * This menu contains commands that allow you to view and manipulate sales and revenue data. To access the Audits menu, enter the service mode and use the directional keys on the keypad to maneuver to the Audits menu.
  • Page 35 Audits Menu Continued . . . PRINT AUDIT DATA - Press the enter key (Reset + 8) to send all of the audit information to a remote printer. Connecting to a printer requires a printer harness, P/N 593-1800, available from Rowe distributors.

  • Page 36: Sales Sub-Menu

    650 Showcase Merchandiser * SALES SUB-MENU * The Sales sub-menu displays sales information in monetary units. The items listed in this menu cannot be changed in this menu. To access the Sales sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Sales sub-menu.

  • Page 37: Cash Sub-Menu

    Programming - 3 * CASH SUB-MENU * This menu contains itemized coin totals for coins in the cashbox and bills in the stacker. Coins in the coin tubes are not included in these totals. These totals cannot be modified in this menu. To access the Cash sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Cash sub-menu.
  • Page 38 650 Showcase Merchandiser Cash Sub-Menu Continued . . . 117: FIVES - This line displays the number and value of Five dollar bills in the bill stacker. This total is cleared when the Empty Bill Accept command is executed. This total is not cleared when the Clear Audit Data command is executed.

  • Page 39: Vend Data Sub-Menu

    Programming - 3 * VEND DATA SUB-MENU * This menu contains sales information, detailing the number of sales made according to various price and time schedules. The totals in this menu cannot be modified in this menu. To access the Vend Data sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Vend Data sub-menu.
  • Page 40 650 Showcase Merchandiser Vend Data Sub-Menu Continued . . . 127: Free Vends - This line displays the number of items free vended since the last time that Audit Data was cleared. 128: Total Vends - This line displays the total number of vends made since the last time that Audit Data was cleared.

  • Page 41: Coin Tubes Sub-Menu

    Programming - 3 * COIN TUBES SUB-MENU * This menu displays the number and value of coins in the coin tubes. Coin tube totals can be adjusted in this menu. To access the Coin Tubes sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Coin Tubes sub-menu.
  • Page 42 650 Showcase Merchandiser Coin Tubes Sub-menu Continued . . . 135: EMPTY COIN TUBES - This function completely empties the coin mech payout tubes. Using this function will reset all coin counts to ‘0’. Do not use this command unless you intend to empty the coin tubes.

  • Page 43: Options Menu

    Programming - 3 * OPTIONS MENU * This menu contains the commands that enable and disable the various machine options. To access the Options menu, enter the service mode and use the directional keys on the keypad to maneuver to the options menu.
  • Page 44 650 Showcase Merchandiser Options Menu Continued . . . To activate the multiview feature press the Next/Toggle key (Reset + 7) to select MULTIVIEW - If OFF is selected, the feature will be disabled. If ON is selected, multiview will be active all the time.

  • Page 45: Setup Menu

    31: COIN ACCEPTOR (Sub-menu) - The Coin Acceptor Sub-menu allows the operator to select the type of coin mech to be used with the 650. Press the Enter key (Reset + 8) to enter the Coin Acceptor sub-menu. The options for this function are Dumb, Exec, and None.
  • Page 46 650 Showcase Merchandiser Set Up Menu Continued . . . TEMPERATURE OPERATION CHART Use For Low Temperature High Temperature Health Temperature U. S. A. 34º F 41º F 45º F Europe 1º C 3º C 8º C Europe 3º C 5º...
  • Page 47 Programming - 3 Set Up Menu Continued . . . 35: SET MESSAGE - This command is used to set the POS message on the customer display. The point of sales message will be displayed when the machine is idle. To select the type of message to be displayed, refer to menu item 27.

  • Page 48: Bill Acceptor Sub-Menu

    650 Showcase Merchandiser * BILL ACCEPTOR SUB-MENU * This menu contains a command that allows the operator to enable or disable the bill acceptor. To access the Bill Acceptor Sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Bill Acceptor Sub-menu.

  • Page 49: Coin Acceptor Sub-Menu

    Figure 3-14. Coin Acceptor Sub-Menu 310: ACCEPTOR TYPE - DUMB - This command allows the operator to select the type of Coin Acceptor installed in the 650. The choices are: Dumb (Used in U.S. & Canadian machines) Exec (Used in export machines), and None.

  • Page 50: Initialize Sub-Menu

    650 Showcase Merchandiser * INITIALIZE SUB-MENU * This menu contains commands that allow the operator to return the vendor to factory defaults, i.e., initialize the vendor. To access the Initialize Sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Initialize Sub-menu.
  • Page 51 Programming - 3 Figure 3-16 . 650 Factory Test Configuration and Pricing Chart 3-23 90065001...

  • Page 52: Price Menu

    Figure 3-17. Price Menu 40: FLEX VEND (Sub-Menu) - The Flex Vend menu contains commands for scheduling various events for the 650. Press the Enter key (Reset + 8) to access the flex vend menu.. 41: SET PRICES - This command is used to set or change prices of the configured compartments.
  • Page 53 .05, so they must end with a 5 or a 0. Any other price will be invalid. g) The 650 remembers the last entered price. Press RESET + 7 to toggle between the last entered price and the current price. Press RESET + 6 or RESET + 8 to store the displayed price.
  • Page 54 650 Showcase Merchandiser Price Menu Continued . . . 46: ADJUST STOCK - This command is used to add stock to or remove stock from compartments. It can be used to change SOLD compartments to FULL when only a few new items are to be added to the vendor.

