- Page 1 Operation and Service Manual Copyright © Mincon 2010, All Rights Reserved.
-
Page 2: Table Of Contents
ABLE OF ONTENTS Table of Contents ..................2 1 Introduction ....................3 2 Installation and Operation ................. 4 Safety ............................4 Set up of HDD40 Hammer and Sonde ..................4 2.2.1 Storage ................................4 2.2.2 Setup of Sonde .............................. 4 2.2.2.1 Installation of DCI Sonde.............................. -
Page 3: Introduction
The Installation and Operation section will deal with setup of the system and basic operation. Following that we will deal with disassembly and servicing. When dealing with the HDD40 in the service section we will separate it into two parts: Firstly the Horizontal Directional Drilling hammer component that makes drilling possible and secondly the Sonde housing component that makes steering possible. -
Page 4: Installation And Operation
Storage If you intend to store the HDD40 Hammer we recommend that ½ pint (¼ litre) of good quality rock drill oil be poured into the hammer to protect it. To do this the hammer section should be unscrewed from the Bent Sub and then the oil should be poured into the top of the hammer and let flow down into the piston chamber of the hammer to coat the parts and protect them from rust and corrosion. - Page 5 Insert and push the DCI Sonde into the tube. Fit the DCI Adaptor Locating cap onto the DCI Sonde ensuring the Locating cap’s intrical key is seated correctly in the Sonde Keyway. Mincon – “Leaders in Rock Drilling Technology” Page 5...
- Page 6 Carriage go forward and the Sonde DCI Adaptor and then screw the Carriage Carriage Locking Cap groove seats Locking Cap in place over the Sonde Carriage Locating pin (See Step 14 for details of the pin). Mincon – “Leaders in Rock Drilling Technology” Page 6...
- Page 7 Above picture shows the Sonde Carriage Locating Pin. The pin is in the Insert and screw the Sonde Housing Backhead in place. Bent Sub set so that the Sonde will be aligned correctly in the twelve O’clock position. Mincon – “Leaders in Rock Drilling Technology” Page 7...
-
Page 8: Installation Of Sub-Sight Sonde
Adaptor end cap shown the assembly locking screw as shown above. Once completed the Sonde above. assembly can be installed from Step 8 above. Mincon – “Leaders in Rock Drilling Technology” Page 8... -
Page 9: Installation Of Bit
Chuck back in place. Step 3 Insert the bit into the Chuck so that the Bent Sub wear carbides are aligned in a straight line with the three bit wear carbides as illustrated above. Mincon – “Leaders in Rock Drilling Technology” Page 9... -
Page 10: Setup And Operation Of Support Station
Prior to operation the Support Station must be setup to ensure that correct and safe operation of the equipment is carried out. CAUTION – For safe working conditions during operation of the equipment it is essential to have received the appropriate training prior to starting up the equipment. Mincon – “Leaders in Rock Drilling Technology” Page 10... -
Page 11: Set Up Of Support Station
Enlarge loop on the other above. Above picture shows air end of the whip check on the air intake valve discharge side of support station. end and loop over air hose and release. Mincon – “Leaders in Rock Drilling Technology” Page 11... - Page 12 5. Fill oil to top of tank, but not past fitting in the middle of the neck. 6. Refit Oil tank cap and tighten using a hammer. CAUTION: Always make sure 4” cap is tight on tank and vent valve is closed before starting compressor. Mincon – “Leaders in Rock Drilling Technology” Page 12...
-
Page 13: Equipment Inspection Prior To Compressor Ignition
Operating correctly – Red light means air off Tri-Lite Controller Valve Operation (Valve closed) Green light air on (Valve Open) Red light – air off (Valve closed) prior to starting Tri-Lite Controller Valve compressor Mincon – “Leaders in Rock Drilling Technology” Page 13... -
Page 14: Pressure Regulator Adjustment
Check the in-line filter on the pump periodically for debris. In colder conditions antifreeze the pump and drain the 40 foot water hose and clean and empty the in-line filter to protect from freezing while not operating the drill. Mincon – “Leaders in Rock Drilling Technology” Page 14... -
Page 15: Commissioning Of Hammer
Insufficient thrust pressure will make the hammer drill erratically and less efficiently and cause premature wear to the bit and chuck splines with likely damage to the hammer components and threads. Mincon – “Leaders in Rock Drilling Technology” Page 15... - Page 16 The Air Consumption of the hammer is as per the chart below. The chart represents operating pressure and equivalent air consumption at sea level with an ambient temperature of 68°F (20°C). Mincon – “Leaders in Rock Drilling Technology” Page 16...
-
Page 17: Servicing
Opening Chuck and Backhead The threads used in Mincon Hammers are right hand threads. Proper tools and break-out systems should be used at all times to dismantle HDD hammers, otherwise damage may be caused to the components which could result in eventual failure or affect the performance of the Hammer. -
Page 18: Dismantling Hammer To Change Drill Bit
Place the bit retaining rings in and screw the chuck in place. Again make sure to have the thin end of the bit retaining rings at the blow tube end of the bit. Mincon – “Leaders in Rock Drilling Technology” Page 18... - Page 19 This gap should be between 0.015” and 0.030”, and can be measured using a feeler gauge. If the gap is less than the minimum, then the lock ring will need to be replaced. Protect the hammer as earlier described by internal lubrication. Mincon – “Leaders in Rock Drilling Technology” Page 19...
-
Page 20: Appendix
Appendix HDD40 exploded view and Parts List MINCON HDD40 PARTS LIST AND SPECIFICATIONS Item Description Part no. MINCON HDD40 HAMMER MHD301AS01 SONDE HOUSING ASSEMBLY MHS301AS01 SONDE HOUSING BACKHEAD MHS301BH01 Air Diverter Plug (Solid) MHS409DP01 Air Diverter Plug (1/8” Orifice) MHS409DP02... -
Page 21: Hdd40 Hammer Service Log
Distributor Probe OD ≥ 0.010” (0.25mm) B 0.795” (20.20mm) Piston ID EXTERNAL WEAR Description Wear Limit As Measured Wearsleeve Discard Dimension: 3.110” (79.0mm) Note: Chuck should be replaced when wear transfers to wearsleeve. Mincon – “Leaders in Rock Drilling Technology” Page 21... -
Page 22: Warranty
Mincon DTH Hammer or spare parts.