  • Page 55: Flex Vend Sub-Menu

    RESET + = Shelf # DOW N Figure 3-19. Flex Vend Menu Flex Vend Description and Operation Flex Vend is a method of scheduling various events for the 650 Showcase Merchandiser. 25 (0-24) events per weekday may be scheduled. Programming an event involves the following:...
  • Page 56 650 Showcase Merchandiser Flex Vend Sub-Menu Continued . . . For Flex Vend, the week starts at SUN 00:00, or midnight on Saturday night. At the week start, all of the events set by Flex Vend are set to the Flex Vend Defaults. These defaults may be programmed.
  • Page 57 Programming - 3 Flex Vend Sub-Menu Continued . . . Event Options Events are entered with the number keys and modified with the Next/Toggle key (Reset + 7). The event number is actually a category of events. The Next/Toggle key (Reset + 7) cycles through the optional settings.
  • Page 58 650 Showcase Merchandiser Flex Vend Sub-Menu Continued . . . When an event is selected, pressing the Enter key (Reset + 8) will advance to the next Flex Vend Slot. When an event is selected, pressing the Delete key (Reset + 4) will delete the current Flex Vend slot and move all subsequent entries up one slot.
  • Page 59 Programming - 3 Flex Vend Sub-Menu Continued . . . 3 FREE VEND Options: 4 MULTIVIEW Options: 5 LOCKOUT Options: LOCKOUT ON LOCKOUT OFF SHUTDOWN NOTE: Shutdown may not be cleared by Flex Vend and will require a service call to put the machine back into service.
  • Page 60 650 Showcase Merchandiser Flex Vend Sub-Menu Continued . . . 404: ERASE SCHEDULE - Use this command to erase all or part of the Flex Schedule. ERASE DAYS - SMTWTFS A typical display reads like this: All of the days shown will be erased.

  • Page 61: Status Menu

    Programming - 3 * STATUS MENU * This menu contains commands that allow the operator to view and clear errors. To access the Status menu, enter the service mode and use the directional keys on the keypad to maneuver to the Status menu.
  • Page 62 650 Showcase Merchandiser Status Menu Continued . . . Figure 3-21. Maneuvering around the spreadsheet. 53: CLEAR ERRORS - This command clears all errors from the error log. 54: TIME OVER HEALTH - This line displays the amount of time that the machine has been at a temperature that exceeds 45°...

  • Page 63: Diagnostics Menu

    Programming - 3 * DIAGNOSTICS MENU * This menu contains commands that allow the operator to view various diagnostic reports and perform diagnostic functions. To access the Diagnostics menu, enter the service mode and use the directional keys on the keypad to maneuver to the Diagnostics menu. Follow the path indicated below, or press ‘6’ on the keypad.
  • Page 64 650 Showcase Merchandiser Diagnostics Menu Continued . . . 64: TEMP IS xxF xxC * CH - This entry displays the current cabinet temperature in Fahrenheit and Celsius. The blinking ‘*’ is the watchdog toggle. ‘C’ after the ‘*’ indicates that the compressor is on.

  • Page 65: Machine History Sub-Menu

    Programming - 3 * MACHINE HISTORY SUB-MENU * This sub-menu contains commands that allow the operator to view data regarding the machine's perfor- mance. To access the History Sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the History Sub-menu.
  • Page 66 650 Showcase Merchandiser Machine History Sub-Menu Continued . . . 605: POWER ON TIMES - This line displays the dates and times that power was applied to the machine, i.e., the main power switch was turned ON. Press the Enter key (Reset + 8) to view the first line in this list. Press the Move Right (Reset + 2) or the Move Left (Reset + 3) key to move up or down through the list of ‘power on’...

  • Page 67: Baffles/Shelves Sub-Menu

    Programming - 3 * B A F F L E S / S H E L V E S S U B - M E N U * This sub-menu contains commands that allow the operator to test the operation of the baffle assembly. To access the Baffles/Shelves Sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Baffles/Shelves Sub-menu.
  • Page 68 650 Showcase Merchandiser Baffles/Shelves Sub-Menu Continued . . . 612: LOCKOUT BAFFLE - This feature allows one or more baffles to be “locked-out” or disabled. This makes it possible for a non-functioning baffle to be disabled so the rest of the machine can remain in operation until repairs can be completed.

  • Page 69: Refrigeration Sub-Menu

    Programming - 3 * REFRIGERATION SUB-MENU * This sub-menu contains entries that allow the operator to track the performance of the refrigeration unit. To access the Refrigeration Sub-menu, enter the service mode and use the directional keys on the keypad to maneuver to the Refrigeration Sub-menu.
  • Page 70 650 Showcase Merchandiser This page intentionally left blank. 3-42 90065001...

  • Page 71: Maintenance

    INTRODUCTION This section will explain how to perform routine maintenance, make necessary adjustments and replace key components of the 650 Showcase Merchandiser. Cleaning Maintain the beauty of the Merchandiser and project the best selling image to the customer by cleaning the machine at regular intervals.

  • Page 72: Drive Motor Assembly

    650 Showcase Merchandiser Drive Motor Assembly The drive motor has one adjustment screw that is used to adjust the stopping position of the shelves. To make the shelves stop higher in relation to the delivery door, turn the adjustment screw clockwise. To make the shelves stop lower, turn the adjustment screw counterclockwise.
  • Page 73 Adjusting Drive Chain Tension In order for the 650’s drive mechanism to function properly, be sure that the drive chain is kept tight. As a result of normal use, it may be necessary to adjust the drive chain tension. Follow the steps below.

  • Page 74: Replacing Baffle Motors

    650 Showcase Merchandiser Replacing Baffle Motors Occasionally it may become necessary to replace a baffle drive motor. Replacing the motor is easily accomplished by following the steps below. 1. Remove the 4 screws that attach the baffle security cover. Lift the cover up and out and remove it from the machine.

  • Page 75: Removing The Baffle Assembly

    Maintenance - 4 Remove Baffle Assembly To remove the Baffle Assembly follow the directions below. 1. Remove the 4 screws that attach the baffle security cover. Lift the cover up and out and remove it from the machine. 2. Disconnect the 2 main harnesses from the opto-circuit board. 3.

  • Page 76: Baffle Height Adjustment

    650 Showcase Merchandiser Baffle Height Adjustment To adjust the baffle height, it is necessary to properly position the opto-circuit board so all the baffles close completely. 1. Remove the baffle security cover. 2. Raise the baffles to their UP position. Press 610.
  • Page 77 Maintenance - 4 Lower Glass Retainer Loosen these screws to adjust baffle height Figure 4-7. Baffle Height Adjustment 900-65001 A...

  • Page 78: Fluorescent Lamp Replacement

    650 Showcase Merchandiser Change the Fluorescent Lamp Located in the Door 1. Remove the 5 screws securing the lamp access panel. 2. Remove the lamp access panel. 3. Remove the light diffuser. 4. Remove the lamp from the front of the vendor.
  • Page 79 Maintenance - 4 Replacing the Heated Insulated Glass Assembly 1. Remove the 5 screws securing the lamp access panel. 2. Remove the lamp access panel. 3. Remove the light diffuser. 4. Remove each of the vertical glass retainers. See Figure 4-9. 5.
  • Page 80 650 Showcase Merchandiser This page intentionally left blank. 4-10 900-65001 A...

  • Page 81: Table Of Contents

    Refrigeration ....................5-11 Refrigerant Charge Troubleshooting ............5-14 Schematics Refrigeration ....................5-18 Power Supply Indicator Lights ................. 5-19 650 System Schematic ................... 5-20 Universal Control Board .................. 5-22 Power Supply ....................5-26 Message Center Display Board ..............5-28 Baffle Board ....................5-30 Optical Sensor ....................

  • Page 82: Introduction

    650 Showcase Merchandiser INTRODUCTION This section contains a preliminary check list and two troubleshooting charts. The first chart lists Error Messages which will be shown on the Message Display Center when in the Service Mode. The second lists possible problems and suggested solutions.

  • Page 83: Error Messages

    For a listing of the Error Messages see the Troubleshooting Chart - Error Messages. To view and clear Error Messages see Service Mode Operation, Figure 3-3. The 650 has self diagnosing software to identify problem conditions. The operator is alerted using error messages rather than error codes.

  • Page 84: Initial Power Up

    Message Center harness should be tested to ensure that power is being supplied. When the UCB software starts up, it sends a 650 software revision identification message to the Message Center for a few seconds. Following this, the display will read ‘TESTING RAM’...
  • Page 85 Troubleshooting - 5 Coin Mechanisms 1. +5 VDC 2. 5V RTN 3. Send 120V Models - 12 or 15 Pin 4. Int MARS TRC - 6000 5. Data COINCO 9300L 6. Accept Enable 7. Dis $.25 8. Dis $10 24V Models - 15 Pin Only 9.

  • Page 86: Error Messages

    650 Showcase Merchandiser Troubleshooting Chart Error Messages RROR ESSAGE ESSAGE EANS ROBABLE AUSE “HEALTH “HEALTH “HEALTH “HEALTH “HEALTH TIME TIME TIME TIME TIME ERROR” ERROR” ERROR” ERROR” ERROR” Unit did not pull down to 45 F or less Machine too close to the wall during the 30-minute period.
  • Page 87 Troubleshooting - 5 Troubleshooting Chart Error Messages RROR ESSAGE ESSAGE EANS ROBABLE AUSE “shelf “shelf “shelf “shelf “shelf motor motor motor motor motor overload” overload” overload” Running current was detected to be overload” overload” Improperly loaded product greater than its allotted percentage of the starting current.

  • Page 88: Coin Mech Socket

    650 Showcase Merchandiser Troubleshooting Chart Problem/Solution ROBLEM ROBABLE AUSE OLUTION DOES NOT ACCEPT COINS Missing Power or Data Signals Check Coin Mech Socket, UCB (P8) and P/S (P6) Blown fuse Check Fuse F1 on P/S Board Defective Coin Mech Replace...

  • Page 89: Problem/Solution

    Troubleshooting - 5 Troubleshooting Chart Problem/Solution ROBLEM ROBABLE AUSE OLUTION NO DISPLAY ON No Power to Message Center Check for +5VDC at Message Center MESSAGE CENTER between Pin 1 (+5V) and Pin 10 (ground). Point of Sale Message Option ON, but Set this option to OFF.
  • Page 90 650 Showcase Merchandiser Troubleshooting Chart Problem/Solution ROBLEM ROBABLE AUSE OLUTION BAFFLES DO NOT OPEN Shelf configuration not correct Reconfigure Shelf (Press 34) Compartment in Sold Condition Rotate the Conveyor one full revolution Invalid selection Check Shelf Configuration No Power to the Baffle Board Reconnect or test motor.

  • Page 91: Refrigeration

    Troubleshooting - 5 Troubleshooting Chart Refrigeration ROBLEM ROBABLE AUSE OLUTION MACHINE IS IN SHUTDOWN Manual Shutdown Active Set to OFF. Press 25. Auto Shutdown Active Check Flex-Vend Programming CONFIGURATION CHANGES Two or More Shelves have a Magnet Check for more than one Magnet BY ITSELF Assembly Assembly on Shelves.

  • Page 92: Refrigeration

    650 Showcase Merchandiser Troubleshooting Chart Refrigeration ROBLEM ROBABLE AUSE OLUTION REFRIGERATION INOPERATIVE Refrigeration Interlock Switch is not Close and latch Main Door. Listen for Actuating or is Defective Evaporator Blower Motor to start. If it runs, switch is OK. If it doesn’t run, check wiring to switch and main door latch adjustment.
  • Page 93 Troubleshooting - 5 This page intentionally left blank. 900-65001 A 5-13...
  • Page 94 50 - 60%, AND refrigerated compartment temperature in normal range (35º - 41ºF). Every refrigeration unit used in the Rowe 650 Showcase Merchandiser is carefully assembled and subjected to a variety of tests, including evaluation to 50 Microns, with a maximum rise over a 5 minute period to 500 Microns.
  • Page 95 Troubleshooting - 5 Refrigerant Charge Troubleshooting READING THE PRESSURES Read the high and low side pressures. If the pressures do not appear to be normal, check the high to low side ratio. The formula is 4.45 £ (P ) £ 5.54 ) / (P HIGH Where P...
  • Page 96 650 Showcase Merchandiser Refrigerant Charge Troubleshooting ROBLEM PRESSURE READINGS ROBABLE AUSE OLUTION HIGH SIDE LOW SIDE Low airflow across condenser Check air intake screen, rear output screen TOO HIGH Defective fan motor or fan blade Replace defective component Lint, dust, or dirt blocking condenser...
  • Page 97 NOTE: Rowe recommends that any time the refrigerant system is opened for parts replacement or leak repair that the liquid line drier be replaced. Be sure to replace the drier with one of the same type and capacity.
  • Page 98 650 Showcase Merchandiser Refrigeration Schematic REFRIG PLUG COND FAN COMP EVAP BLOWER EVAP HEATER #1 EVAP HEATER #2 PAN HEATER WH/RD WH/OR WH/OR 2 4 VD C 2 4 VD C 24 VD C BACKUP REFRIG DEFROST NOTE - All Relays are...

  • Page 99: Power Supply Indicator Lights

    Troubleshooting - 5 Power Supply Indicator Lights +24 V DC +5 VDC Power Supply Assembly 55001890 -24 VDC +24 VPDC LIGHTS REFRIGERATION CONTROL DEFROST SHELF DIRECTION SHELF DRIVE COMPRESSOR Figure 5-3. Power Supply Indicator Lights Indicator Name Color Status Function +24VDC Green Always ON...

  • Page 100: System Schematic

    650 Showcase Merchandiser VOLTAGE SELECTOR PLUGS 5 5 02 1 51 0 240V 220V 120V TRANSFOR ME R A N D BR/W BR/W FIL TE R AS SEM BLY BR/W W/BL W/BL W/BL 55001891 T RANSFORMER 120V 55001886 55001885 55001884...
  • Page 101 CO I N 9 PI N BAFFLE DRIVE 3 BAFFLE DRIVE 2 PLU G MECH BR/W BAFFLE DRIVE 1 Y/BR 16 P IN PLU G 55101810 EXPORT WITH EXECUTIVE COIN M ECH ONLY Figure 5-4. 650 System Schematic 900-65001 A 5-21...
  • Page 102 650 Showcase Merchandiser U 8 A 1489 MESSAGE CENT ER +1 2 SPEAKER U 2 A 14 8 8 1 0Mh z C 28 22pF 2 2p F 15 u F U 2 B U 1 1 A 7 4 H C 1 4...
  • Page 103 Troubleshooting - 5 D [0 ..7 ] D [0..7 ] A[0 ..15 ] A[0..3] U 1 4 2 7 C 51 2 A1 1 A1 3 VC C A1 4 GN D 1 4 A1 5 IN S U 18 A U 1 0A 74 H C 0 8 74HC14...
  • Page 104 650 Showcase Merchandiser H EALTH U17A LM324 TEMPIN +5VD C AC H 3 23.2K 1% GN D TEMP D [0..7] D[0..7] R 13 R 14 34.8K 1% 100K 1% A[0..3] A[0..3] U 17B LM324 AC H 2 R 12 499 1%...
  • Page 105 Troubleshooting - 5 U 1 0 E 74HC14 CD40107 U 5 A 74HC157 1N4148 PS2501-2 J 1 3 MS1 60 0 /SER IAL T X- MS1 6 00 (B) R X+ U 5B GN D SD ATA 1 80 SC L OC K AU X SER IAL SCTS U 1 0F...
  • Page 106 650 Showcase Merchandiser NEUTRAL 3AG-2 FI L TE RE D 1N4004 1N4004 AC IN 5AMP156 1N4004 1N 4004 1N 4004 1N4004 .01uF J 10 470uF 18V .5A FR OM 1N 4004 1N4004 18V .5A TR ANSFORM ER 5V .5A 5V .5A...
  • Page 107 Troubleshooting - 5 TO BILL NEUT RAL ACC EPTOR HO T +120V PDC 120V COIN M ECH SUP PLY -120V PDC DOM ESTIC +24V PDC M ECH . -24V PDC 11AMP156 3.3K GLED -24V DC 24V AC 24 VAC EXEC. M ECH. 24 VAC 24V AC 2AMP156...
  • Page 108 650 Showcase Merchandiser C.T. -3 0 V DC -37 VDC CPS1223N 47UF 47UF .1UF .1UF VDIS .1UF DOUT ENBL 47UF O.10 .1UF O.11 BLNK O.12 22UF O.13 O.14 O.15 O.16 22UF T1OUT O.17 T1IN O.18 T2OUT T2IN 22UF O.19 R1IN O.20...

  • Page 109: Message Center Display Board

    Troubleshooting - 5 COMA FIP20B6R 74LS156N RP1H 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 For Equivalent Engineering Drawing, See 28096900 Figure 5-7. Message Center Display Board 900-65001 A 5-29...
  • Page 110 650 Showcase Merchandiser 24VDC 5VDC 20 UF SEL DOWN SEL UP 20 UF .1 UF 4.7 K 4.7 K 4.7 K 5 VDC 5VDC .1 UF SELECT BAFFLE 1 OUT BAFFLE 2 OUT MOT OR BAFFLE 3 OUT RET URN...
  • Page 111 Troubleshooting - 5 24VDC 5VDC 24VDC 5VDC 2.2 K 2.2 K 2.2 K 2.2 K 1/2 W 1/2 W 1/2 W 1/2 W SEL UP SEL UP LM339 LM339 47 K 47 K LM339 LM339 47 K 47 K VREF VREF OUT 1 OUT 2...

  • Page 112: Optical Sensor

    650 Showcase Merchandiser Optical Sensor Schematic CON3 GREEN LED 3.3K 2N2222 H21A3 For Equivalent Engineering Drawing, See 28038300 Figure 5-9. Optical Sensor Schematic 5-32 900-65001 A...
  • Page 113 Fig. No. Description Pg. No. Optional Kits ....................6-2 Introduction ....................6-3 Ordering Replacement Parts ..............6-3 650 Trim Panels..................6-4 Main Door Assembly, Exterior ..............6-6 Main Door Assembly, Interior ..............6-8 Baffle Assembly ..................6-10 Delivery Door Assembly ................6-12 Main Power Switch ..................6-13 Service Door Assembly ................6-14 Message Center Assembly ..............6-16...

  • Page 114: Optional Kits

    Optional Kits Part No. Description Function 65079034 RBA-7 Bill Acceptor Allows 4-way Acceptance 548-06000 Printer Harness Kit Allows MIS retrieval via printer 551-06000 MARS VFM3 Adapter Kit MARS B/A Usage 900-65001 A...

  • Page 115: Introduction

    ORDERING REPLACEMENT PARTS This parts catalog contains a list of replacement parts All parts must be ordered from an authorized Rowe that are available for the vendor . Each list contains an Distributor. Parts orders are often delayed because of inadequate or incomplete ordering information.

  • Page 116: Trim Panels

    650 Showcase Merchandiser Fig. 1 650 Trim Panels 900-65001 A...
  • Page 117 650 Showcase Merchandiser Fig. 1 650 Trim Panels Index Rowe Imperial Award Series Description Genesis Crown All Walnut 2000 Trim - Door - Vertical 983-101 983-101 983-101 983-102 Overlay - Vertical L.H. 985-69-9 985-69-12 985-69-2 985-69-141 Trim - Door Vertical...

  • Page 118: Main Door Assembly, Exterior

    650 Showcase Merchandiser Fig. 2 Main Door Assembly, Exterior FRONT 24 VOLTS 900-65001 A...
  • Page 119 650 Showcase Merchandiser Fig. 2 Quantity Index Part Number Description Assembly 55001420 Main Door F/A 98300354 Retainer - Trim 50.5" 55000486 Plastic Light Shield (Lens) 55000472 Panel - Display, Right Side 55001410 Heated Insulated Glass Assembly 55001433 Delivery Door Assembly...

  • Page 120: Main Door Assembly, Interior

    650 Showcase Merchandiser Fig. 3 Main Door Assembly, Interior 14, 15 30, 31 900-65001 A...
  • Page 121 650 Showcase Merchandiser Fig. 3 Quantity Index Part Number Description Assembly 55001420 Door Final Assembly 55101401246 Door W/A 55100402 Bracket - Security, Top, Main Door 55101412 Lock Bracket W/A 55100413 Spring - Delivery Door 55000903 Rod - Spring Tension 55001413...

  • Page 122: Baffle Assembly

    650 Showcase Merchandiser Fig. 4 Baffle Assembly Top of Vendor 6-10 900-65001 A...
  • Page 123 650 Showcase Merchandiser Fig. 4 Quantity Index Part Number Description Assembly 55001432 Baffle Assembly 55001006 Baffle Plate Weld Assembly 55001007 Baffle & Flag Assembly 55000407 Guide - Baffle, L.H. 55000409 Guide - Baffle, R.H. 55000408 Guide - Baffle, Center 88684810 #10-24 x 5/8"...

  • Page 124: Delivery Door Assembly

    650 Showcase Merchandiser Fig. 5 Delivery Door Assembly Quantity Index Part Number Description Assembly 55001433 Delivery Door Assembly - Complete 55000639 Frame - Delivery Door 55000424 Seal - Delivery Door 55000425 Gasket - Delivery Door, Top 55000429 Strip - Delivery Door, Top...

  • Page 125: Main Power Switch

    650 Showcase Merchandiser Fig. 6 Main Power Switch Quantity Index Part Number Description Assembly 55001858 Switch Panel Assembly - Complete 301-01711 Switch, Main Line 939-01252 Insulation, Fishpaper - Main Line Switch 921-00287 Screw 950-00349 Lockwasher 912-00047 Circuit Breaker, Refrigeration Unit - 15 Amps...

  • Page 126: Service Door Assembly

    650 Showcase Merchandiser Fig. 7 Service Door Assembly Selection Coin Coin Return Insert Change Returned Below 6-14 900-65001 A...
  • Page 127 650 Showcase Merchandiser Fig. 7 Quantity Index Part Number Description Assembly 55101501 Service Door Final Assembly 50001025 Message Center Assembly 55101518 Latch - Message Center 55101516 Locking Cam R/A 55101510 Coin Insert and Return Assembly 55101508 Coin Mech Mounting Plate Assembly...

  • Page 128: Message Center Assembly

    650 Showcase Merchandiser Fig. 8 Message Center Assembly 6-16 900-65001 A...
  • Page 129 650 Showcase Merchandiser Fig. 8 Quantity Index Part Number Description Assembly 50001025 Message Center Assembly - Complete 50000101 Housing - Message Center 50000121 Overlay - Message Center 50001023 PCB Assembly - Keyboard 28096701 PCB Assembly - Display UCB 50001024 Harness Assembly - Message Center...

  • Page 130: Coin Mech Mounting Plate Assembly

    650 Showcase Merchandiser Fig. 9 Coin Mech Mounting Plate Assembly 6-18 900-65001 A...
  • Page 131 650 Showcase Merchandiser Fig. 9 Quantity Index Part Number Description Assembly 55101508 Coin Mech Mounting Assembly 55101509 Coin Mech Mounting Plate R/A 55100523 Latch - Coin Mech Slide 55100524 Bracket - Coin Mech Slide 55100525 Baffle - Coin Guide 55100526...

  • Page 132: Cabinet Assembly

    650 Showcase Merchandiser Fig. 10 Cabinet Assembly 6-20 900-65001 A...
  • Page 133 650 Showcase Merchandiser Fig. 10 Quantity Index Part Number Description Assembly 55101920 Cabinet Assembly 55101910 Sliding Panel 70712301 Slide - Jonathan 92100525 Screw - Machine 10-32 x 5/16" H 49000356 Guide - Slide Panel Rear 44812306 Screen - Rear Weld...

  • Page 134: Motor & Hub Assembly

    650 Showcase Merchandiser Fig. 11 Motor & Hub Assembly Quantity Index Part Number Description Assembly 55101802 Motor and Optic Switch Assembly 92100407 1/4-20 X 3/8" Machine Screw 55101801 Motor - Shelf 55000819 Plate - Motor Mounting 55001864 Optical Cycle Cam...

  • Page 135: Drive Assembly

    650 Showcase Merchandiser Fig. 12 Drive Assembly Quantity Index Part Number Description Assembly 55000102 Sprocket - 30 Tooth 55001000 Carrier Assembly - Left (See Figure 6-14 for Detail) 55001001 Carrier Assembly - Right (See Figure 6-15 for Detail) 55001914 Carrier Retainer Assembly...
  • Page 136 650 Showcase Merchandiser Fig. 13 Carrier Assembly - Left FRONT VIEW REAR VIEW Quantity Index Part Number Description Assembly 55001000 Carrier Assembly - L/H 55000106 Carrier - Shelf 55000105 Hub - Gear, Shelf, L/H 55000104 Gear, Idler, Small 55000109 Retainer - Hub, Shelf...

  • Page 137: Carrier Assembly - Right

    650 Showcase Merchandiser Fig. 14 Carrier Assembly - Right FRONT VIEW REAR VIEW Quantity Index Part Number Description Assembly 55001001 Carrier Assembly - R/H 55000106 Carrier - Shelf 55000103 Hub - Shelf, R/H 55000109 Retainer - Hub, Shelf 55000108 Roller - Shelf Carrier...
  • Page 138 650 Showcase Merchandiser Fig. 15 Shelf Assembly VIEW 8 (On Shelf 1 Only) $1.00 $.75 $1.50 $1.75 $1.00 $1.50 Quantity Index Part Number Description Assembly 55001600 Shelf Assembly 55000612 Product Shelf 55000607 Shelf Divider 55000609 Shelf Back 55000606 Latch 55000611...
  • Page 139 650 Showcase Merchandiser Fig. 16 Sliding Panel Assembly Quantity Index Part Number Description Assembly 55101910 Sliding Panel Assembly 55101911 Sliding Panel W/A 50001000016 Universal Control Board 55001890 Power Supply 55021510 Transformer Assembly 55101806 Ballast Assembly (U.S. & Canada) 55100801 Service Box...

  • Page 140: Power Supply Assembly

    Power Supply Assembly Quantity Index Part Number Description Assembly 62000101 CBA 650 Power Supply 59301817 MFAB Assembly - Base & Stud 93901502 Insulator - Fishpaper Whole 55000630 Cover - Power Supply 93400151 Screw - S/T #8 x 1/4" Type 2 92100258 Screw - #6-32 x 3/8"...

  • Page 141: Transformer Assembly

    650 Showcase Merchandiser Fig. 18 Transformer Assembly Quantity Index Part Number Description Assembly 55021510B Transformer and Bracket Assembly 91600071 Grommet 55001868 Transformer Assembly 55000578 Bracket - Transformer Mounting 92400054 Nut - #8-32 KEPS 70073609 Circuit Breaker - 6 Amp 70073605...

  • Page 142: Ballast & Socket Assembly

    650 Showcase Merchandiser Fig. 19 Ballast & Socket Assembly Quantity Index Part Number Description Assembly 55001425 Ballast & Socket Assembly 55000490 Bracket-Lamp Socket Mounting 97600018 Socket - Starter 85351608 #4 x 1/2 R.H.P.H. Self-Tapping Screw 97500549 Cable Tie 40801815 Ballast Assembly 85663006 #8 x 3/8"...

  • Page 143: Power Cord/Filter Assembly

    650 Showcase Merchandiser Fig. 20 Power Cord/Filter Assembly Quantity Index Part Number Description Assembly 50501815 Power Cord/Filter Assembly 50501837 Jumper - Ground 70713002 EMI Filter - 115-240V 15A 50501814 Power Cord Assembly 91600016 Strain Relief 93400151 Screw #8-32 x 1/4"...

  • Page 144: Refrigeration Unit Sheet 1

    650 Showcase Merchandiser Fig. 21 Refrigeration Unit, Sheet 1 Quantity Index Part Number Description Assembly 55001200 Refrigeration Unit - Complete 55001802 Power Cord 55001201 Base Weld Assembly 55001211 Blower Motor 55001209 Cover Evaporator 55001205 Cover Weld Assembly 55001212 Scroll 55001210...
  • Page 145 650 Showcase Merchandiser Fig. 22 Refrigeration Unit, Sheet 2 Quantity Index Part Number Description Assembly 55001200 Refrigeration Unit - Complete 55001205 Housing - Evaporator and Condenser Cover 55000241 Gasket - Evaporator Outlet 55001207 Evaporator Drip Tray Assembly 55001222 Evaporator 55000242...
  • Page 146 650 Showcase Merchandiser Fig. 23 Refrigeration Unit, Sheet 3 6-34 900-65001 A...
  • Page 147 650 Showcase Merchandiser Fig. 23 Quantity Index Part Number Description Assembly 55001200 Refrigeration Unit - Complete 55001201 Base - Refrigeration Unit W/A 55001202 Condenser 55000205 Shroud - Condenser Fan 50800219 Fan - Condenser 55000204 Bracket, Condenser Fan Mounting 59521515001 Motor, Condenser Fan...

  • Page 148: Opto-Circuit Board Assembly

    650 Showcase Merchandiser Fig. 24 Opto-Circuit Board Assembly, Sheet 1 6-36 900-65001 A...
  • Page 149 650 Showcase Merchandiser Fig. 24 Opto-Circuit Board Assembly, Sheet 2 Ref. Part Description Reference Number Capacitor - Monolithic Ceramic .1 µF 70028511 Capacitor - Electrolytic 50 VDC 22 µF 70028107 Capacitor - Electrolytic 50 VDC 22 µF 70028107 Capacitor - Monolithic Ceramic .1 µF...
  • Page 150 650 Showcase Merchandiser Fig. 24 Opto-Circuit Board Assembly, Sheet 3 Ref. Part Description Reference Number Relay - D.P.D.T. 24VDC 25195801 Relay - D.P.D.T. 24VDC 25195801 Relay - D.P.D.T. 24VDC 25195801 Relay - D.P.D.T. 24VDC 25195801 Relay - D.P.D.T. 24VDC 25195801 Relay - D.P.D.T.
  • Page 151 650 Showcase Merchandiser Fig. 24 Opto-Circuit Board Assembly, Sheet 4 Ref. Part Description Reference Number Resistor - Carbon Film W 5% 1 KW 79901102 560 W Resistor - Carbon Film W 5% 79901561 1K W Resistor - Carbon Film W 5%...

  • Page 152: Universal Control Board

    650 Showcase Merchandiser Fig. 25 Universal Control Board, Sheet 1 1 U10 ROWE INTERNATIONAL UNIVERSAL CONTROL BOARD ASSY 28001401 U24 C49 6-40 900-65001 A...
  • Page 153 650 Showcase Merchandiser Fig. 25 Universal Control Board, Sheet 2 Ref. Part Description Reference Number Capacitor - 15V 10% 15 µF 70025302 Capacitor - 50 V 10% .1 µF 70028649 Capacitor - 50 V 10% .1 µF 70028649 Capacitor - 50 V 10% .1 µF...
  • Page 154 650 Showcase Merchandiser Fig. 25 Universal Control Board, Sheet 3 Ref. Part Description Reference Number Capacitor - 35 V 10% 1 µF 70025301 Capacitor - 50 V 10% .1 µF 70028649 Capacitor - 35 V 10% 1 µF 70025301 Capacitor - 50 V 10% .1 µF...
  • Page 155 650 Showcase Merchandiser Fig. 25 Universal Control Board, Sheet 4 Ref. Part Description Reference Number Resistor - Carbon Film W 5% 1 KW 79901102 390 W Resistor - Carbon Film W 5% 79904391 Resistor - Carbon Film W 5% 1 KW...
  • Page 156 650 Showcase Merchandiser Fig. 25 Universal Control Board, Sheet 5 I.C. - UCB - Programmed GAL16V8 28027101 I.C. - Quad OP Amp LM324 30800216 I.C. - Quad 2 Input and Gate CMOS 74HC08 79940008 I.C. - Octal D-Flip Flop w/Clear...

  • Page 157: Power Supply Circuit Board

    650 Showcase Merchandiser Fig. 26 Power Supply Circuit Board Assembly, Sheet 1 900-65001 A 6-45...
  • Page 158 650 Showcase Merchandiser Fig. 26 Power Supply Circuit Board Assembly, Sheet 2 Ref. Part Description Reference Number Capacitor - Ceramic Disc 1 KV .01 µF 70022508 Capacitor - Ceramic Disc 1 KV .01 µF 70022508 Capacitor - Electrolytic 50 VDC 470 µF...
  • Page 159 650 Showcase Merchandiser Fig. 26 Power Supply Circuit Board Assembly, Sheet 3 Ref. Part Description Reference Number Header - Polarized .100 9-Position 70076409 Header - Polarized Locking Ramp .156 9-Position 70080509 Header - Polarized Locking Ramp .156 6-Position 70080506 Header - Polarized Locking Ramp .156 8-Position 70080508 Header - Polarized Locking Ramp .156 10-Position...

  • Page 160: Harness List

    650 Showcase Merchandiser Fig. 27 Harness List Harness Assembly Part Description Number Baffle Switch 55001432B Main Door 55001881 Heaters & Lamp 55101804 Ballast 55001844 UCB to Power Supply 55001894 Interconnect 55001898 Power Supply J1 55001855 UCB J12 to Printer & D...
  • Page 161 650 Showcase Merchandiser Index Index This section contains an index of the parts catalog. Index entries are sorted by part number and part name. Use this index to quickly locate parts in the parts catalog. Do not use the index to order parts. Use it only to locate the page on which a part is shown.
  • Page 162 Motor, Condenser Fan ..........6-35 59521515001 55001425 Ballast & Socket Assembly ........6-30 62000101 CBA 650 Power Supply ........... 6-28 55001428 Light Shield Retainer ..........6-9 62000301 Circuit Board Assembly - Baffle ......6-11 55001430 Lamp Access Assembly ..........6-9 65079034 RBA-7 Bill Acceptor ..........
  • Page 163 650 Showcase Merchandiser Index 70025301 Capacitor - 1µF, 35V 10% ......6-41, 6-42 91600071 Grommet - 59/64 I.D..........6-35 70025302 Capacitor - 15µF, 15V 10% ......6-41, 6-42 91600081 Grommet ..............6-33 70025303 Capacitor - 47µF, 10V 10% ......6-41, 6-42 91600100 Plug - Liner ...............
  • Page 164 650 Showcase Merchandiser Index Cash Box W/A ................. 6-15 CBA 650 Power Supply ..............6-28 Chain - Door Stop ................6-21 Accumulator ..................6-35 Chain Assembly ................6-23 Air Duct - Bottom ................6-21 Channel - Delivery Door ............... 6-12 Air Duct - Top ................
